Wireless FISHEYE IP Camera KEEYO LV-P-IP4M2FE 4Mpx IR 25m 180 degrees
Photo gallery
-
Manufacturer
-
Product Code
LV-P-IP4M2FE
-
Warranty
24 miesiące
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Compact
- Night visibility: up to 20m
- Connectivity: Wireless
- Memory card slot: Yes
- Audio: Yes
- Color: White
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,84 MB
-
Oprogramowanie do konfiguracji i obsługi zdalnej
Size: 162,4 MB
-
Size: 1,19 MB
Product Description
The LV-P-IP4M2FE is a camera for special tasks. With a FishEye lens, it achieves a field of view of 180°, making it an ideal camera even for small rooms. In addition, it does not require a DVR to operate, the footage can be recorded using a MicroSD card. The maximum capacity it will handle is 1TB. The camera also has infrared light illumination with a range of 15m, which is enough for indoor monitoring.
Features of the LV-P-IP4M2FE camera:
- High-resolution 4Mpx video recording
- Wireless WIFI connectivity
- Enhanced dynamic range with WDR technology
- PoE power supply support with IEEE 802.3af standard
- Support for microSD cards with a maximum capacity of 1TB
- 180° field of view
- Support in Bitvision mobile app
- Indoor application
Remote access from desktops and smartphones
The mobile app is a quick and easy way to operate your property's video surveillance system, with it you will be able to:
✅Save video snippets to your smartphone's memory
✅Configure time frames for motion detection
✅Receive notifications from motion detection or other events
✅Share your devices with other smartphones with the mobile app, such as family members or employees
Support popular browsers
The WEB server on KEEYO cameras is supported by popular browsers like Google Chrome, Mozilla Firefox or even Safari.
High-quality image
The latest technologies used in the camera's sensor and sensor, combined with advanced optics, provide images of high quality and excellent sharpness compared to lower resolution cameras. The device records at 4Mpx resolution ensuring that even the smallest detail is captured on the footage.
Fisheye lens
The Fisheye lens allows for a field of view larger than the human eye. In practice, this means that it is possible to monitor even small rooms with a single camera.
| Image sensor | 1/2.8" SONY Starvis CMOS with backside illumination |
| Resolution | 4MP |
| Effective pixels | 2592 (S) x 1520 (W) |
| Compression | H.264/H.264+/H.265/H.265+/JPEG/AVI |
| Audio compression | G.711A/U, AAC |
| TV system | PAL/NTSC |
| Electronic Shutter Time | Auto: PAL 1/25-1/10000 s; NTSC 1/30-1/10000 s |
| Minimum illumination | Color: 0.003 lux at F1.6, AGC ON; Black and white: 0 lux with IR. |
| Signal-to-noise ratio | ≥52dB |
| Scanning system | Progressive |
| Video output | Network |
| Reset button | Yes |
| Lens type | - |
| Focal length | Fisheye lens 1.1 mm |
| Focus control | Fixed |
| Lens type | Fixed focal len |
| Pixels | 4MP |
| Night vision | |
| Infrared LEDs | 42µx 3 pcs. |
| Infrared range | 15 m |
| Infrared status | Automatic control |
| Infrared activation | Intelligent, manual and scheduled |
| Networking | Ethernet RJ-45 (10/100Base-T) |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, SMTP, UDP, SNMP |
| ONVIF support | ONVIF 19.12 (S/T/G profile) |
| P2P | Yes, QR code support |
| POE | Internal POE, support IEEE 802.3af |
| Video delay | 0.3 s (within the local network) |
| Main stream 1 | 1920x1920@30fps |
| Main stream 2 | 1536x1536@30fps |
| Main stream 3 | 1024x1024@30fps |
| Secondary stream 1 | 1024x1024@30fps |
| Additional stream 2 | 720x720@30fps |
| Additional stream 3 | 512x512@30fps |
| Three streams | "1024x1024@30fps 720x720@30fps 512x512@30fps". |
| Browsers | IE8-11, Google Chrome, Firefox, Mac Safari |
| Login information | login: admin password: admin |
| Smartphone | iPhone, Android |
| Wireless | 3dBi antenna |
| Hotspot | No |
| Wi-Fi | Wi-Fi (IEEE802.11b/g/n), 2.4 GHz |
| Wi-Fi range | Max. 100 m unobstructed |
| AI function | Intelligent analysis |
| Camera functions | Day/night (color/black/white with IR filtering), image configuration, saturation/brightness/contrast/sharpness, mirroring, 3D NR, white balance, flicker control, video violation, HLC |
| Corridor pattern | None |
| ROI | Support |
| Fog removal mode | Support |
| BLC | Support |
| WDR | HDR: 120dB |
| Motion detection | Support |
| Privacy masking | 3 rectangular zones |
| Recording mode | NVR/VMS/Web/SD Card |
| Language | "Simplified Chinese, Traditional Chinese, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Dutch, Czech, Vietnamese" |
| Interface | Audio line input/output (3.5mm audio interface), built-in microphone and speaker |
| Alarm | 1 input/output |
| SD card slot | External, support up to 1 TB, built-in 4G memory |
| RS485 | None |
| General | Housing: metal, handle: plastic |
| Anti-cut handle | No |
| Infrared filter (IR Cut) | Yes |
| Operating temperature | -20°C to +60°C, max RH95% |
| Storage temperature | -20°C to +60°C, max RH95% |
| Power source | DC12V±10%, 550mA |
| Dimensions | ￠120 x 49 (W) mm |
| Weight | 500 g |
