Satel Perfecta 16-WRL Wireless Alarm 6x Sensor, LCD, App, GSM Notification

Set includes:

• Perfecta 16-WRL SET-A Main Board ( 1pc )
• PRF-LCD-WRL keypad ( 1 pc )
• Detector MPD-300 ( 6pcs)
• Wireless Siren MSP-300 ( 1pc )
• Transformer TRP 40VA/16V/18V ( 1pc )
• Rechargeable battery 12V 7A ( 1pc )

Remote access from your phone SATEL systems allow you to configure, control and view using the PERFECTA CONTROL application, which will provide you with constant access to your alarm system from any place on earth with Internet access. PERFECTA CONTROL allows you to: Check the status of individual devices Control relays Read data from sensors Arm / Disarm alarms Receive event notifications

Notification PUSH notifications on alarm systems are sent directly to users' smartphones via the mobile app, reporting real-time events such as motion detection or door opening. SMS and email serve as alternative communication channels, allowing the alarm system to send alerts and detailed event reports directly to the user's cell phone or email address, even when the user does not have access to the mobile app.

Built-in GSM/GPRS modem The GSM module in the control panels ensures reliability of communication, allowing alerts and alarm messages to be sent directly to the end user or to the monitoring station, even in the event of failure of telephone lines or the Internet. It allows the alarm system to be remotely controlled and configured via a smartphone or computer, increasing convenience and accessibility for the user. In addition, thanks to data encryption, the GSM module provides a high level of security for transmitted information, minimizing the risk of interception by unauthorized persons.

Home automation control The home automation control panel allows users to remotely manage various home systems, such as lighting, heating, and roller shutter systems, through a mobile app or web interface. This allows users to automate household tasks, as well as adjust settings based on user needs or detected events, offering not only increased security, but also comfort and energy efficiency.

Ability to set up two independent zones

In control panels, the ability to set up two zones allows independent management and control of different areas of a facility, making it possible, for example, to activate the alarm system only in a selected part of the building, while the rest remains unchanged. This allows users to flexibly adapt protection to individual needs and situations, for example, securing the office at night while the system remains disabled in the living area.

Schedule and time switches The scheduler in the control panels allows the security system to be automatically switched on and off at predetermined times, greatly enhancing user comfort and ensuring that protection is optimized without the need for manual intervention. As a result, users can rest assured about the safety of their property, even when they forget to activate the alarm system, which further contributes to saving energy and resources. In addition, the schedule also allows you to control home automation elements such as lighting, blinds, etc.

Built-in GSM/GPRS modem The GSM module in the control panels ensures reliability of communication, allowing alerts and alarm messages to be sent directly to the end user or to the monitoring station, even in the event of failure of telephone lines or the Internet. It allows the alarm system to be remotely controlled and configured via a smartphone or computer, increasing convenience and accessibility for the user. In addition, thanks to data encryption, the GSM module provides a high level of security for transmitted information, minimizing the risk of interception by unauthorized persons.

Jamming detection The jamming detection function in alarm panels is used to identify attempts to interfere with radio signals, a key aspect of ensuring uninterrupted communication and protecting against advanced attacks. When such an interference attempt is detected, the system can automatically notify owners or a monitoring station of the potential threat, allowing for a quick response and increasing the overall reliability of the alarm system.

The PERFECTA 16-WRL SET-A control panel comes complete with ANT-GSM-I antenna and OPU-4 P. The system based on the PERFECTA 16 control panel is characterized by quick installation, simple configuration and easy and intuitive operation. In addition to basic, traditional methods of system control, the PBX also offers more modern ones, such as the functional and intuitive PERFECTA CONTROL mobile device application.

Perfecta 16-WRL Main Board

• wired programmable inputs: 8 (max. 16)
• choice of configuration (NO, NC, EOL, 2EOL/NO, 2EOL/NC)
• ability to operate roller shutter and vibration detectors
• programmable wired outputs: 4 (max. 12)
• additional 4 wireless outputs (for MSP-300)
• integrated radio module (433MHz frequency)
• number of zones: 2 (3 surveillance modes each)
• event memory: 3854
• timers: 8 (exceptions can be set)
• integrated modules:
• GSM/GPRS with 2 SIM slots (SMS, station monitoring, PUSH notifications)
• voice (playback of voice messages)
• acoustic alarm verification (listening for sounds)
• automatic diagnostics of basic components
• communication bus for keypads (PRF-LCD) and expansion modules
• 15 user passwords (1 service password)
• system control:
• PRF-LCD / PRF-LCD-WRL keypads (max. 4)
• PERFECTA CONTROL mobile application
• MPT-350 remote controllers (max. 15)
• possibility to update software (firmware)
• built-in switching power supply
• protections: overload, total battery discharge
• 2 power outputs on the main board
• compliance with EN 50131 Grade 2
• dimensions: 160x110mm
• warranty: 24 months

PRF-LCD-WRL keypad

• cooperation with PERFECTA 16-WRL, PERFECTA 32-WRL control panels
• two-way coded radio communication in 433 MHz frequency band
• large, easy to read LCD display
• LEDs informing about partitions and system status
• quick activation of a selected arming mode by means of function keys
• panic, fire and rescue alarms called from keypad
• backlighting of the display and keys
• audible signaling of selected events in the system
• signaling loss of communication with the control panel
• power supply: two lithium batteries 3 V CR123A

4x MPD-300 detector

• digital detection algorithm with temperature compensation, providing high resistance to false alarms and repeatability of parameters,
• ability to change sensitivity allowing you to match the optimal detector parameters to the protected room,
• optional operation mode with immunity to movement of small animals up to 15kg, allowing to protect rooms with pets,
• power management system allowing for years of operation without replacing the CR123A lithium battery,
• LED indicating violations in test mode, making it easier to start up and later maintain the system,
• Sabotage detection - opening of the housing, detachment from the ground

MSP-300 Wireless Siren

• optical and acoustic signaling independently triggered via radio
• optical signaling: super bright LEDs
• acoustic signaling: piezoelectric transducer
• possibility to trigger one of several acoustic signals
• advanced radio circuit for optimized communication with low power consumption
• remote configuration
• power supply by efficient BAT-ER-3.6 battery with capacity of 13 Ah and wide operating temperature range
• operation in temperature from -40°C to +55°C
• tamper protection against opening the housing and detachment from the ground
