Wireless LCD Manipulator with Proximity Card Reader Satel INT-KWRL-BSB

223.98

Wireless LCD Manipulator with Proximity Card Reader Satel INT-KWRL-BSB
Wireless LCD Manipulator with Proximity Card Reader Satel INT-KWRL-BSB
Wireless LCD Manipulator with Proximity Card Reader Satel INT-KWRL-BSB
  • Manufacturer

    SATEL
  • Product Code

    INT-KWRL-BSB

  • Warranty

    24 miesiące


Ask about this product show form

  • Availability: in stock Shipping 24h

Price (Incl. VAT):

223,98 €

Add to Watchlist

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

Wireless LCD keypad with proximity card reader Satel INT-KWRL-BSB.



The INT-KWRL wireless keypad enables operation and programming of the INTEGRA series control panels. It is designed to operate as part of a two-way ABAX wireless system. In order to connect the keypad to the control panel, you will need one of the controllers: ACU-120 or ACU-270. The radio system used in INT-KWRL enables the keypad to operate at a distance of up to 400 m from ACU-270. In the case of ACU-120, this range is twice as long and amounts up to 800 m!


INT-KWRL offers full functionality known from wired keypads. In addition, it has a built-in proximity card and key fob reader. Thanks to this functionality, it is possible to operate the system without having to remember the password. Using the aforementioned passive transponders, it is possible to arm the system fully, disarm the system, as well as cancel the alarm.

The powerful batteries used in the INT-KWRL keypad allow the device to operate continuously for up to 3 years. This efficiency was achieved, among other things, by using a separate battery for the display and keypad backlighting. For additional reduction of power consumption, it is possible to disable the proximity card reader (e.g. when the alarm system is not to be operated with them). The device was developed for users who prefer a traditional interface for operating the alarm system, but expect solutions that are attractive in terms of design. An additional advantage of the wireless keypad is its high flexibility when it comes to the place of installation - there are no restrictions related to cable routing.


Main features
  • cooperation with control panels of INTEGRA and INTEGRA Plus families (Firmware 1.17 or later)
  • connection to the control panel requires the ACU-120 or ACU-270 controller (Firmware 5.03 or later)
  • full functionality corresponding to wired LCD keypads
  • two-way coded radio communication in the 868 MHz frequency band
  • range in open space:
  • up to 800 m when connected to ACU-120
  • up to 400 m in connection with ACU-270
  • built-in passive transponder reader: proximity cards and key fobs
  • Panic, FIRE, and AID alarms triggered from keypad
  • audible signaling of selected events in the system (piezoelectric transducer)
  • two operating modes: active/inactive
  • wake-up option
  • configuration via:
  • DLOADX program (in version 1.17.001 or higher)
  • keypad in service mode
  • large, easy-to-read LCD display
  • display of inscriptions compatible with the control panel language version
  • LEDs indicating the status of partitions and the system
  • backlighting of the display and keypad (white color)
  • tamper contact reacting to opening of the housing and detaching it from the wall
  • housing for quick and easy installation
  • power supply: two CR123A 3 V batteries

Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt
