Abax 2 Wireless glass break detector AGD-200 DG

The AGD-200 DG detector is used to detect glass breakage from ordinary, tempered and laminated glass. It uses advanced dual-track signal analysis in detection. The sensitivity of the built-in microphone can be adjusted. The device operates as part of a two-way ABAX 2/ABAX wireless system.

Configuration, as well as software updates of the AGD-200 DG are done remotely. Radio communication in the ABAX 2 system is encrypted in the AES standard.

The detector is characterized by low power consumption. It is powered by a CR123A 3 V lithium battery, the state of which is constantly monitored. The available "ECO" option (only in ABAX 2) allows up to four times the operating time, without having to replace the battery.

The device has an LED, indicating, among other things, a violation in test mode. In addition, it is equipped with tamper protection against opening and against detachment from the ground.

The detector is available in white (AGD-200), brown (AGD-200 BR) and dark gray (AGD-200 DG).

• glass breakage detection of plain, laminated and tempered glass
• advanced dual-track (multi-frequency) signal analysis
• cooperation with:
• ABAX 2 system controllers (ACU-220 and ACU-280) and ARU-200 retransmitter
• ABAX system controllers (ACU-120 and ACU-270), INTEGRA 128-WRL control panel and ARU-100 retransmitter
• radio communication range in open space:
• in ABAX 2: up to 2000 m (with ACU-220) / up to 1200 m (with ACU-280).
• in ABAX: up to 500 m
• remote configuration and software update
• detection sensitivity adjustment
• built-in temperature sensor (temperature measurement from -10°C to +55°C)
• LED indicator signaling violations in test mode
• low power consumption and battery monitoring
• "ECO" option to extend battery life (ABAX 2 only)
• power supply: CR123A 3 V battery
• tamper protection against opening the housing and against detachment from the ground
