Curtain sensor AOCD-260
Photo gallery
-
Manufacturer
-
Product Code
AOCD-260
-
Warranty
24 miesiące
- Sensor type: Kurtynowa
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,09 MB
-
Size: 0,26 MB
-
Size: 0,13 MB
Do you represent a budgetary unit?
Check out the deferred payment option.
Product Description
AOCD-260 curtain detector
The AOCD-260 curtain detector monitors a narrow strip of space with a width of only 0.6 m and a length of 10 m. The device detects movement when it crosses the border of the protected area - it can be part of perimeter protection. It operates as part of a two-way ABAX 2/ABAX wireless system. The product complies with the requirements of EN 50131 Grade 2 (for indoor applications). The detector has two detection paths: infrared and microwave, which can be adjusted independently. Detection is based on digital signal processing, supported by dynamic temperature compensation, ensuring correct operation of the detector in the temperature range from -40°C to +55°C. The AOCD-260 monitors the motion detection system and signals any irregularities in its operation. The detector is characterized by high resistance to false alarms. Configuring the device and updating its software is done remotely. Radio communication in the ABAX 2 system is encrypted in the AES standard.
AOCD-260 has a tri-color LED indicating, among other things, violation in test mode. The detector is powered by a CR123A 3 V battery. When its charge level is lower than the set value, the detector will report low battery information. The available ECO option (only in ABAX 2) allows up to four times the operating time without changing the battery. The device has a polycarbonate housing (IP54 rating). The detector is equipped with tamper protection against opening and against detachment from the ground. It can be mounted directly on the wall (Grade 2) or with an angle bracket.
When it is required to move the detector away from the wall, even for a distance of several centimeters, it is worth using the BRACKET E modular bracket. Especially if there is a gutter or lamp in the vicinity of the device, which may limit the full range of the detector's detection field. A special insert for AGATE/AOCD-260 detectors allows their installation also using BRACKET A and BRACKET B brackets (recommended for indoor installation). All the above-mentioned brackets are suitable for wall and ceiling mounting. In addition, BRACKET E and BRACKET B have an enclosed design that allows the cable to be hidden, thus improving the overall aesthetics of the installation.
Main features:
- compliance with EN 50131 Grade 2 requirements (for indoor applications)
- two detection paths: PIR and microwave
- detection area: 10 m x 0.6 m, 6° angle
- high resistance to false alarms
- advanced digital signal processing
- dynamic compensation of temperature changes
- cooperation with:
- ABAX 2 system controllers (ACU-220 and ACU-280) and ARU-200 retransmitter
- ABAX system controllers (ACU-120 and ACU-270), INTEGRA 128-WRL control panel and ARU-100 retransmitter
- radio communication range in open space:
- in ABAX 2: up to 2000 m (with ACU-220) / up to 1600 m (with ACU-280).
- in ABAX: up to 500 m
- remote configuration and software update
- independently adjustable sensitivity of PIR and MW tracks
- built-in temperature sensor (temperature measurement from -40°C to +55°C)
- LED indicator signaling violations in test mode
- splash-proof, weatherproof polycarbonate housing with IP54 rating
- low power consumption and battery monitoring
- "ECO" option to extend battery life (ABAX 2 only)
- power supply: CR123A 3 V battery
- tamper protection against opening the housing and against detachment from the ground
- can be mounted directly on a flat surface or with the use of:
- angle bracket
- adjustable bracket BRACKET A
- tilt angle adjustment in the range of approx. 30°
- 90° rotation angle adjustment
- possibility to mount the detector on the wall or ceiling
- adjustable BRACKET B bracket
- internal channel for cable routing
- fully enclosed design for improved installation aesthetics
- tilt angle adjustment of approx. 30°
- 90° rotation angle adjustment
- possibility to mount the detector on the wall or ceiling
- distance bracket BRACKET E
- BRACKET E-1 (GY) - body for mounting E-2A bracket
- BRACKET E-2A (GY) - insert for mounting AOCD-260 curtain detectors, also on BRACKET A or BRACKET B bracket
- BRACKET E-3 (GY) - distance (height 30 mm) for moving the detector away from the wall or ceiling
- BRACKET E-4 (GY) - base (height 20 mm)
- BRACKET E-6 - tamper sensor (1 NO/NC switch, wire length 50 cm)
Technical specifications:
| Expected battery life (in years) | up to 2 |
| Detectable movement speed | 0.3...3 m/s |
| Operating temperature range | -40°C...+55°C |
| Recommended installation height | 2,4 m |
| Maximum current consumption | 26 mA |
| Weight | 118 g |
| Maximum humidity | 93±3% |
| Operating frequency band | 868.0 ÷ 868.6 MHz |
| Battery | CR123A 3V |
| Standby current consumption | 70 µA |
| Dimensions | 44 x 105 x 40 mm |
| Environmental class according to EN50130-5 | IIIa |
| Standards met | EN50131-1, EN50130-4, EN50130-5 |
| Temperature measurement accuracy | ±1°C |
| Microwave frequency | 24.125 GHz |
| Start-up time | 45 s |
| Degree of protection IP | IP54 |
| Radio communication range (in open area) for ACU-120 | up to 500 m |
| Radio communication range (outdoors) for ACU-270 | up to 500 m |
| Radio communication range (outdoors) for ACU-220 | up to 2000 m |
| Radio communication range (in the open field) for ACU-280 | up to 1600 m |
| Temperature measurement in the range | -40°C...+55°C |
| Detection area | 10 m x 0.6 m, 6° |
| Grade of protection according to EN50131-2-4 (mounting directly to wall) | Grade 2 |
"Source: SATEL sp. z o.o., www.SATEL.pl".
