RACK Power Supply ZR12-150X2

The image shows a rack-mounted power supply unit with a black metal frame and two perforated metal covers for ventilation. It features dual 12V DC outputs, each providing 12.5A, designed for efficient power distribution in electronic systems.

Manufacturer
Delta
Product Code

ZR12-150X2
Warranty

24 miesiące

see description

Ask about this product show form

Files attached to the product show files

Availability: in stock Shipping 24/48h

Price (Incl. VAT):

101,01 €

Add to Watchlist

Do you represent a budgetary unit?
Check out the deferred payment option.

Product Description

High-quality professional switching power supply with short-circuit, overvoltage and overload protection.

Technical specifications:

Power supply type:	Impulse - 2 pcs.
Power supply voltage:	switch selectable 90 V ... 132 V AC, 180 V ... 264 V AC
Frequency of supply voltage:	47 ... 63 Hz
Power supply power:	2 x 150 W
Output voltage:	2 x 12 V DC
Output voltage adjustment:	11.4 V ... 13.2 V DC
Current capacity of the power supply:	2 x 12.5 A
Efficiency:	89 %
MTBF (mean time between failures):	> 700000 h - Telcordia SR-332
Protections:	Surge protection Short-circuit protection Overload
Manufacturer / Brand:	DELTA
Housing type:	1 U 19" rack
Operating temperature / relative humidity:	-10 °C ... 70 °C / 10 % ... 95 %
Weight:	1.17 kg
Dimensions:	483 x 44 x 100 mm
