High-speed surveillance camera 4Mpx BCS-SDIP2432Ai-II Starlight Technology
Photo gallery
-
Manufacturer
-
Product Code
BCS-SDIP2432Ai-II
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Rotating
- Memory card slot: Yes
- Audio: Yes
Files attached to the product show files
Price (Incl. VAT):
Archival product
Najniższy koszt dostawy: 21,24 zł
Do you represent a budgetary unit?
Check out the deferred payment option.
Related products
Product Description
Main features:
- 1/2.8" 4Mpx PS STARVIS CMOS sensor
- Starlight technology
- H.265+/H.264+/MJPEG encoding
- Support for three encoding streams
- 4.9-156mm lens with 32× optical zoom
- Mechanical infrared filter
- Built-in web-service, compatibility with BCS-NVR, CMS(BCS Manager), BCS mobile app(iOS, android), P2P
- Features AWB, AES, AGC, BLC, HLC, WDR(120dB), Ultra DNR, Defog, ROI, EIS
- Smart functions: perimeter protection, line crossing, area intrusion, face detection, audio detection, auto-tracking, SMD Plus, metadata
- Max 30fps@4Mpx(2560×1440)
- Max operation speed 500°/s, PAN:0°~360°, TILT:0°~90°
- Automation functions: 300 presets, 5 tracks, 8 routes, auto-scan, auto-pan
- Alarm 2/1, audio 1/1
- Intelligent 3D positioning
- IP67, IK10 metal housing
- Operating conditions -40°C ~ +60°C
- Power supply DC24V, PoE+(802.3at)
| Model | BCS-SDIP2432Ai-II |
| Video system | IP |
| Scanning system | Progressive Scan |
| Sensor | 1/2.8" 4Mpx STARVIS CMOS |
| Number of pixels | 2560×1440 |
| RAM/ROM | 1GB/4GB |
| Sensitivity | 0.005Lux@F1.35; B/W: 0.0005Lux@F1.35 |
| Lens | Motozoom 4.9-156mm; F1.35-F4.4 |
| Viewing angle | H: 61.6°-2.1°; V: 35.1°-1.3°; D: 68.2°-2.5° |
| Zoom | Optical 32×, digital 16× |
| DORI | Detect 3120m/ Observe 1232m/ Recognize 624m/ Identify 312m |
| White balance | (AWB) Auto/ Manual |
| Backlight compensation | BLC/HLC/WDR(120dB) |
| Shutter | 1/1~1/30000s |
| Gain control | (AGC) Auto/manual |
| Noise reduction | Ultra 2D/3D DNR |
| Motion detection | 4 areas |
| Privacy mask | 24 areas |
| Image rotation | Flip 180° |
| Sharpening | Auto/manual |
| Day/Night | Mechanical IR filter (ICR |
| PAN Range | 0°~360° infinite |
| TILT Range | 0°~90° auto flip 180° |
| PAN speed | 0.1°~350°/s (500°/s in preset) |
| TILT speed | 0.1°~250°/s (500°/s in preset) |
| Automation functions | 300 presets, 5 tracks, 8 routes, auto-scan, auto-pan |
| Start/stop | Restore last PTZ position after power failure; activate preset, track, route after idle period |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG (second stream) |
| Resolution | 4M (2560 × 1440); 3M (2048 × 1536); 1080P (1920 × 1080); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Main stream | 4M/3M/1080P/1.3M/720P (1-25/30 fps) |
| Second stream | D1/CIF (1-25/30 fps) |
| Third stream | 720P (1-25/30 fps) |
| Bitrate | H.264: 3 Kbps-20480 Kbps H.265: 3 Kbps-20480 Kbps |
| Network connection | RJ-45 (10M/100Mbps) |
| Protocols | IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Audio | 1 input / 1 output |
| Audio coding | G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723 |
| Alarm | 2 inputs / 1 output |
| Compatibility | ONVIF(S/G/T) |
| Users | Maximum of 20 logged in |
| Mobile users | iOS, android |
| Memory card slot | microSD up to 256GB |
| Power supply | DC24V/2.5A, PoE+(802.3at), Power consumption max. 16W |
| Operating conditions | -40°C ~+60°C / 10~95%RH |
| Housing Metal | IP67, IK10 |
| Dimensions and weight | Φ186 mm x 253 mm (Φ7.32" x 9.96") 2.5kg |
