IP Thermal Camera TPC-BF5601-T(25MM) DAHUA
Photo gallery
-
Manufacturer
-
Product Code
TPC-BF5601-T(25MM)
-
Warranty
36 miesięcy
- Technology: Thermal
- Resolution: 1MPx
- Enclosure: Tube
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Type: Stationary
Ask about this product show form
Related products
Product Description
Thermal IP camera TPC-BF5601-T(25MM) DAHUA
The TPC-BF5601-T(25MM) thermal imaging camera is a state-of-the-art solution to detect the presence of people, animals and vehicles regardless of the prevailing video conditions. The device is equipped with a sensitive VOx microbolometer, allowing to observe objects in fog, smoke and in the absence of light An additional advantage of the TPC series cameras is the ability to detect fire and send a signal to the control panel in case of its occurrence. The ability to be powered by PoE, in accordance with the 802.3af standard, makes the device even more versatile and easier to install.
| Standard: | TCP/IP, CVBS |
| Transducer: | Uncooled VOx microbolometer |
| Matrix size: | 640 x 512 px |
| Spot size: | 17 µm |
| Thermal sensitivity (NETD): | ≤ 40 mK @ F1.0 |
| Spectral range: | 8 µm ... 14 µm |
| Resolution: | 1280 x 1024 - 1.4 Mpx, 1280 x 720 - 720p, 640 x 512 - 0.3 Mpx |
| Lens: | 25 mm |
| Viewing angle: | 25 ° |
| Video output: | CVBS, PAL - 1 Vpp / 75 Ω, BNC |
| RS-485 interface: | Yes |
| Memory card slot: | Supports Micro SD cards up to 256GB (local recording possible) |
| Video compression method: | H.265 / H.264M / H.264H / H. 264B / MJPEG |
| Alarm inputs / outputs: | 2 / 2 |
| Audio: |
|
| Temperature measurement: |
|
| Temperature measurement range: |
|
| Main stream transmission speed: | 25 fps @ 1280 x 1024 |
| Network interface: | 10/100 Base-T (RJ-45) |
| Network protocols: | HTTP, HTTPS, TCP/IP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE IPv4/IPv6, SNMP, QoS, UPnP, NTP |
| WEB Server: | Built-in |
| Max. number of online users: | 20 |
| ONVIF: | Yes |
| Cell phone access: | Port 37777 |
| Default IP address: | 192.168.1.108 |
| Default admin login/password.: | admin / admin |
| Web access ports: | 80, 37777 |
| Access ports via PC application: | 37777 |
| Access ports viamobile app: | 37777 |
| ONVIF port: | 80 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Secondary stream |
| Selected features: |
|
| Powersupply: |
|
| Power consumption: | max. 13 W |
| Housing: | Compact - Metal |
| Color: | White + Black |
| Operating temperature : | -40 °C ... 70 °C |
| Leakage class: | IP67 |
| Weight: | 1.4 kg |
| Dimensions: | 291 x 104 x 97 mm |
| Supported languages: | English |
| Manufacturer/Brand: | DAHUA |
