Switch poe GTX-B1-24-242SFP 24-port sfp

The image shows a sleek, black 24-port Gigabit PoE switch with additional SFP ports for enhanced connectivity. The switch features a sturdy metal casing with ventilation on the sides for efficient cooling.

  • Product Code

    GTX-B1-24-242SFP

  • Warranty

    24 miesiące

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: Product temporarily unavaliable

Price (Incl. VAT):

399,30 €

Add to Watchlist

Powiadom o dostępności pokaż formularz

Shipping from: 12,98 €

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

POE Switch GTX-B1-24-242SFP 24-PORT SFP.

With its reliability and transmission quality assurance, the GTX-B1-24-242SFP 24-Port PoE Switch is an ideal solution for IP CCTV applications The PoE power supply capability, according to the 802.3af/at standard, makes the device even more versatile and easier to install


Technical specifications:



LAN ports:
  • 24 x RJ45 ( 24 x PoE (802.3af/at) ),
  • 2 x SFP port - Uplink
Web / console management:No
LEDs:Power, PoE, Link/Act, Speed
Transmission speed:
  • 1000 Mbps : 2 x SFP Port - Uplink,
  • 10 / 100 / 1000 Mbps : 24 x LAN & PoE Port.
Operating modes:
  • NOM - Normal - the device works like a normal PoE switch.
  • VLAN - Ports 1 ... 22 are isolated from each other and work separately with ports 23, 24
  • CENK (Surveillance Priority Transmission for Uplink) - port traffic balancing control to prevent loss of large data packets
Maximum output power:30 W / port PoE - Ports 1 ... 24
Maximum total power:400 W
MAC address table:8k
Selected features:
  • Auto MDI/MDI-X detection - automatically detects data transmission mode
  • Full Duplex : IEEE802.3x,Half Duplex : Back Pressure
  • PD Alive mode - monitors ports that are powering PoE devices and automatically restarts by cutting off power when an unresponsive device is detected
  • MTBF (mean time between failures): 50000 h
Certifications:CE, FCC Class B
Powersupply:100 ... 265 V AC
Operating temperature:-10 °C ... 45 °C
Weight:3.39 kg
Dimensions:440 x 290 x 45 mm, RACK 19", 1U
