Surveillance Kit 6x Camera BCS-B-EIP12FR3(2.0) Full HD IR 30m Audio PoE 1TB
Photo gallery
-
Manufacturer
-
Product Code
ZM26352
-
Warranty
24 miesiące
- Technology: IP
- Resolution: 2Mpx
- Enclosure: Dome
- Number of cameras: 6
- Connectivity: Wired
- Color: White
Ask about this product show form
Related products
Product Description
Our kits are carefully selected devices that guarantee full compatibility and efficiency. You will find all the necessary components and accessories that will allow you to immediately start installing and configuring your equipment.
In surveillance cameras is a technology that allows direct communication between the camera and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:
The Power over Ethernet (PoE) function in surveillance cameras is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of surveillance systems.
H.265+ coding, also known as High Efficiency Video Coding (HEVC+), is an advanced video compression technology used in modern surveillance systems. It is an extension of the H.265/HEVC standard, providing even higher compression efficiency than its predecessors. The main features of H.265+ coding in surveillance DVRs are:
BCS-B-EIP12FR3(2.0) dome camera
D.O.R.I.
The WDR (Wide Dynamic Range) function, or Wide Dynamic Range, in surveillance cameras is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the WDR function are:
The white light illumination feature of surveillance cameras is used to improve image quality in low-light conditions. Here are some key aspects of this technology:
Accessories:
The kit includes:
- BCS-B-NVR0801-8P(2.0) DVR ( 1pc ).
- BCS-B-EIP12FR3(2.0) camera ( 6pcs ).
- Hard drive 1TB ( 1pc ).
- UTP cat.5e cable ( 30m )
- Sticker "Attention Object Monitored" ( 1pcs )
- Set of RJ45 plugs
Main features:
- Complete monitor kit with 6 cameras, DVR and all necessary accessories.
- High image quality 2560x1960p pixels (2Mpx)
- Viewing angle of cameras: H: 106.7°, V: 57.1° D: 115.7°
- Outdoor/indoor mountable camera
- Built-in intelligent image recognition and analysis algorithms
- Enhanced recording performance with H.265+ codec
- Infrared light range - 30m
- Cameras meeting IP67 waterproof rating
- Audio recording with a microphone built into the cameras
- Cameras with loudspeaker enabling two-way communication
- Hard drive with a capacity of 1TB, dedicated for use in video surveillance systems
- Possibility of remote monitoring via a web browser, PC application and mobile device application.
- P2P (cloud) support - a feature that allows remote access without port forwarding and public IP address
Remote access from phone and desktop computerBCS systems allow you to configure, control and view using the BCS Line and BCS Manager applications, which will provide you with constant access to monitoring from anywhere on earth with Internet access. The above programs allow you to:
|
 |
P2P function
In surveillance cameras is a technology that allows direct communication between the camera and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:
- Direct Connection: P2P allows a direct connection between the camera and the user's device. This means that video data can be transmitted directly, without having to go through an intermediary server.
- Ease of Setup: One of the main advantages of P2P is the ease of setup. Users often only need to scan a QR code or enter a camera ID to establish a connection.
- Remote Access: The user can access the camera's video from anywhere in the world, provided both the camera and the end device have Internet access.
Power Over Ethernet (PoE)
The Power over Ethernet (PoE) function in surveillance cameras is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of surveillance systems.
High-quality imageA light-sensitive sensor and a high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The device records at 2Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
|
 |
IP DVR BCS-B-NVR0801-8P(2.0) 8 channel DVR.
- Supports 8 IP channels
- Support for P2P mobile application
- High resolution recording up to 4K
- H.265+ video encoding
Efficient storage
H.265+ coding, also known as High Efficiency Video Coding (HEVC+), is an advanced video compression technology used in modern surveillance systems. It is an extension of the H.265/HEVC standard, providing even higher compression efficiency than its predecessors. The main features of H.265+ coding in surveillance DVRs are:
- Higher Compression Efficiency: H.265+ makes it possible to significantly reduce the size of video files while maintaining the same image quality. This saves disk space and increases the storage time of recordings.
- Energy Savings: More efficient compression reduces the CPU load, resulting in lower power consumption of surveillance equipment.
BCS-B-EIP12FR3(2.0) dome camera
- Resolution: 2 Mpx
- Sensor: 1/2.8''
- Scanning system: Progressive Scan
- Pixels: 1920(H)×1080(V)
- Lens: Fixed
- Focal length: 2.8mm
- Aperture: F2.1
- Focus: Fixed
- Iris: Fixed
- Digital zoom: 16×
- Viewing angle: H: 106.7°, V: 57.1° D: 115.7°
- DORI: Detect 43m / Observe 17m / Recognize 9m / Identify 4m
- Camera sensitivity: 0.02Lux(F2.1,AGC) 0Lux(B/W,IR)
- S/N ratio: 52dB
- White balance: (AWB) Auto / manual
- WDR: DWDR
- Background compensation: BLC / HLC / DWDR
- Shutter: Auto / manual 1~1/100000s
- Gain Control: (AGC) Auto / manual
- Noise Reduction: 2D/3D DNR
- Image rotation: Mirror, Flip 0°/90°/180°/270°
- Number of streams: 2
People and vehicle detectionMotion detection with silhouette recognition of people and vehicles in surveillance cameras is an advanced feature that allows to increase the precision and efficiency of monitoring systems. It allows the camera to classify notifications according to the type of silhouette detected. At the same time providing more detailed information, but also completely filtering out irrelevant ones such as: Moving trees and bushes. |
 |
Automatic day/night modeAdapted to work in all lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens. |
 |
IP67-compliant housing
Such an enclosure protects the camera from external factors such as dust, dirt and moisture, which is especially important in industrial or dusty environments. Cameras with IP67 housing can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage. |
 |
D.O.R.I.
- Detection (43m): The system is able to detect the presence of an object or person at a distance of up to 43 meters. This means that at this distance you can tell that something is within the camera's range of view, but you can't necessarily determine what it is.
- Observation (17m): At distances of up to 17 meters, the system can not only detect an object, but also provide enough detail for the observer to get an idea of the general shape and perhaps some of the characteristics of the object, but without exact recognition.
- Recognition (9m): Recognition at a distance of up to 9 meters enables the system to provide enough detail for the observer to determine the type of object, for example, to distinguish whether it is a person, a car or another object.
- Identification (4m): At a distance of up to 4 meters, the system is able to provide a highly detailed image to identify specific features of an object or person, such as a face, vehicle license plate, etc., enabling accurate identification.
Wide dynamic range - That is, high quality in difficult conditions
The WDR (Wide Dynamic Range) function, or Wide Dynamic Range, in surveillance cameras is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the WDR function are:
- Exposure balancing: WDR helps produce clear images in situations where there is strong backlighting or underexposure, such as when filming from inside a building overlooking a brightly lit exterior.
- Preservation of detail: With WDR, cameras can better capture details in the dark and bright parts of the image. This allows clear recognition of faces, vehicle license plate numbers and other important elements that might not be visible under standard conditions.
- Image processing technology: WDR achieves its effects by quickly switching between different exposure levels or by combining several images taken with different exposure settings to create a single, balanced image.
- Usefulness in security monitoring: This feature is particularly important in security monitoring systems, where it is important to get clear images in a wide variety of lighting conditions, both indoors and outdoors.
LED illumination and color images after dark
The white light illumination feature of surveillance cameras is used to improve image quality in low-light conditions. Here are some key aspects of this technology:
- Improving visibility at night: When natural light levels are low, white light illumination produces a colorful and clear image that is typically of better quality than images obtained using infrared (IR).
- Preventive effect: Bright light can act as a deterrent to potential intruders or criminals, as it signals that the area is being monitored and well lit.
Video and audio recordingThe audio recording function of surveillance cameras allows you to record sounds along with video, which significantly increases the capabilities and efficiency of surveillance systems. The main advantages of such a solution are:
|
 |
Accessories:
For whom will this monitoring kit be suitable?
This is a modern solution with a wide range of applications. Reach for this universal set if you are interested, for example, in monitoring rooms, grounds or objects both indoors and outdoors. It will prove useful wherever you can run a cable installation.
With its help it is possible, among other things:
- monitoring of a store,
- monitoring of a wholesale and warehouse, as well as a production hall,
- monitoring of a school, monitoring of a kindergarten or other educational institutions,
- monitoring of a backyard, sports field or playground,
- monitoring of a private home,
- monitoring of a bar and restaurant,
- monitoring of a parking lot.
Choose this set if you need a professional monitoring system that will not let you down.
