Wireless intercom EURA ADP-80A3 - white-graphite, 426~440 MHz, range up to 100m, 1 entrance support.
Photo gallery
-
Manufacturer
-
Product Code
A31A282
-
Warranty
24 miesiące
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,94 MB
-
Size: 1,59 MB
-
Size: 0,43 MB
Product Description
Main features:
- Power type: Rechargeable (3.7V/ 2200mAh) 18650 battery.
- DC 5V charging voltage
- Housing material: Plastic
- Current consumption - standby / operation<110uA / <350mA
- Operating frequency 426~440 MHz
- Working rangeymax. up to 100m outdoor (indoor - range depends on type of obstacles)
- Housing materialPlastic material
- Mounting method of the outdoor unitSurface mounted
- Protective canopy
- Protection class IP44
The VDP-80A3 wireless intercom is an innovative solution for those who want to enjoy the functionality of an intercom without the hassle of running wires. The ADA-90A3 outdoor cassette communicates with the uniphone in the 426-440 MHz radio band. In order to use the full functionality of the device, it is possible to connect an electromagnetic bolt to control the entrance of visitors. The cassette illuminates the button when communication with the uniphone is established. The device is powered by 12V DC. The wireless uniphone - Eura ADA-80A3 - allows you to operate the entrance through direct control of the electromagnetic bolt. In addition, it is equipped with a 3-level ringer volume control function, moreover, the user can select one of 16 available chime melodies. The device is powered by a built-in rechargeable battery. The uniphone is charged via the built-in microUSB socket, located on the back of the device. The built-in antenna provides the device with connectivity up to 100 meters (in open areas).
Video instructions:
Video presentation of the product:
Technical specifications:
| Uniphone: | |
| Power supply type | Rechargeable (3.7V/ 2200mAh) 18650 battery |
| Charging voltage | DC 5V |
| Current consumption - standby / operation | <800uA / <350mA |
| Operating frequency | 426~440 MHz |
| Range of operation | max. up to 100m outdoors (indoors - range depends on type of obstructions) |
| Housing material | Plastic |
| Uniphone dimensions (H x W x D) | 154 x 54 x 36 mm |
| Net weight of the uniphone | 160 g |
| External cassette: | |
| Power supply voltage | 12V DC |
| Current consumption - standby / operation | <110uA / <350mA |
| Operating frequency | 426~440 MHz |
| Range of operation | max. up to 100m outdoors (indoors - range depends on type of obstructions) |
| Housing material | Plastic |
| External cassette mounting method | Surface mounted |
| Protective canopy | Yes |
| Protection rating | IP44 |
| Temperature range of the cassette | -10ºC ~ +50ºC |
| Dimensions of external cassette (H x W x D) | 158 x 62 x 50.5 mm |
| Net weight of the cassette | 160 g |
| Logistics data: | |
| Package dimensions (W x SZ x G) | 160 x 190 x 55 mm |
| Gross weight | 450 g |
| Type of packaging | Carton |
