IP Recorder 16-channel, dual-disk BCS-V-NVR1602-A-4K-AI
Photo gallery
-
Manufacturer
-
Product Code
BCS-V-NVR1602-A-4K-AI
-
Warranty
36 miesięcy
- Technology: IP
- Number of channels: 16
- Built-in POE switch: No
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,32 MB
-
Size: 1,44 MB
-
Size: 12,48 MB
Product Description
Main features:
- Ability to display and record video from 16 IP cameras simultaneously (max. 12 Mpx)
- Intelligent analysis of 4 channels with 4 Mpx camera
- Input bitrate: 160 Mbps/output: 256 Mbps
- Gigabit Ethernet network interface support P2P function
- Display performance: 16 x 2 Mpx ( 30 fps)
- Support for basic functions of intelligent image analysis
- Space for 2 SATA hard drives, each with max. 10 TB (20 TB total)
- Built-in outputsHDMI, VGAandBNC- max. Display resolution of 3840 x 2160 (for HDMI1)
- Built-in 2 USB ports: 1x USB 3.0 and 1x USB 2.0
- Built-in 4 alarm inputs and 1 alarm output
- Built-in 1 audio input and 1 audio output
- Built-in RS-485 and RS-232 interface
- CompressionH.265+/ H.265 / H.264+ / H.264 / MPEG4
BCS-V-NVR1602-A-4K-AI is a universal DVR. It works great in systems where high quality recording is crucial. Consequently, it can be successfully used in places such as railroad stations, bank facilities, industrial or public use facilities.
Series "4K"- Support for high-resolution cameras (max. 32 Mpx)
A major advantage of DVRs belonging to the "4K" series is the support of high-resolution IP cameras. The BCS-V-NVR1602-A-4K-AI model can effectively display and record video from 16 cameras, at a maximum resolution of 32/24 Mpx for 1 channel. By which it works great in places where high quality of generated image is crucial.
Technical specifications:
| Device Name | BCS-V-NVR1602-A-4K-Ai |
| Product line | BCS View |
| System | IP |
| Pentaplex function | Live viewing / recording / playback / archiving / remote access |
| Channels | 16 |
| Drives | 2 |
| Disk capacity | 10 TB |
| Max recording resolution | 32 Mpx |
| Input bandwidth | 160Mbps |
| Output bandwidth | 256Mbps |
| Display performance | 16×2M(30fps) |
| Recording resolution | 32M(ch1) / 24M(ch1) / 12M / 8M / 6M / 5M / 4M / 3M / 2M / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Video compression | H.265+ / H265 / H.264+ / H.264 / MPEG4 (ONVIF H.264) |
| Video outputs | HDMI4K/VGA/BNC |
| HDMI display resolution | 3840×2160 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolution | 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| Output split | 1/4/6/8/9/16 |
| Playback | 1/4/9/16 |
| Archiving | Possibility of ripping footage to external media such as USB FLASH, USB HDD |
| Users | 128 |
| Interfaces | 1×USB2.0, 1×USB3.0 |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711ulaw/G.711alaw/G.722/G.726/MP2L2 |
| Alarm input | 4 |
| Alarm output | 1 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Networking | 2×RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF |
| Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Power supply | 12V DC |
| Power consumption (without drives) | 15W max |
| Operating conditions | -10°C~+55°C max 90% RH |
| Enclosure | 1U |
| Dimensions (W×D×H) | 385×315×52mm |
| Weight (without drives) | 1.6 kg |
| Ai - Intelligent functions from the DVR | Face detection and face identification or perimeter protection (person/vehicle recognition mechanical) |
| Ai - Perimeter protection | 4 2Mpx channels, 12 rules |
| Ai - Face detection | 1 8Mpx channel |
| Ai - Face identification | 4 identification channels, 16 databases, 10K images (max 512KB, total 150MB) |
