Extralink 37U 600x800 Black | Rack cabinet | standing
Photo gallery
-
Manufacturer
-
Product Code
EX.11397
Ask about this product show form
Files attached to the product show files
Related products
Product Description
Main features
- Front and rear doors
- Front door with small lock made of tempered glass
- Possibility to open the door to the left or right side
- Superb design, precise dimensions, meticulous workmanship
- Adjustable feet, heavy duty casters
- Adjustable dimensions of cable entrances for top cover and bottom plate
- Reliable body connection by means of a series connection kit
- Removable side panels for easy maintenance
Standing rack cabinet by EXTRALINK - 37U, 600 × 800
The rack cabinet from Extralink is designed for wall mounting in offices, network server rooms and CCTV control rooms. The outer walls are made of cold-rolled steel sheet. Equipped with a pane of tempered glass, the front door can open to the left or right side.
Clearly marked cabinet height
The vertical rails are properly marked for height, which is as high as 37U (from unit), providing enough space to mount more equipment. However, the total height of the cabinet is 176.5 cm.
Easy removal of the side walls
The latches on the side walls allow them to be removed. Locks and keys are included.
Simple cable management
Up to 4 cable pulling grommets have been placed in the bottom panel of the cabinet, thus reducing the risk of cables getting pinched or tangled.
The ceiling of the cabinet adapted to install fans
On the ceiling of the cabinet are prepared 4 places for installing fans for better cooling of devices, there is also an additional cable pulling grommet.
Technical specifications:
| Cabinet height | 37U |
| Soundproof | No |
| Depth | 800mm |
| Product depth | 800 |
| Color | Black |
| Product color | Black |
| Front door construction | Tempered glass |
| Rear door construction | Steel |
| Side panel construction | Steel |
| Wheels | Yes |
| Number of stabilizer foot screws | 4 |
| Number of fans | 4 |
| Maximum weight | 600 |
| Materials | Glass, Steel |
| Model | Freestanding stand |
| Side panels included | Yes |
| Rack capacity | 37U |
| Adjustable feet | Yes |
| Rails | Yes |
| Cooling type | Passive |
| Door type | Glazed |
| Frame type | Closed |
| Size | 48,3 |
| Stabilizing foot screw | Yes |
| Width | 600mm |
| Product width | 600 |
| Removable side panels | Yes |
| Product height | 1765 |
| Lock | Yes |
| Front door key lock | Yes |
| Rear door key lock | No |
| Side panel key lock | Yes |
| Removable front door | Yes |
| Removable rear door | No |
