BCS Point Dome Network IP Camera BCS-P-DIP24FSR3-AI2-G 4MP IR 30m
Photo gallery
-
Manufacturer
-
Product Code
BCS-P-DIP24FSR3-AI2-G
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Dome
- Night visibility: up to 30m
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Color: Black
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 1,44 MB
-
Size: 3,73 MB
-
Size: 1,21 MB
Related products
Product Description
Main features:
|
|
The BCS-P-DIP24FSR3-Ai2-G camera is an advanced high resolution 4 Mpx surveillance device. It has a fixed lens with a focal length of 2.8mm and an aperture of F1.6, allowing a wide angle of view. It is equipped with intelligent functions such as perimeter protection, object recognition, face detection and people counting. The camera also offers advanced video compression, power supply via 12VDC or PoE, and is weatherproof with IP67 and IK10 ratings.
Technical specifications:
| Device Name | BCS-P-DIP24FSR3-Ai2-G |
| Product line | BCS Point |
| Camera type | Dome |
| Resolution | 4 Mpx |
| Sensor | 1/3'' |
| Scanning system | Progressive Scan |
| Pixels | 2688(H)×1520(V) |
| Lens | fixed |
| Focal length | 2.8 mm |
| Aperture | F1.6 |
| Focus | Fixed |
| Iris | Fixed |
| Digital zoom | 16× |
| Viewing angle | H: 101.1° V: 55.3° |
| DORI | Detect 63m / Observe 25m / Recognize 13m / Identify 6m |
| Sensitivity of the camera | 0.003Lux(F1.6,AGC) 0Lux(B/W,IR) |
| S/N ratio | 56dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Image rotation | Mirror, Flip 0°/90°/180°/270° |
| Number of streams | 3 |
| Resolutions | 4M(2688×1520)(2560×1440) / 3M(2304×1296) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / (640×360) / 2CIF(704×288) / CIF(352×288) |
| Main stream | 2688×1520/2560×1440/2304×1296/1920×1080/1280×720(30fps) |
| Second stream | 1280×720/720×576/640×360/704×288/352×288(30fps) |
| Third stream | 720×576/640×360/704×288/352×288(30fps) |
| Bitrate | 128Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR |
| Illuminator type | IR |
| Illuminator | 30m |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711 |
| Alarm input | 1 |
| Alarm output | 1 |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detection | 4 |
| Privacy masks | 4 |
| Networking | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
| Power supply type | 12VDC / PoE(802.3af) |
| Power consumption | max 4.5W |
| Housing color | Graphite |
| IP protection class | IP67 |
| IK10 | Yes |
| Operating conditions | -30°C~+60°C max 95% RH |
| Dimensions | Ø109×81mm |
| Weight | 0.42kg |
| Ai - Built-in intelligent functions | Yes |
| Ai - Perimeter protection | Yes |
| Ai - Object recognition | Yes |
| Ai - Face detection | Yes |
| Ai - People counting | Yes |
