Surveillance Kit 4x TVICAM-T5M-20DL 5Mpx, ICR, WDR, HiLook by Hikvision

Our kits are carefully selected devices that guarantee full compatibility and efficiency. You will find all the necessary components and accessories that will allow you to immediately start installing and configuring your equipment.

The kit includes:

• DVR-4CH-5MP ( 1pc ).
• TVICAM-T5M-20DL camera ( 4pcs ).
• Hard drive 1TB ( 1pc ).
• UTP cat.5e cable ( 20m )
• Sticker "Attention Monitored Object" ( 1pc )
• Power splitter ( 1pcs )
• DC connectors ( 4pcs ), signal converters ( 4pcs ).
• Bulk power supply for cameras ( 1pc ), LZ-1 power splitter ( 1pc ).

Main features:

• Complete monitor kit with 4 cameras TVICAM-T5M-20DL, DVR and all necessary accessories.
• High image quality 2560x1960p pixels (5Mpx)
• Viewing angle of the cameras: H: 85° V: 63° D: 110°
• Outdoor/indoor mountable camera
• Infrared light range - 20m
• Cameras meeting IP66 protection class
• Hardware digital WDR
• 1TB hard drive, dedicated for use in video surveillance systems
• Possibility of remote monitoring via web browser, PC application and mobile device application.
• P2P (cloud) support - a feature that allows remote access without port forwarding and public IP address

High-quality image The light-sensitive sensor and high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The TVICAM-B5M records at 5Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage. A: 1280x720p ( 1Mpx ) B: 1920x1080p ( 2Mpx ) C: 2048x1536p ( 3Mpx ) D: 2560x1440p ( 4Mpx ) E: 2560x1960p ( 5Mpx ) F: 3840x2160p ( 8Mpx )

DVR-4CH-5MP 4 channel DVR HiLook by Hikvision

• Human and vehicle target classification based on deep learning in motion detection 2.0
• H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 video compression
• HDTVI/AHD/CVI/CVBS/IP video inputs
• Audio via coaxial cable
• Capable of connecting up to 6 network cameras (up to 8 MP)
• Capable of encoding up to 8 MP @8 fps

Dome camera TVICAM-T5M-20DL

• High quality imaging with 5 Mpx, 2560 x 1944 resolution.
• 2.8mm fixed lens
• Infrared range up to 20 meters
• White light range - 20 meters
• Support for four analog TVI/AHD/CVI/CVBS systems
• IP66 water and dust resistance

Efficient storage

H.265+ encoding, also known as High Efficiency Video Coding (HEVC+), is an advanced video compression technology used in modern surveillance systems. It is an extension of the H.265/HEVC standard, providing even higher compression efficiency than its predecessors. The main features of H.265+ coding in surveillance DVRs are:

• Higher Compression Efficiency: H.265+ makes it possible to significantly reduce the size of video files while maintaining the same image quality. This saves disk space and increases the storage time of recordings.
• Energy Savings: More efficient compression reduces the CPU load, resulting in lower power consumption of surveillance equipment.

IP66 certified housing This housing protects the TVICAM-T5M-20DL from external factors such as dust, dirt and moisture, which is especially important in industrial environments or dusty locations. Cameras with IP66 housing can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage.

Remote access from phone and desktop computer Hikvision systems allow you to configure, control and view the TVICAM-T5M-20DL cameras using applications that will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to: Access video preview and play back the recorded footage Save portions of the video to your smartphone memory Configure time frames for motion detection Receive notifications from motion detection or other events Share your device with other smartphones with the mobile app, such as family members or employees

Wide Dynamic Range - That is, high quality in challenging conditions

The WDR (Wide Dynamic Range) function of the TVICAM-T5M-20DL is a technology that improves image quality in difficult lighting conditions, especially when there are simultaneously very bright and very dark areas in the field of view of the TVICAM-B5M. Key aspects of the WDR function are:

• Exposure balancing: WDR helps produce clear images in situations where there is strong backlighting or underexposure, such as when filming from inside a building overlooking a brightly lit exterior.
• Preservation of detail: With WDR, cameras can better capture details in the dark and bright parts of the image. This allows clear recognition of faces, vehicle license plate numbers and other important elements that might not be visible under standard conditions.
• Image processing technology: WDR achieves its effects by quickly switching between different exposure levels or by combining several images taken with different exposure settings to create a single, balanced image.
• Usefulness in security monitoring: This feature is particularly important in security monitoring systems, where it is important to get clear images in a wide variety of lighting conditions, both indoors and outdoors.





Automatic day/night mode Adapted to operate the TVICAM-T5M-20DL in all lighting conditions with visibility up to 20m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.

LED illumination and color image after dark

The white light illumination function of the TVICAM-T5M-20DL is used to improve image quality in low-light conditions. Here are some key aspects of this technology:

• Improving nighttime visibility: When natural light levels are low, white light illumination produces a colorful and clear image that is typically of better quality than images obtained using infrared (IR).
• Preventive effect: Bright light can act as a deterrent to potential intruders or criminals, as it signals that the area is being monitored and well lit.
