SATEL Perfecta 16 Alarm System, 8x Detector, LCD, SP-4001 R Siren, accessories
Photo gallery
-
Manufacturer
-
Product Code
ZA30183
-
Warranty
24 miesiące
- Number of sensors: 8
Ask about this product show form
Product Description
Main features of the set:
- Renowned manufacturer SATEL
- LCD keypad with illuminated keys
- Loud audible signaling plus super-bright LEDs
- Large, easy-to-read LCD display
- Built-in GSM/GPRS module with 2 SIM slots
- Emergency power supply from battery
- PERFECTA CONTROL mobile application
- Polish user manual
- Polish installation manual
- Easy installation and operation
Kit includes:
- PERFECTA 16 SET-A control panel
- Transformer 230V/18V AC for OPU-3 P enclosure, 40VA - TR40VA
- Gel battery 12V 7.2Ah
- LCD keypad for PRF-LCD control panel
- SP-4001 R optical and acoustic siren
- SATEL SLIM-PIR motion detector ( 8 pcs ).
Remote access from your phoneSATEL systems allow you to configure, control and view using the PERFECTA application, which will provide you with constant access to your alarm system from any place on earth with Internet access. SATEL allows you to:
|  |
NotificationPUSH notifications on alarm systems are sent directly to users' smartphones via the mobile app, reporting real-time events such as motion detection or door opening. SMS and email serve as alternative communication channels, allowing the alarm system to send alerts and detailed event reports directly to the user's cell phone or email address, even when the user does not have access to the mobile app. |  |
Home automation controlThe home automation control panel allows users to remotely manage various home systems, such as lighting, heating, and roller shutter systems, through a mobile app or web interface. This allows users to automate household tasks, as well as adjust settings based on user needs or detected events, offering not only increased security, but also comfort and energy efficiency. |  |
Built-in GSM/GPRS modemThe GSM module in the control panels ensures reliability of communication, allowing alerts and alarm messages to be sent directly to the end user or to the monitoring station, even in the event of failure of telephone lines or the Internet. It allows the alarm system to be remotely controlled and configured via a smartphone or computer, increasing convenience and accessibility for the user. In addition, thanks to data encryption, the GSM module provides a high level of security for transmitted information, minimizing the risk of interception by unauthorized persons. |  |
Possibility to configure two independent zones
In control panels, the ability to set up two zones allows independent management and control of different areas of a facility, making it possible, for example, to activate the alarm system only in a selected part of the building, while the rest remains unchanged. This allows users to flexibly adapt protection to individual needs and situations, for example, securing the office at night while the system remains disabled in the living area.
Schedule and time switchesThe scheduler in the control panels allows the security system to be automatically switched on and off at predetermined times, greatly enhancing user comfort and ensuring that protection is optimized without the need for manual intervention. As a result, users can rest assured about the safety of their property, even when they forget to activate the alarm system, which further contributes to saving energy and resources. In addition, the schedule also allows you to control home automation elements such as lighting, blinds, etc. |  |
Jamming detectionThe jamming detection function in alarm panels is used to identify attempts to interfere with radio signals, a key aspect of ensuring uninterrupted communication and protecting against advanced attacks. When such an interference attempt is detected, the system can automatically notify owners or a monitoring station of the potential threat, allowing for a quick response and increasing the overall reliability of the alarm system. |  |
The PERFECTA 16 control panel
complete with ANT-GSM-I antenna and OPU-4 P housing. The system based on the PERFECTA 16 control panel is characterized by quick installation, simple configuration and easy and intuitive operation. In addition to basic, traditional methods of system control, the control panel also offers more modern ones, such as the functional and intuitive PERFECTA CONTROL mobile device application.
Main features of the control panel:
- 8 to 16 programmable wired inputs
- ability to operate roller shutter and vibration detectors
- 4 to 12 programmable wired outputs
- 2 power outputs on the main board
- GSM/GPRS with 2 SIM slots (SMS, monitoring to station, mobile application, PUSH notifications)
- voice (playback of voice messages for telephone notification)
- acoustic alarm verification (listening for sounds)
- automatic diagnostics of basic system components
- built-in switching power supply:
- overload protection
- protection against complete battery discharge
- regulation of battery charging current
Transformer
230V/18V AC for OPU-3 P enclosure, 40VA - TR40VA
Main features of the transformer:
- Transformer in housing
- Output voltage 16/18 VAC
- Nominal output current 2.22A
- Power supply power of 40VA
- Degree of protection IP43
- Dimension (dia. x h.) (mm) 126.6x92.8
Gel battery 12V 7.2Ah
Maintenance-free battery, does not require water refilling and constant maintenance of electrolyte. This type of battery can also be used as a power source in portable devices.
Main features of the battery:
- Rated voltage 12V
- Rated capacity 7.2Ah
- Design life of 2 ÷ 3 years at 20°C
- Internal resistance 25 mΩ
- Charging voltage at 25°C
- Buffer operation 13.65 V ± 0.15 V
- Cyclic operation 14.70 V ± 0.30 V
- Charging current: Recommended 0.7 A, Maximum 2.1 A
- Max. discharge current (5s) 105 A
- Weight 2.05 kg
- Dimensions W=151, H=100, D=65 [mm, +/-2].
LCD keypad
for the PRF-LCD control panel. The PRF-LCD keypad is used for everyday operation of PERFECTA series control panels. The device meets the Grade 2 security requirements of EN 50131. Large keys, LCD display and LEDs indicating system status make system operation convenient and clear for all users.
Main features of the keypad:
- cooperation with PERFECTA series control panels
- large, easy to read LCD display
- LEDs indicating the status of partitions and the system
- quick activation of a selected arming mode by means of function keys
- Panic, FIRE, AID alarms called from keypad
- backlighting of the display and keys
- audible signaling of selected events in the system
- signaling loss of communication with the control panel
SP-4001 R
is an optical-acoustic signaling device for outdoor installation, equipped with super-bright LEDs and a piezoelectric transducer
Main features of the signaling device:
- acoustic signaling: piezoelectric transducer
- optical: super bright LEDs
- tamper protection: against opening, detachment from the ground
- internal cover made of galvanized sheet metal
- housing made of high-impact polycarbonate
- selectable alarm signal - 3 acoustic signals
- electronics protected against weather conditions
- dimensions: 148x254x64mm (W/H/D)
- available colors: red,blue or orange
- warranty: 24 months
SATEL SLIM-PIR motion detector.
The SLIM-PIR detector detects motion in the protected area. The device can be mounted on an adjustable BRACKET D ceiling/wall mount (to be purchased separately).
Main features of the detector:
- compliance with the requirements of EN 50131 for Grade 2
- motion detection using a passive infrared (PIR) sensor
- adjustable detection sensitivity
- digital motion detection algorithm
- digital temperature compensation
- wide-angle lens designed specifically for SLIM LINE series detectors
- possibility to replace the lens with curtain lens (CT-CL2) or long range lens (LR-CL2)
- built-in parametric resistors (2EOL: 2 x 1.1 kΩ)
- LED indicator for signaling
- choice of LED indicator light color (4 colors available)
- remote on/off switching of the LED indicator
- supervision of motion detection system and supply voltage
- tamper protection against opening the housing
Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt
Odpowiedzialność za produkt
SATEL sp. z o.o.
ul. Budowlanych 66
80-298 Gdańsk
satel@satel.pl
