IP Tube Camera 8Mpx BCS-L-TIP58FCR3L3-Ai1-G(3), NightColor, ADC, WDR 120dB
- Technology: IP
- Resolution: 8Mpx
- Enclosure: Tube
- Night visibility: up to 30m
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
Ask about this product show form
Do you represent a budgetary unit?
Check out the deferred payment option.
Product Description
Here are the main features of the BCS-L-TIP58FCR3L3-Ai1-G(3) camera:
General features:
- Product line: BCS Line
- Camera type: Tube
- Resolution: 8 Mpx (3840 × 2160)
- Sensor: 1/2.7'' CMOS
- Scanning system: Progressive Scan
- RAM: 256 MB
- ROM: 2 GB
Lens:
- Focal length: 2.8 mm (fixed)
- Aperture: F1.0
- Focus: Fixed
- Iris: Fixed
- Digital zoom: 16×
Viewing angle:
- H: 106°
- V: 55°
- D: 125°
DORID:
- Detection range: 91 m
- Observation: 36 m
- Recognition: 18 m
- Identification: 9 m
Camera sensitivity:
- Color: 0.004 Lux (F1.0, 30IRE)
- B/W: 0.0004 Lux (F1.0, 30IRE), 0 Lux (IR)
Image technology:
- WDR: 120 dB
- Background compensation: BLC / HLC / WDR (120 dB) / SSA
- Shutter: Auto / manual (1/3 ~ 1/100000s)
- Gain control (AGC): Auto / manual
- Noise Reduction: 3D DNR
- Lens Distortion Correction (LDC): Yes
Image Rotation:
- Functions: Mirror, Flip 0°/90°/180°/270°
Resolutions and Streams:
- Main stream: 3840 × 2160 (1~25/30fps)
- Second stream: 704 × 576 (
125fps) / 704 × 480 (130fps) - Third stream: 1920 × 1080 (1~25/30fps)
Bitrate:
- H.264: 3 kbps ~ 16384 kbps
- H.265: 3 kbps ~ 16384 kbps
Video compression:
- Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG / Ai Coding
Day/Night:
- ICR: Mechanical infrared filter
- Illuminator type: IR LED + White Light
- Illuminator range: 30 m
- NightColor: Yes
Audio:
- Microphone: Yes
- Speaker: Yes
- ADC active deterrence function: Optical and audible alarm
Inputs/Outputs:
- Audio input: 1
- Audio output: 1
- Alarm input: 1
- Alarm output: 1
Storage:
- Storage: FTP, SFTP, NAS
- Memory card slot: microSD 512 GB
Network and power:
- Network: RJ-45 10/100 Mbps
- Compatibility: ONVIF (S/G/T)
- Network Protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP, P2P
- Power supply: 12V DC / PoE (802.3af)
- Power consumption: max 9.4 W
Housing and protection:
- Housing color: Graphite
- Protection class: IP67
- Operating conditions: -40°C ~ +60°C, max 95% RH
- Dimensions: 288.4 × 94.4 × 84.7 mm
- Weight: 1 kg
AI functions:
- Built-in intelligent functions: Image recognition and analysis algorithms
- Perimeter protection: Area intrusion, line crossing
- Object recognition: Person/vehicle recognition
- SMDS: SMD 4.0
