32-channel IP Recorder AcuPick BCS-L-NVR3208XR-A-8KR-Ai BCS Line
Photo gallery
-
Manufacturer
-
Product Code
BCS-L-NVR3208XR-A-8KR-Ai
-
Warranty
36 miesięcy
- Technology: IP
- Number of channels: 32
- Built-in POE switch: No
Ask about this product show form
Product Description
The main features of the BCS-L-NVR3208XR-A-8KR-Ai DVR are:
- Product line: BCS Line
- System: IP with industrial-grade processor, Linux operating system
- Pentaplex function: live viewing, recording, playback, archiving, remote access
- Channels: 32
- Disk support: 8 disks, maximum capacity of 16 TB per disk, RAID 0/1/5/6/10 support with Hot Swap function
- Recording modes: Continuous, manual, alarm, motion detection, schedule, Ai
- Max. recording resolution: 32 Mpx
- Input bandwidth: 1024 Mbps (512 Mbps for Ai)
- Output bandwidth: 800 Mbps (400 Mbps for Ai)
- Recording bandwidth: 1024 Mbps (512 Mbps for Ai)
- Display performance: Supports up to 2×32M (30 fps), 128×D1 (30 fps)
- Recording resolutions: 32M / 24M / 16M / 12M / 8M / 5M / 4M / 2M / 1.3M / 720P / D1
- Video compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG / MPEG4
- HDMI outputs: 1×8K, 2×4K
- VGA outputs: 2×VGA
- HDMI display resolutions: Up to 7680×4320 (HDMI3)
- VGA display resolutions: Up to 1920×1080
- Screen splitting: 1/4/8/9/16/25/36
- Playback: 1/4/9/16 channels simultaneously
- Archiving: USB Flash, USB HDD
- User Support: Up to 128 users
- Interfaces: 2×USB 2.0, 2×USB 3.0, eSATA
- Alarm inputs/outputs: 16 inputs, 8 outputs
- Audio inputs/outputs: 1 input, 2 outputs
- Audio compression: G.711A / G.711U / G.726 / PCM
- Network: 2×RJ-45 10/100/1000/2500 Mbps
- Protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, P2P
- PTZ support: intelligent 3D positioning with BCS Line series PTZ cameras
- Power supply: 2× 100~240V AC, power consumption max 18W (without disks)
- Operating conditions: -10°C to +55°C, max 93% RH
- Enclosure: 2U
- Dimensions: 444×476×95 mm
- Weight: 8.1 kg (without disks)
AI functions:
- Face detection: 4 channels from DVR, 32 from cameras
- Face identification: 20 channels from cameras, 4 from DVR
- Perimeter protection: 24 channels from DVR, 32 from cameras
- Metadata: Person and vehicle recognition, attributes (clothing color, vehicle type, etc.).
- SMD (Smart Motion Detection): 32 channels from DVR, 32 from cameras
- Additional functions: People counting, crowd detection, ARTR (Automated Traffic Recognition), vehicle traffic volume, object monitoring
