KEEYO LV-V-IP8M25TF-E 8Mpx IR25m IP Bullet Camera

Bitvision is a simple and fast way to operate your property monitoring system, with it you will be able to:

✅Access video previews and playback stored footage
✅Save video snippets to your smartphone's memory
✅Configure time frames for motion detection
✅Receive notifications from motion detection or other events
✅Share your devices with other smartphones with the mobile app, such as family members or employees

Power Over Ethernet (PoE)

The LV-V-IP8M25TF-E 's Power over Ethernet (PoE) function is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of monitoring systems.

Support for popular browsers

The WEB server in KEEYO cameras is supported by popular browsers like Google Chrome, Mozilla Firefox or even Safari.

Accurate notifications without false alarms

The LV-V-IP8M25TF-E's human and car silhouette detection feature offers significant advantages, such as increased efficiency and accuracy in monitoring. It allows automatic recognition and tracking of specific objects, which minimizes false alarms and facilitates rapid response to real threats or suspicious events, improving the overall security and performance of surveillance systems.

Built-in microphone

The LV-V-IP8M25TF-E's built-in microphone enables audio recording, which greatly enhances surveillance and situation analysis capabilities. With the audio recording function, you can better understand the context of events, identify voices, detect disturbing sounds, and monitor spaces for not only visual, but also acoustical, supporting a more comprehensive approach to security and real-time intervention.

High-quality image

The latest technologies used in the camera's sensor and sensor, combined with advanced optics, deliver high quality images with excellent sharpness compared to lower resolution cameras. The device records at 8Mpx resolution ensuring that even the smallest detail is captured in the footage.

Automatic Day/Night mode

Adapted to work in all lighting conditions with visibility up to 25m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.

Wide Dynamic Range: DWDR

The use of extended dynamic range DWDR takes care of the quality of recordings by detecting and making lighting corrections in areas of overexposure and lack of light. Thanks to this solution, the device is able to capture details of contrasting images.

Resistant to weather conditions

The IP67 waterproof rating means that the camera can be placed anywhere. Even during the harshest atmospheric conditions, the device guarantees trouble-free operation thanks to the high-quality materials of the device's housing.

Technical specifications:

Model	LV-V-IP8M25TF-E
Camera
Image sensor	1/2.7" Progressive Scan CMOS
Resolution	8MP
Effective pixels	3840(H)x2160(V)
Compression	H.264/H.265/JPEG/AVI/MPEG
Video Format	PAL/NTSC
Electronic shutter speed	1/3-1/10000th of a second
Minimum illumination	Color: 0.02 Lux (F2.0, AGC ON), B/W: 0 Lux with IR
S/N ratio	60dB
Lens
Focal length & FOV	Horizontal FOV 45°, vertical FOV 45°, angular FOV 110°
Lens type	Fixed focal length lens 2.8mm
Focus control	Fixed
Aperture	F2.0
Pixels	8MP
Night visibility
Assistance light	42x IR LED
Range of booster light	25m
Power supply of booster light	Auto Control, Smart, Manual & Timed Mode
Network
Ethernet	RJ-45 (10/100 Base-T)
Protocol	TCP/IP, IPv4, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, SMTP, UDP, QoS, 802.1x
ONVIF	Supports ONVIF 19.12 (Profile S/T)
P2P	Yes
PoE	Yes, 802.3af
Video	H.264
Main streams	Main stream 1: 3840x2160@20fps Main stream 2: 2880x1620@30fps Main stream 3: 1920x1080@30fps Secondary stream: 352x288@30fps
Browser	IE8-11, Google Chrome, Firefox , Mac Safari
Bitvision mobile app	iPhone, Android
AI features
Intelligent analysis	Intruder detection (based on human detection), motion detection based on human detection
Camera functions
Day/Night	Color / B/W (IR-CUT)
Image configuration	Saturation / Brightness / Contrast / Sharpness / Mirroring / 3D NR / White balance / Anti-flicker / HLC / Distortion
FullColor	Yes
BLC	Yes
WDR	DWDR
Motion detection	People and vehicle detection
Privacy masking	3 rectangular zones
Recording mode	NVR/CMS/Web
Language	Simplified Chinese, Traditional Chinese, English, Russian, Korean, Polish, French, Japanese, Spanish, Portuguese, Italian, Hebrew, Ukrainian, Arabic, Vietnamese, Thai, Hungarian
Interface
Audio	Built-in microphone
General
Housing	Front: Metal, Rear: Plastic, IP67
IR filter	Yes
Working temperature	-20°C ~ +60°C, RH 95% Max
Storage temperature	-20°C ~ +60°C, RH 95% Max
Power source	DC12V±10%, 700mA
Dimensions	176.64(W) × 57(H) × 69.81(D) mm
Weight	600g
