CONOTECH black gel-filled twisted pair cable cat.6 305m

The image shows a Conotech U/UTP Cat. 6 GEL LAN cable packaged in a white and red box with a handle for easy carrying. The box highlights features such as 100% copper construction and 305 meters (1000 feet) of cable length.
The image shows a Conotech U/UTP category 6 GEL cable with twisted pairs of colored wires exposed at one end. The cable is designed for high-speed data transmission and features a durable black outer sheath.

  • Manufacturer

    Conotech

  • Product Code

    NS-711

  • Warranty

    24 miesiące

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: in stock Shipping 24h

Price (Incl. VAT):

176,76 €

Add to Watchlist

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

The high-performance U/UTP cat.6 GEL + PE network cable is an unshielded twisted pair cable consisting of four asymmetrically twisted pairs of wires made of pure copper. Each pair is separated by a cross separator, which minimizes interference between the wires. Homogeneous high-density HDPE polyethylene with excellent dielectric properties is used for their insulation, and the cable is additionally protected by a gel that protects it from longitudinal water ingress.
  • Type: U/UTP, cat.6 GEL+UV made of pure copper
  • Inner conductor: CU, four pairs asymmetrically twisted Ø 0.57 ± 0.02 mm, wire - 23 AWG
  • Conductor insulation: HDPE polyethylene (PE) + hydrophobic gel
  • Cross separator: polyethylene (PE)
  • Outer sheath: polyethylene PE, black color
  • Outer diameter: Ø 6.3 ± 0.02 mm
  • Operating temperature: -20 C ÷ +70 C
  • Laying temperature: 0 C ÷ +70 C
  • Minimum bending radius [x cable diameter]: >8
  • Application: outdoor, underground
  • Compliance with standards:
  • ISO/IEC 11801:2010, EN 50173-1:2011, IEC 61156-5:2002 and TIA/EIA 568-B.2:2001
  • Product symbol: NS-711
  • Brand name: CONOTECH
The outer sheath of black PE polyethylene with a diameter of Ø 6.30 ± 0.02 mm effectively protects the cable from mechanical damage and weathering. The 305m cable is packaged in a convenient Easy Pull Box for easy unwinding, and features a meter marker for precise wear control.
The product meets EU directives and European quality standards, as certified by the Communications Institute in Warsaw.

Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt

Odpowiedzialność za produkt

Importer: Novisat Sp. z o.o.

Właściciel marki: CONOTECH

UL. Zaporoska 37B

53-519 Wrocław

Kraj: Polska

Tel: + 48 717990934

Adres e-mil: novisat@novisat.pl
