IP Bullet Camera 4Mpx BCS-V-TIP54FCR6L6-Ai2(2), NightColor, AcuSense
Photo gallery
Product Description
Here are the main features of the BCS-V-TIP54FCR6L6-Ai2(2) camera:
- Product line: BCS View
- Camera type: Tube
- Resolution: 4 Mpx (2688×1520)
- Sensor: 1/1.8'' CMOS
- Scanning system: Progressive Scan
- Lens: Fixed, focal length 2.8 mm, aperture F1.0
- Viewing angle:
- H: 104°
- V: 54.4°
- D: 126.7°
- DORI range:
- Detection: 61 m
- Observation: 24 m
- Reconnaissance: 12 m
- Identification: 6 m
- Camera sensitivity: 0.0005Lux (F1.0, AGC), 0Lux (B/W, IR)
- S/N ratio: 52 dB
- White balance: Auto / manual
- WDR: 130 dB
- Background compensation: BLC / HLC / WDR (130 dB)
- Shutter: Auto/manual 1/3~1/100000 s
- Gain Control (AGC): Auto / manual
- Noise Reduction: 3D DNR
- RoI (Region of Interest): Yes
- Image rotation: Mirror horizontal/vertical, 180° rotation
- Number of streams: 3
- Resolutions:
- Main: 2688×1520@30fps, 1920×1080@30fps, 1280×720@30fps
- Second stream: 1280×720@30fps, 640×480@30fps, 640×360@30fps
- Third stream: 1920×1080@10fps, 1280×720@10fps, 640×480@10fps, 640×360@10fps
- Bitrate: 32 Kbps ~ 8 Mbps
- Video compression: H.265, H.265+, H.264, H.264+, MJPEG
- Day/night mode: ICR (mechanical infrared filter)
- IR illuminator + White Light: Range up to 60m
- Storage: FTP, NAS, microSD slot up to 512 GB
- Support: Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App (iOS, Android)
- Motion detection: yes
- Privacy masks: 4
- Network: RJ-45 10/100 Mbps
- Compatibility: ONVIF (S/G/T)
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, SRTP, SFTP
- Power supply: 12V DC / PoE (802.3af)
- Power consumption: Max 9 W
- Housing color: White
- Protection class: IP67
- Operating conditions: -30°C ~ +60°C, max 95% RH
- Dimensions: 286.7×93.3×91.2 mm
- Weight: 1 kg
- Ai - Built-in smart functions:
- Perimeter protection: Intrusion into the area, crossing the line
- Object recognition: Person/mechanical vehicle (false alarm reduction)
- Face detection: Face detection and tracking, face photo
