Monitoring set 4x BCS-L-TIP15FCR3L3-AI1 5Mpx, 2.8 mm, 0.007Lux BCS
Photo gallery
-
Manufacturer
-
Product Code
ZM35474
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 5Mpx
- Enclosure: Tube
- Night visibility: up to 30m
- Number of cameras: 4
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Color: White
Ask about this product show form
Related products
Product Description
Product contents:
In addition to the camera, the box also contains useful instructions and mounting accessories to speed up the entire process of mounting the camera.
BCS products are devices that focus on ease of use, literally anyone can handle their installation and configuration thanks to the instructions included in the kit.
In addition to the camera, the box also contains useful instructions and mounting accessories to speed up the entire process of mounting the camera.
- 4x BCS-L-TIP15FCR3L3-AI1
- 1x BCS-L-NVR0401-4KE(2) DVR.
- 1x Toshiba S300 2TB hard drive from Surveillance series, dedicated to CCTV solutions
- 1x Switch BCS-B-SP0402
- 20m of cat.5e UTP cable
- A set of necessary accessories, needed to run the system
- "ATTENTION MONITORED OBJECT" sticker
BCS products are devices that focus on ease of use, literally anyone can handle their installation and configuration thanks to the instructions included in the kit.
Features of the set:
- 5 Mpx camera with 2960×1688 resolution provides detailed images.
- Wide viewing angle (H: 111° / V: 58° / D: 132°) enables effective surveillance of vast areas.
- Infrared and white light range of up to 30m - monitoring in any lighting conditions.
- Built-in microphone - audio recording without the need for additional equipment.
- IP67-rated housing - weatherproof.
- Advanced AI analysis - recognition of silhouettes, people and vehicles.
- WDR 120 dB support - better images in high light contrast conditions.
- BCS-L-NVR0401-4KE(2) 4-channel DVR - support up to 4 high-definition IP cameras.
- Compatibility with mobile and computer applications - remote viewing and operation.
- P2P (cloud) support - fast remote access without port forwarding.
- H.265+ compression - save disk space while maintaining high image quality.
- HDMI and VGA outputs - possibility to connect a local monitor.
- Powering cameras via PoE - simpler installation and less cabling.
- Complete mounting kit in a box - quick and easy installation.
- Compatibility with third-party systems - ONVIF, CMS applications and network protocols.
Features of BCS-L-TIP15FCR3L3-AI1 camera:
- High image quality 2960(H)×1688(V) (5Mpx)
- Viewing angle of cameras: H: 111° V: 58° D: 132°
- Outdoor/indoor mountable camera
- Intelligent image analysis with silhouette recognition
- Infrared light range - 30m
- Cameras meeting IP67 waterproof rating
- Audio recording with built-in microphone
- Cameras with loudspeaker enabling two-way communication
- Hardware WDR 120dB
- Possibility of remote monitoring via web browser, PC application and mobile device application.
- P2P (cloud) support - a feature that allows remote access without port forwarding and public IP address
BCS-L-NVR0401-4KE(2) 4 channel DVR:
- Recording resolution: 16Mpx
- Video compression: H.265+
- Video outputs 1x HDMI, 1x VGA
- Simultaneous video playback from 4 cameras
- Possibility of remote monitoring via web browser, PC application and mobile device application.
- Disk support: 1x HDD (Maximum 16TB)
- 12VDC power supply
Toshiba S300 2TB drive:
- 2TB capacity - dedicated to video surveillance systems.
- Supports up to 64 cameras and 8 drives - ideal for CCTV recorders.
- Rotational speed of 5400 rpm and 128MB buffer - ensures stable operation with continuous data recording.
- Maximum data transfer rate: 184 MB/s - efficient handling of multiple video streams.
- MTTF: 1,000,000 hours, 180 TB/year load - high reliability and durability for 24/7 operation.
- Shock sensor and RoHS compliance - ruggedness and safe operation in harsh environments.
- SMR (Shingled Magnetic Recording) technology - optimized for long-term recording.
High-quality image
The light-sensitive sensor and high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The device records at 5Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
The light-sensitive sensor and high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The device records at 5Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
- A: 1280x720p ( 1Mpx )
- B: 1920x1080p ( 2Mpx )
- C: 2048x1536p ( 3Mpx )
- D: 2560x1440p ( 4Mpx )
- E: 2960×1688p 5Mpx )
- F: 3840x2160p ( 8Mpx )
P2P function
In surveillance cameras is a technology that allows direct communication between the camera and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:
In surveillance cameras is a technology that allows direct communication between the camera and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:
- Direct Connection: P2P allows a direct connection between the camera and the user's device. This means that video data can be transmitted directly, without having to go through an intermediary server.
- Ease of Setup: One of the main advantages of P2P is the ease of setup. Users often only need to scan a QR code or enter a camera ID to establish a connection.
- Remote Access: The user can access the camera's video from anywhere in the world, provided both the camera and the end device have Internet access.
Live Streaming (RTMP)
RTMP, or Real-Time Messaging Protocol, is a protocol used to transmit audio, video and other data in real time over the Internet. In the context of surveillance cameras, RTMP is mainly used to stream live video from a camera to a server or platform, which can be local or remote.
RTMP is particularly useful for applications that require live streaming to the Internet, such as streaming services or social media. Its use in surveillance cameras allows wide access to camera images, both for individual users and professional monitoring teams.
RTMP, or Real-Time Messaging Protocol, is a protocol used to transmit audio, video and other data in real time over the Internet. In the context of surveillance cameras, RTMP is mainly used to stream live video from a camera to a server or platform, which can be local or remote.
RTMP is particularly useful for applications that require live streaming to the Internet, such as streaming services or social media. Its use in surveillance cameras allows wide access to camera images, both for individual users and professional monitoring teams.
Certified IP67 housing
Such a housing protects the camera from external factors such as dust, dirt or moisture, which is especially important in industrial or dusty environments. Cameras with IP67 housing can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage.
Such a housing protects the camera from external factors such as dust, dirt or moisture, which is especially important in industrial or dusty environments. Cameras with IP67 housing can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage.
Remote access from phone and desktop computer
BCS systems allow you to configure, control and view via apps that will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to:
BCS systems allow you to configure, control and view via apps that will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to:
- Access video preview and play back recorded footage
- Save parts of the video to your smartphone's memory
- Configure time frames for motion detection
- Receive notifications from motion detection or other events
- Share your device with other smartphones with the mobile app, such as family members or employees
Wide dynamic range - That is, high quality in challenging conditions
WDR (Wide Dynamic Range), or Wide Dynamic Range, in surveillance cameras is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the WDR function are:
WDR (Wide Dynamic Range), or Wide Dynamic Range, in surveillance cameras is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the WDR function are:
- Exposure balancing: WDR helps produce clear images in situations where there is strong backlighting or underexposure, such as when filming from inside a building overlooking a brightly lit exterior.
- Preservation of detail: With WDR, cameras can better capture details in the dark and bright parts of the image. This allows for clear recognition of faces, vehicle license plates and other important elements that might not be visible under standard conditions.
- Image processing technology: WDR achieves its effects by quickly switching between different exposure levels or by combining several images taken with different exposure settings to create a single, balanced image.
- Usefulness in security monitoring: This feature is particularly important in security monitoring systems, where it is important to get clear images in a wide variety of lighting conditions, both indoors and outdoors.
People and vehicle detection
Motion detection with silhouette recognition of people and vehicles in surveillance cameras is an advanced feature that allows monitoring systems to be more precise and effective. It allows the camera to classify notifications according to the type of silhouette detected. At the same time providing more detailed information, but also completely filtering out irrelevant ones such as: Moving trees and bushes.
Motion detection with silhouette recognition of people and vehicles in surveillance cameras is an advanced feature that allows monitoring systems to be more precise and effective. It allows the camera to classify notifications according to the type of silhouette detected. At the same time providing more detailed information, but also completely filtering out irrelevant ones such as: Moving trees and bushes.
Power Over Ethernet (PoE)
The Power over Ethernet (PoE) function of surveillance cameras is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of surveillance systems.
The Power over Ethernet (PoE) function of surveillance cameras is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of surveillance systems.
Video and audio recording
The audio recording feature of surveillance cameras allows audio to be recorded along with video, greatly enhancing the capabilities and efficiency of surveillance systems. The main advantages of such a solution are:
The audio recording feature of surveillance cameras allows audio to be recorded along with video, greatly enhancing the capabilities and efficiency of surveillance systems. The main advantages of such a solution are:
- Comprehensive surveillance: Audio recording enables the collection of more detailed information about the monitored environment, which can be helpful in analyzing events or identifying people.
- Situation analysis: Audio can provide additional information that is not visible on video, such as conversations, background noises, or other sounds, which can be important for understanding the context of an event.
- Increased monitoring effectiveness: Integrating audio into a visual surveillance system increases the overall effectiveness of the system, enabling faster and more accurate responses to incidents.
Automatic day/night mode
Adapted to work in all lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.
Adapted to work in all lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.
D.O.R.I.
The DORI (Detection, Observation, Recognition, Identification) parameter is used to determine the ability of video systems, such as surveillance cameras, to detect, observe, recognize and identify objects or people at specific distances. The values given for each of these four elements determine the effective range at which the system can perform each of these activities:
The DORI (Detection, Observation, Recognition, Identification) parameter is used to determine the ability of video systems, such as surveillance cameras, to detect, observe, recognize and identify objects or people at specific distances. The values given for each of these four elements determine the effective range at which the system can perform each of these activities:
- Detection (64m): The system is able to detect the presence of an object or person at a distance of up to 64 meters. This means that at this distance you can tell that something is within the camera's range of view, but you can't necessarily determine what it is.
- Observation (25m): At distances of up to 25 meters, the system can not only detect an object, but also provide enough detail for the observer to get an idea of the general shape and perhaps some of the characteristics of the object, but without exact recognition.
- Recognition (13m): Recognition at a distance of up to 13m enables the system to provide enough detail for the observer to determine the type of object, for example, to distinguish whether it is a person, car or other object.
- Identification (6m): At a distance of up to 6 meters, the system is able to provide a highly detailed image to identify specific features of an object or person, such as a face, vehicle license plate, etc., enabling accurate identification.
Technical Specifications:
| Technical Specification - BCS-L-TIP15FCR3L3-Ai1 | |
|---|---|
| Device Name | BCS-L-TIP15FCR3L3-Ai1 |
| Product line | BCS LINE |
| Camera type | Tube |
| Resolution | 5 Mpx (2960×1688) |
| Sensor | 1/2.7'' CMOS |
| Scanning system | Progressive Scan |
| RAM / ROM | 256MB / 128MB |
| Focal length | 2.8mm, F1.6 (fixed lens) |
| Viewing angle | H: 111°, V: 58°, D: 132° |
| DORI | 64m (Detection) / 25m (Observation) / 13m (Recognition) / 6m (Identification) |
| Sensitivity | 0.007Lux (color), 0.0007Lux (B/W), 0Lux (IR) |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR |
| Shutter | Auto / manual 1/3~1/100000s |
| Noise reduction | 3D DNR |
| Image rotation | Mirror, Flip 0°/90°/180°/270° |
| Number of streams | 2 |
| Resolutions | 5M, 4M, 3M, 2M, 720P, D1, CIF |
| Bitrate | H.264: 32-8192 Kbps, H.265: 12-8192 Kbps |
| Video compression | H.265+/H.265/H.264+/H.264/MJPEG |
| Day/Night | ICR mechanical filter |
| Illuminator | IR LED + WhiteLight, range 30m |
| NightColor | Yes |
| Microphone | Yes |
| Audio compression | G.711A, G.711Mu, G.726, PCM |
| Storage | FTP, SFTP, NAS |
| MicroSD card slot | Up to 256 GB |
| Management | Web, CMS, App (iOS, Android) |
| Motion detection / Privacy masks | 4 / 4 |
| Networking | RJ-45 10/100 Mbps |
| Compatibility / Protocols | ONVIF(S/G/T), IPv4/IPv6, TCP/IP, etc. |
| Power supply | 12VDC or PoE (802.3af) |
| Power consumption | Max. 5.5W |
| Housing | White, IP67 |
| Operating conditions | -40°C to +60°C, up to 95% RH |
| Dimensions / Weight | 166.2×70×70 mm / 0.48 kg |
| AI - Perimeter protection | Intrusion, line crossing |
| AI - Object recognition | Person/vehicle recognition, false alarm reduction |
| AI - SMD | SMD 4.0 intelligent motion detection |
Technical Specifications:
| Device Name | BCS-L-NVR0401-4KE(2) |
| Product Line | BCS Line |
| System | IP |
| Pentaplex function | Live viewing / recording / playback / archiving / remote access |
| Channels | 4 |
| Drives | 1 (not included) |
| Disk capacity | 16 TB |
| Max recording resolution | 16 Mpx |
| Input bandwidth | 80Mbps |
| Output bandwidth | 80Mbps |
| Display capacity | 2×16M(30fps) / 2×12M(30fps) / 4×8M(30fps) / 1×16M Ai(30fps) / 2×12M Ai(30fps) / 3×8M Ai(30fps) / 4×5M Ai(30fps) |
| Recording resolution | 16M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / 1.3M / 720P / D1 / CIF |
| Video compression | H.265+ / H265 / H.264+ / H.264 / MJPEG |
| Video outputs | HDMI4K/VGA |
| HDMI display resolution | 3840×2160 / 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolution | 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| Output split | 1/4 |
| Playback | 1/4 |
| Archiving | Possibility of ripping material to external media such as USB FLASH, USB HDD |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711A / G.711U / G.726 / PCM |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Networking | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T), support for third-party cameras |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search, P2P, auto register |
| Power supply | 12V DC |
| Power consumption (without drives) | max 10W |
| Operating conditions | -10°C~+55°C max 93% RH |
| Enclosure | 1U |
| Dimensions (W×D×H) | 260×232.5×50.3mm |
| Weight (without drives) | 0.86 kg |
| Ai - Intelligent functions from the DVR | Face detection, face identification, perimeter protection (person/vehicle recognition mechanical), SMD Plus |
| Ai - Intelligent functions from cameras | Face detection, face identification, perimetric protection (person/vehicle recognition mechanical), SMD Plus, people counting, ARTR, heat map |
| Ai - Perimetric protection | 2 channels from DVR, 10 rules per channel / 4 channels from cameras |
| Ai - Face detection | 1 channel from DVR (12 images/s) / 4 channels from cameras / face attributes (gender, age, glasses, expression face, mask, beard) |
| Ai - Face identification | 4 channels of detection from camera + identification from DVR (12 images/s) / 1 channel of detection from DVR + identification from DVR (12 images/s) / 8 channels of identification from cameras / up to 10 face databases, 20 thousand images, up to 2.5GB |
| Ai - SMD | 4 channels from DVR / 4 channels from cameras |
Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt
Odpowiedzialność za produkt
BCS Sp.z o.o.
ul. Modularna 11 (Hala IV)
02-238 Warszawa
info@bcs.pl
Similar products in this category
Quick online quote
Use our calculators for a quote. Fill in the form - Our consultants will prepare a dedicated offer
-
Quote form
Use our tool for a monitoring quote, provide basic information and receive the offer directly to your email
See
-
Quote form
Check how much the installation of an alarm costs, provide basic information and receive the offer directly to your email
See
-
Quote form
Quote an access control system in any facility. to specific zones and areas using any identification
See
-
Quote form
Get a quote for the costs of a double-leaf, sliding, garage gate for your building or property
See
Our recommendations
- City monitoring
- Home monitoring
- Estate monitoring
- Shop monitoring
- Pharmacy monitoring
- Parking monitoring
- Office monitoring
- School monitoring
- Warehouse monitoring
- Gas station monitoring
- Hard drive capacity calculator
- Lens focal length calculator
- Comprehensive expert support
- Efficient order processing
- Competitive prices, promotions, and discounts
- 17 years on the market
