IP Dome Camera 4Mpx BCS-L-EIP14FCR3L3-Ai1, SkyLight, IR 30m, WDR 120dB

Here are the main features of the BCS-L-EIP14FCR3L3-Ai1 camera:

General features:

• Product line: BCS Line
• Camera type: Dome
• Resolution: 4 Mpx (2688×1520)
• Sensor: 1/2.9'' CMOS
• Scanning system: Progressive Scan
• Pixels: 2688(H) × 1520(V)
• RAM: 128 MB
• ROM: 128 MB

Lens:

• Focal length: 2.8 mm (fixed)
• Aperture: F1.6
• Focus: Fixed
• Iris: Fixed
• Digital zoom: 16×

Viewing angle:

• H: 95°
• V: 52°
• D: 114°

DORID:

• Detection range: 64 m
• Observation: 25 m
• Recognition: 13 m
• Identification: 6 m

Camera sensitivity:

• Color: 0.006 Lux (F1.6, 30IRE)
• B/W (with IR): 0.0006 Lux (F1.6, 30IRE), 0 Lux (with IR)

Image technology:

• WDR: 120 dB
• Background compensation: BLC / HLC / WDR (120 dB)
• Shutter: Auto / manual (1/3 ~ 1/100000s)
• Gain Control (AGC): Auto / manual
• Noise Reduction: 3D DNR
• Image rotation: Mirror, Flip 0°/90°/180°/270°

Resolutions and streams:

• Main stream: 2688×1520 (120fps), 2560×1440 (125/30fps)
• Second stream: 704×576 (125fps), 704×480 (130fps)

Bitrate:

• H.264: 32 Kbps ~ 6144 Kbps
• H.265: 12 Kbps ~ 6144 Kbps

Video compression:

• Compression: H.265 / H.265+ / H.264 / H.264+ / MJPEG

Day/Night:

• ICR: Mechanical infrared filter
• Illuminator type: IR LED + White Light
• Illuminator range: 30 m
• NightColor: Yes

Audio:

• Microphone: Yes
• Audio compression: G.711A / G.711Mu / G.726 / PCM

Storage:

• Memory card slot: microSD (up to 256 GB)
• Storage: FTP, SFTP

Network and Power:

• Network: RJ-45 10/100 Mbps
• Compatibility: ONVIF (S/G/T)
• Network Protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Bonjour
• Power supply: 12V DC / PoE (802.3af)
• Power consumption: Max 5.2 W

Housing and protection:

• Housing color: White
• Protection class: IP67
• Operating conditions: -40°C ~ +55°C, max 95% RH
• Dimensions: Ø106 × 94 mm
• Weight: 0.39 kg

AI functions:

• Perimeter protection: Intrusion into the area, crossing the line
• Object recognition: Person/vehicle recognition, false alarm reduction
• SMD Plus: Intelligent Motion Detection (SMD Plus)

The camera offers advanced image analysis and perimeter detection using artificial intelligence, making it ideal for advanced surveillance systems.
