SATEL SLIM-PIR-LUNA-PET motion sensor resistant to pets with illumination function.
Photo gallery
-
Manufacturer
-
Product Code
SLIM-PIR-LUNA-PET BUS
-
Warranty
24 miesiące
-
Time for return
30 days
- Sensor type: Traffic
Ask about this product show form
Product Description
- compliance with the requirements of EN 50131 for Grade 2
- motion detection using a passive infrared sensor (PIR)
- adjustable detection sensitivity
- digital algorithm of motion detection
- digital temperature compensation
- wide-angle lens designed specifically for SLIM LINE series detectors
- resistance to movement of animals weighing up to 20 kilograms
- possibility to configure operating parameters of the detector by means of OPT-1 remote controller
- built-in parametric resistors (2EOL: 2 x 1.1 kΩ / 2 x 4.7 kΩ / 2 x 5.6 kΩ)
- lighting function implemented using white LEDs
- possibility of remote control of lighting or activation of lighting by motion
- LED indicator for signaling
- choice of LED indicator light color (7 colors available)
- remote on/off switching of LED indicator
- remote switching between two sensitivity levels of the PIR sensor
- remote activation/deactivation of the configuration mode
- supervision of motion detection system and power supply voltage
- tamper protection against opening the housing and detachment from the ground
Technical specifications:
- Power supply voltage (±15%) 12 V DC
- Detectable movement speed 0.3...3 m/s
- Operating temperature range -10°C...+55°C
- Recommended installation height 2.4 m
- Standby current consumption 13 mA
- Maximum current consumption 97 mA
- Weight 142 g
- Maximum humidity 93±3%
- Dimensions 62 x 137 x 42 mm
- Environmental class according to EN50130-5 II
- Alarm signaling time 2 s
- Comply with EN 50131-1, EN 50131-2-2, EN 50130-4, EN 50130-5 standards
- Parametric resistors 2 x 1.1 kΩ / 2 x 4.7 kΩ / 2 x 5.6 kΩ
- Start-up time 30 s
- Security level according to EN50131-2-2 Grade 2
- Detection area 12 m x 13 m, 90°
- Alarm outputs (NC relay, resistive load) 40 mA / 24 V DC
- Tamper outputs (NC relay, resistive load) 40 mA / 24 V DC
- Relay contact resistance (alarm output) 26 Ω
- Relay contact resistance (tamper output) 26 Ω
"Source: SATEL sp. z o.o., www.SATEL.pl".
