Access controller with Roger PR602LCD-DT-I reader

T&A terminal (indoor) PR602LCD-DT-I
The indoor PR602LCD-DT-I is a single-passage controller, used as part of the RACS 4 access control system which is designed for the most popular access control solutions. The controller is an essential component in the construction of an RACS system as a Time & Attendance terminal. It can be used in both standalone and network installations of up to 4000 users. The controllers are equipped with RS485 communication interface, which can be used both for their programming and communication in a network system.

The device is equipped with a keypad with four function keys, a 4-line LCD display, three programmable NO/NC input lines, two programmable transistor outputs and one relay output. The PR602LCD-DT controllers have a built-in dual-system reader for EM125kHz and 13.56MHz MIFARE proximity card standards. The said MIFARE reader can read the serial number (CSN) of MIFARE Ultralight/Classic/Plus/Desfire type cards.

Main features:

• built-in EM 125 kHz and 13.56 MHz MIFARE card reader
• possibility to connect an external reader (two-way passage control)
• compatibility with PRT (Roger) series, Wiegand 26..66 bit readers
• three programmable NO/NC input lines
• two programmable transistor outputs 1A
• relay output 1.5A/30V
• support for up to 4000 users in the system
• power supply: 12V DC
• communication via RS485
• color: dark gray
• built-in LCD display
• built-in keypad with four function keys
• extensive time registration functions (RCP Master)
• protection class: IP41
• average current consumption: 100 mA
• any communication bus topology
• 250 access groups
• 32,000 events in buffer
• 99 time schedules
• tamper protection (tamper)
• local anti-passback
• global anti-passback (CPR32-SE-BRD required in the system)
• possibility to connect I/O expander type XM-2
• integration with alarm system via I/O lines
• identification modes: Card or PIN, Card and PIN, Card only, PIN only
• read range: up to 15 cm
• door modes: normal, locked, unlocked and conditionally unlocked
• quick update of user privileges (about 5 seconds per controller in the system)
• system management via computer network WAN/LAN, or serial port COM/USB
• possibility to divide the system into subsystems
• concurrent configuration of subsystems (the number of subsystems does not increase the time to transfer settings)
• screw terminals

Technical specifications:

Supply voltage	Nominal 12VDC, acceptable 10-15VDC
Proximity cards	EM 125 kHz (UNIQUE) compatible with EM4100/4102 and 13.56MHz compatible with ISO14443A and MIFARE
Reading range	Up to 15cm for ISO type cards (depends on card type and quality)
Current consumption	100mA
Contact Tamper	Potential-free NC type contact, 24V/50mA
Inputs	Three (IN1 - IN3) two-state NO/NC input lines internally polarized to supply plus via 15kΩ resistor, switching threshold approx. 3.5V
Relay output	Relay output (REL1) with one isolated NO/NC contact, max load 30V/1.5A
Transistor outputs	Two transistor outputs (IO1, IO2) of open collector type, max. load 15VDC/1A
Distances	Between controller and communication interface (RS485): max. 1200m Between external reader and controller: max. 150m Between controller and I/O expanders: max. 150m
Environmental class	I
Operating temperature	5°C ~ 40°C
Humidity	10% - 95% (non-condensing)
Protection class	IP41
Dimensions (W/H/D)	110x170x42mm
Weight	410g
