Access controller PR411DR-BRD

The image shows a green electronic access control board with various components, including capacitors, connectors, and integrated circuits. The board is designed for managing and controlling access in security systems.

  • Manufacturer

    ROGER

  • Product Code

    PR411DR-BRD

  • Warranty

    36 miesięcy

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: in stock Shipping 2-3 days

Price (Incl. VAT):

117,52 €

Add to Watchlist

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

PR411DR-BRD access controller


The PR411DR series controllers are designed for the most popular access control solutions. They can be used in both standalone and networked installations of up to 1,000 users. All PR411SE series controllers are equipped with RS485 communication interface, which can be used both for their programming and for communication in a network system. Access control system based on PR411DR controllers can be managed locally via COM/USB serial ports or remotely via WAN/LAN computer network (UT-4 interface required).

Main features:

  • 12 VDC, 24 VDC, 18 VAC power supply
  • DIN rail mounting
  • 8 programmable input lines
  • 4 programmable output lines
  • 2 relay outputs 1.5 A/30 V and 5 A/ 30V or 230 VAC
  • manual programming (reader with keypad required)
  • remote programming from a computer
  • communication interface RS485, RACS Clock&Data, Wiegand 26..66bit
  • cooperation with RFT1000 readers
  • cooperation with long range readers
  • support for up to 1 thousand users
  • 33 million events in buffer in subsystem equipped with CPR32-NET
  • real time clock (CPR32 required)
  • user groups
  • access zones
  • Time schedules (CPR32 required)
  • Anti-passback local
  • Anti-passback global (CPR32 required)
  • bank lock
  • hotel functions
  • operation of turnstiles (tripods)
  • operation of barriers
  • integration with alarm systems
  • integration with closed-circuit television (CCTV-DVR)
