Ethernet converter + EPOE LR1002 Dahua

The image shows a white Ethernet over coaxial converter with two BNC connectors and Ethernet ports. The device is designed for extending network connections over long distances using existing coaxial cables.
The image shows a white coaxial to Ethernet adapter with a short cable, featuring a coaxial input on one end and an RJ45 connector on the other. A small tag with CE marking is attached to the cable, indicating compliance with European standards.
The image shows a close-up of a white Ethernet cable with a clear RJ45 connector. The connector displays eight gold-plated pins for reliable network connectivity.
The image illustrates various configurations for connecting network devices using LR1002 adapters and Ethernet cables. It shows different setups for transmitting data between switches and cameras through intermediary devices.
The image shows a packaged set of two passive video baluns designed for CCTV systems, featuring BNC connectors and RJ45 cables. The baluns are encased in a clear plastic cover, allowing visibility of the components and their connections.
  • Manufacturer

    Dahua
  • Product Code

    LR1002

  • Warranty

    36 miesięcy


Ask about this product show form

  • Availability: Sold out

Price (Incl. VAT):

14,22 €

Add to Watchlist

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

The LR1002 device works as a converter of RJ45 port to BNC port allowing data and ePoE power transmission via coaxial cable. Two devices are required to create a transmission path The LR1002 converter also works with extenders LR1002-1ET, LR1002-1EC.


Package includes: 2 pcs. Listed price per package
LAN ports:1 pcs. RJ45
Transmission ports:1 pcs. BNC
Transmissionspeed:10 / 100 Mbps Full Duplex
Transmissionrange:max. 1000 m @ 10 Mbps
max. 400 m @ 100 Mbps
The transmission range and power supply is strongly dependent on the cable used and the power required to power the receiver
Protections:Surge protection
Selected features:
  • Plug & Play
  • Auto MDI/MDI-X detection - automatically detects data transmission mode
  • Support for IP cameras and network devices
  • Easy installation - no IP and MAC address configuration required
  • Includes 2 pcs.
Power supply:ePoE
Weight:0.030 kg
Dimensions:
  • 56 x 27 x 21 mm
  • 7 cm (cable length)
Manufacturer / Brand:Dahua
