Switch poe XPOE-6-11-S2 5-PORT ATTE

The image shows a white, rectangular PoE switch with a durable, weather-resistant casing designed for outdoor use. It features multiple cable entry points at the bottom and a label on the side indicating technical specifications and certifications.

  • Manufacturer

    ATTE

  • Product Code

    XPOE-6-11-S2

  • Warranty

    24 miesiące

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: in stock Shipping 24/48h

Price (Incl. VAT):

83,62 €

Add to Watchlist

Najniższy koszt dostawy: 20,68 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

The XPOE-6-11-S2 switch is designed to power IP cameras operating under the IEEE 802.3af/at standard 5 ports support Power over Ethernet (PoE)
The LONG RANGE operation mode allows to extend the transmission range of power and data for LAN ports 1 ... LAN 4 up to 280m while limiting the network bandwidth for these ports to 10Mbps

LAN ports:
  • 1 x RJ45 10/100 Base-T - Uplink
  • 5 x RJ45 10/100 Base-T, PoE 802.3af/at / Passive PoE
Web / console management:No
LEDs:Power, LAN
Transmission speed:10 / 100 Mbps : 1 LAN Port + 5 LAN & PoE Ports.
Maximum output power:
  • 40 W @ Passive PoE - Ports 1 ... 4,
  • 70 W @ Passive PoE - Port 5,
  • 30 W @ PoE (802.3af/at) - Ports 1 ... 5
Maximum total power:50 W
Operating modes:
  • Standard: 100 m @ 10/100 Mbps - Ports 1 ... 6
  • Long Range : 280 m @ 10 Mbps - Ports 1 ... 4 ; 100 m @ 10/100 Mbps - Ports 5, 6
Selected features:
  • Ability to independently enable and disable PoE power for each LAN port 1 ... LAN 5
  • Wide input voltage range
  • Up to 70W power on LAN_5 PoE IN/OUT port
  • Powered via screw connector (Vin) or from another PoE PASSIVE switch (PoE IN/OUT port)
  • Cascadable power supply - one switch powers another - PoE IN/OUT port
  • Output voltage for PoE devices Vout =Vin
  • Protection class: IP56
  • Cable glands are placed on the housing : 6 x M16
Power supply:10 ... 56 V DC
Operating temperature:-25 °C ... 50 °C
Weight:0.34 kg
Dimensions:158 x 118 x 77 mm
Manufacturer / Brand:ATTE
