POE Switch with IPUPS-8-20-H Buffer Power Supply 8-port ATTE

The image shows an open metal enclosure containing a PoE switch with buffer power supply, featuring multiple circuit boards and wiring. The setup is designed for network connectivity and power management, suitable for security and communication systems.

  • Manufacturer

    ATTE

  • Product Code

    IPUPS-8-20-H

  • Warranty

    24 miesiące

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: in stock Shipping 24/48h

Price (Incl. VAT):

409,21 €

Add to Watchlist

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

8-port PoE switch in an indoor enclosure with buffer power supply8 ports support Power over Ethernet (PoE) function


IPUPS-8-20-H set consists of XPOE-10-20A-OF switch module, AUPS-70-120-OF buffer power supply module and ASUC-100-480-OF voltage converter module enclosed in ABOX-H indoor enclosure with space for 2 18Ah batteriesThe buffer power supplies are designed to work with maintenance-free batteries (gel or AGM) with a nominal voltage of 12V

LAN ports:
  • 2 x RJ45 10/100/1000 Base-T - Uplink,
  • 8 x RJ45 10/100 Base-T + PoE (802.3af/at) / Passive PoE
    • Web / console management:No
    LEDs:AC, DC, CHARGING (battery charging), PoE, Gigabit Ethernet
    Transmission speed:
  • 10 / 100 / 1000 Mbps : 2 x Uplink port,
  • 10 / 100 Mbps : 8 x LAN & PoE port
    • Maximum output power:
  • 40 W @ Passive PoE - LAN1 ports ... LAN8,
  • 30 W @ PoE (802.3af/at) - Ports LAN1 ... LAN8
    • Maximum total power:60 W
    Operation modes:Standard: 100 m @ 10/100 Mbps - Ports LAN1 ... LAN8
    Selected features:
  • 4K UHD support
  • Independent PoE on/off capability for each LAN port 1 ... LAN 8
  • Modular design streamlines service tasks and enables quick, easy system expansion
  • Raster module mounting system makes it easy to expand the unit with additional modules
  • 2 x Battery space : 12 V / 18 Ah
  • DVR (NVR) space
  • Battery charging current : 1 A / 2 A - (set by jumper JP1)
  • Battery - Reverse polarity protection, Deep discharge battery protection
  • OC type technical outputs indicating power supply output voltage loss (OUF) and 230V mains voltage loss (ACF)
  • Power supply thermal protection : 130 °C
  • Overload protection
  • LAN & PoE ports - Short-circuit protection, Surge protection
  • TAMPER enclosure open indication switch
  • Protection class: IP20
    • Powersupply:190 ... 260 V AC
    Weight:4.40 kg
    Dimensions:455 x 405 x 150 mm
    Manufacturer / Brand:ATTE
