AHD, HD-CVI, HD-TVI, CVBS, TCP/IP DH-XVR1B08-I 8-channel recorder Dahua

A sleek black Dahua video recorder with a minimalist design and subtle branding on the front panel. The device features a compact, rectangular shape suitable for modern surveillance setups.
The image shows the back panel of a security DVR with multiple BNC video inputs, HDMI and VGA ports, and USB connections. The device is designed for connecting various surveillance cameras and output displays.
The image shows a set of electronic accessories including a black power adapter, a wired USB mouse, and various connecting cables with different colored wires. Additionally, there are small screws and connectors included in the set, suitable for assembling or connecting electronic devices.
  • Manufacturer

    Dahua
  • Product Code

    XVR1B08-I

  • Warranty

    36 miesięcy

  • Technology: AHD/HD-CVI/HD-TVI/IP
  • Number of channels: 8
  • Built-in POE switch: No

Ask about this product show form

  • Availability: Product temporarily unavaliable

Price (Incl. VAT):

111,39 €

Add to Watchlist

Powiadom o dostępności pokaż formularz

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

5-in-1 Hybrid DVR XVR1B08-I 8 channels Dahua.

The DH-XVR1B08-I is a low budget recording device used in small video surveillance structures. The device is part of Dahua's innovative Cooper Series of self-adaptive 5-system DVRs, which enable smooth and dynamic recording of sites and objects. Cooper series XVR recorders meet the basic requirements for such systems while allowing considerable savings. The presented DVR DHI XVR1B08-I is designed for monitoring based on eight channels with any CVBS / AHD / HD-CVI / HD-TVI / IP cameras and two additional channels with IP cameras (simultaneous operation of up to 10 IP channels).



Main features:

  • video inputs: 8x CVI / AHD / TVI / CVBS / IP + 2x IP
  • video outputs: 1x VGA, 1x HDMI (Full HD)
  • recording (CVI, AHD, TVI): 25/30 fps @ 960x1080 (1080N - 1080p Lite)*.
  • recording (IP): 25/30 fps* @ 3072x2048 (6Mpx)
  • compression format: AI Coding*/H.265+/H.265/H.264+/H.264
  • audio input/output: 1/1 (RCA)
  • network interface: 1x Ethernet RJ45 100Mbps
  • disk support: 1x HDD Sata III (max. 6TB)
  • support for P2P connections
  • AI functions: SMD+ (4 channels)
  • remote control of OSD menu of cameras thanks to CoC function
  • audio recording from up to 8 CVI cameras or 10 IP cameras
  • bitrate: 32Kbps ~ 4096Kbps (per channel), 40Mbps - for IP



Technical specifications:




Standard:AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
Video inputs:8 pcs. BNC - AHD / HD-CVI / HD-TVI / CVBS
Video outputs:1 pcs. HDMI
1 pcs. VGA
Audio inputs:
  • 1 pcs. CINCH,
  • 8 - Audio support over coaxial cable, HD-CVI only
Audio outputs:1 pcs. CINCH
Video compression method:AI Coding / H.265+ / H.265 / H.264+ / H. 264
Recorded image resolutions:
  • AHD / HD-CVI / HD-TVI:
    1080N - 960 x 1080 ,
    720p - 1280 x 720 ,

  • CVBS:
    960H - 960 x 576 ,
    D1 - 720 x 576 ,

  • IP :
    6 Mpx - 3072 x 2048
Adjustable recording speed:6 Mpx IP @ 1 ... 25 fps
1080N @ 1 ... 25 fps
720p @ 1 ... 25 fps
960H @ 1 ... 25 fps
to be allocated to each channel
Operating modes:8 x AHD / HD-CVI / HD-TVI / CVBS / IP + 2 x IP
Recording modes:Manual, motion detection, schedule
Supported hard drives:1 x 6 TB SATA
Archiving to external media:Snapshot of video frame or archive recordings to USB drive
Search and playback of recordings:Search for recordings by time + time line with recording type. Playback: forward, accelerate, decelerate, stepwise
Advanced search (every second)
Network functions:Client program and IE browser: live viewing, playback and archiving of recordings, partial configuration of DVR parameters
Network interface:1 x RJ-45 - 100BASE-TX
Bitrate:32 ... 4096 kbit/s
Network protocols:HTTP, HTTPS, TCP/IP, IPv4/IPv6, WiFi, 3G/4G, SNMP, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, IP Search
Cell phone access:Port: 37777 or access via cloud (P2P).
  • Android: Free DMSS app
  • iOS (iPhone): Free DMSS app

    See the video on how to set up P2P on Dahua DVRs and how to enable the mobile app
Alarm inputs/outputs:No
PTZ control:IP speed dome cameras (Speed Dome)
HD-CVI coax PTZ compatible control.
Motion detection:Zoning : 22 x 18 detection fields
USB:2 x USB 2.0
Selected functions:SMD PLUS - search for object classified as: human, motor vehicle, non-motor vehicle
Mouse operation:Yes
IR remote control included:No
Power supply:12 V DC / 1.5 A (power adapter included)
Color:Black
Weight:0.58 kg
Dimensions:198 x 203 x 42 mm
Supported languages:Polish, English, Bulgarian, Czech, Finnish, Greek, Romanian, Serbian, Slovenian, Hungarian
Manufacturer/Brand:Dahua

Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt
