Set of Four IP Cameras DS-2CD1341G0-I/PL 4 Mpx, NVR-4CH-POE Recorder Hikvision
Photo gallery
-
Manufacturer
-
Product Code
ZM23157
-
Warranty
24 miesiące
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Dome
- Number of cameras: 4
- Connectivity: Wired
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,86 MB
-
Size: 0,23 MB
-
Size: 2,61 MB
Related products
Product Description
Our kits are carefully selected devices that guarantee full compatibility and efficiency. You will find all the necessary components and accessories that will allow you to immediately start installing and configuring your equipment.
In surveillance cameras is a technology that allows direct communication between the camera ( DS-2CD1341G0-I/PL ) and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:
The DS-2CD1341G0-I/PL 's Power over Ethernet (PoE) function is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of surveillance systems.
H.265+ coding, also known as High Efficiency Video Coding (HEVC+), is an advanced video compression technology used in modern surveillance systems such as NVR-4CH-5MP/4P / HWN-4104MH-4P and DS-2CD1341G0-I/PL. It is an extension of the H.265/HEVC standard, providing even higher compression efficiency than its predecessors. The main features of H.265+ encoding in surveillance DVRs are:
The DS-2CD1341G0-I/PL 's D-WDR (Digital Wide Dynamic Range) function is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the D-WDR feature are:
EXIR diodes in Hikvision DS-2CD1341G0-I/PL surveillance cameras are an advanced lighting technology that brings significant improvements in the quality and efficiency of surveillance.
The kit includes:
- Hikvision NVR-4CH-POE / HWN-4104MH-4P DVR ( 1 pc ).
- Hikvision DS-2CD1341G0-I/PL camera ( 4 pcs ).
- Hard drive 1TB ( 1pc ).
- UTP cat.5e cable ( 20m )
- Attention Facility Monitoring sticker ( 1pc )
- Set of RJ45 plugs
Main features:
- Complete monitor kit with 4 cameras, DVR and all necessary accessories.
- High resolution image quality up to 4 Mpx(2560 x 1440p)
- Viewing angle of the cameras: 100°
- Outdoor/indoor mountable cameras
- Night visibility up to 30 meters
- Day/night ICR cameras
- EXIR LEDs
- Motion detection
- Cameras meeting IP67 waterproof rating
- Overwrite function
- Viewing via internet on computer, mobile, tablet
- P2P(cloud) support - function allowing remote access without port forwarding and public IP address
- Software included
- Polish manual for operation, configuration and installation
Remote access from your phone and desktop computerHikvision systems allow you to configure, control and view the DS-2CD1341G0-I/PL using Hik-Connect and iVMS-4200 applications, which will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to:
Hik-Connect - Free app for iOS and Android smartphones |
 |
P2P function
In surveillance cameras is a technology that allows direct communication between the camera ( DS-2CD1341G0-I/PL ) and an end device (such as a smartphone or computer) without the need for an external server. Here are the main features and principles of this function:
- Direct Connection: P2P allows a direct connection between the camera and the user's device. This means that video data can be transmitted directly, without having to go through an intermediary server.
- Ease of Setup: One of the main advantages of P2P is the ease of setup. Users often only need to scan a QR code or enter a camera ID to establish a connection.
- Remote Access: The user can access the camera's video from anywhere in the world, provided both the camera and the end device have Internet access.
Power Over Ethernet (PoE)
The DS-2CD1341G0-I/PL 's Power over Ethernet (PoE) function is a technology that allows data and electrical power to be transmitted to a network device via a single Ethernet cable. With this solution, cameras can be installed in locations where access to power sources is limited or non-existent. PoE simplifies installation, reducing the need for additional cables and power supplies. In addition, surveillance systems using PoE are easier to scale, as adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost-effectiveness of surveillance systems.
High-quality imageThe light-sensitive sensor and high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The DS-2CD1341G0-I/PL records at 4Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
|
 |
NVR-4CH-POE / HWN-4104MH-4P 4 channel DVR.
- Support for IP cameras from other manufacturers
- Possibility to connect up to 4 IP cameras
- H.265+ video compression
- Live viewing, recording and playback of footage from cameras up to 8 Mpx
- 1 SATA interface for recording and backup
- 1 10/100Mbps network card with automatic speed selection
- Simultaneous HDMI/VGA output
- Built-in PoE switch 4 ports
- Mobile devices with systems: Android, iOS,
- Modern housing
- Built-in web server, support via CMS or mobile client
Efficient storage
H.265+ coding, also known as High Efficiency Video Coding (HEVC+), is an advanced video compression technology used in modern surveillance systems such as NVR-4CH-5MP/4P / HWN-4104MH-4P and DS-2CD1341G0-I/PL. It is an extension of the H.265/HEVC standard, providing even higher compression efficiency than its predecessors. The main features of H.265+ encoding in surveillance DVRs are:
- Higher Compression Efficiency: H.265+ makes it possible to significantly reduce the size of video files while maintaining the same image quality. This saves disk space and increases the storage time of recordings.
- Energy Savings: More efficient compression reduces the CPU load, resulting in lower power consumption of surveillance equipment.
DS-2CD1341G0-I/PL dome camera
- Lens: fixed focal length 2.8mm
- Resolution: 4 Mpx
- Viewing angle: 100°
- Recording speed: 20 fps @ 4 Mpx; 25 fps @ 3 Mpx
- Image quality correction features
- IR range: 30 m
- Image compression method: H.265+/H.265/H.264+/H.264
- Application: outdoor and indoor objects
- Angle adjustment (handle): rotation: 0 to 360°, tilt: 0 to 180°, rotation: 0 to 360°
- Tube housing: metal + plastic
- Protection class: IP67
- Operating temperature: -30 °C to 60 °C
- Power supply: PoE (802.3af), 12 V DC / 410 mA
- Dimensions: Ø110 × 93.2 mm
Automatic day/night modeAdapted to work in all lighting conditions DS-2CD1341G0-I/PL with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens. |
 |
IP67-compliant housing
Such an enclosure protects the DS-2CD1341G0-I/PL from external factors such as dust, dirt and moisture, which is especially important in industrial or dusty environments. Cameras with IP67 housing can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage. |
 |
Wide dynamic range - That is, high quality in difficult conditions
The DS-2CD1341G0-I/PL 's D-WDR (Digital Wide Dynamic Range) function is a technology that improves image quality in difficult lighting conditions, especially when there are very bright and very dark areas in the camera's field of view at the same time. Key aspects of the D-WDR feature are:
- Exposure balancing: D-WDR helps to produce clear images in situations where there is strong backlighting or underexposure, such as when filming from inside a building overlooking a brightly lit exterior.
- Preservation of detail: With D-WDR, cameras can better capture details in the dark and bright parts of the image. This allows for clear recognition of faces, vehicle license plates and other important features that might not be visible under standard conditions.
- Image processing technology: D-WDR achieves its effects by quickly switching between different exposure levels or by combining several images taken with different exposure settings to create a single, balanced image.
- Usefulness in security monitoring: This feature is particularly important in security monitoring systems, where it is important to get clear images in a variety of lighting conditions, both indoors and outdoors.
Improved infrared - EXIR LEDs
EXIR diodes in Hikvision DS-2CD1341G0-I/PL surveillance cameras are an advanced lighting technology that brings significant improvements in the quality and efficiency of surveillance.
First of all, the entire visible frame is evenly illuminated, even at the edges of the image. EXIR provides better visibility at night and in low-light conditions, increasing the range of observation. It is also more energy efficient and has a longer lifetime, reducing operating costs.
Accessories:
Accessories:
Who will this surveillance kit be suitable for?
This is a modern solution with a wide range of applications. Reach for this versatile kit if you are interested, for example, in monitoring rooms, grounds or facilities both indoors and outdoors. It will prove useful wherever you can run a cable installation.
With its help it is possible, among other things:
- monitoring of a store,
- monitoring of a wholesale and warehouse, as well as a production hall,
- monitoring of a school, monitoring of a kindergarten or other educational institutions,
- monitoring of a backyard, sports field or playground,
- monitoring of a private home,
- monitoring of a bar and restaurant,
- monitoring of a parking lot.
Choose this set if you need a professional monitoring system that will not let you down.
