Monitoring set with a 5 Mpx BCS-B-TIP15FR3(2.0) tube camera and accessories

Main features:

• Complete set BCS DVR with 1 BCS 2K+ camera.
• High image quality 2592 x 1944 pixels 5Mpx

• Outdoor/indoor mountable camera
• Night visibility up to 30 meters
• Day/night ICR camera

• Motiondetection
• Overwrite function
• High capacityhard drive
• Viewing via the internet on your computer, cell phone, tablet
• P2P(cloud) support - function that allows remote access without port forwarding and public IP address
• Software included
• Polish manual for operation, configuration and installation

REMOTE ACCESS - BCS Manager

BCS is a mobile application that will allow you to configure devices and remotely view recorded video anytime, anywhere you are, in addition, it is extremely easy to configure and available in Polish.

AUTOMATIC DAY/NIGHT MODE

Adapted to work in any lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.

DVR IP network DVR, 4 channel, single disk.

• Model: BCS-B-NVR0401(2.0)
• View and record up to 4 IP cameras at a maximum resolution of 4K
• Kompresja H.265+/H265/H.264+/H.264
• Maximum incoming bandwidth 64Mbps, outgoing bandwidth 48Mbps
• Simultaneous operation of HDMI(3840×2160) and VGA(1920×1080) outputs
• Advanced video detection: motion detection, obstruction, video loss
• Support for 1 SATA drive up to 6TB
• 1 audio output
• 1×RJ45, 2×USB
• Built-in web server, support via CMS (BCS Manager), BCS mobile app (iOS, android), P2P, Onvif
• 12V DC power supply





SAVING SPACE ON HDD DRIVE

H.265+ encoding, so that the demand for disk space is reduced while not degrading the video quality of the recorded image.

1x BCS Basic 5Mpx IR 30m horn camera



• Model: BCS-B-TIP15FR3(2.0)
• IP dome camera
• 1/2.8" 5Mpx PS CMOS sensor
• Resolution 2592 ×1944@20fps
• Mechanical infrared filter
• 2D/3D digital noise reduction
• AGC, ATW, AES, BLC, FLC, D-WDR functions
• Fixed focal length lens 2.8mm F2.1
• Infrared illuminator with a range of up to 30m
• IP67 outdoor metal housing
• Application: outdoor and indoor
• Perfect for e.g. offices, warehouses, stores
• Working temperature -30°C ~ +60°C
• DC 12V power supply (power supply tolerance ±10%)

WEATHER RESISTANT

IP67 degree of protection means that the camera can be placed anywhere. The device guarantees trouble-free operation even in the harshest atmospheric conditions, thanks to the high-quality materials of the device housing.

HIGH QUALITY IMAGE

The latest technologies used in the camera's sensor and sensor, combined with advanced optics, provide high quality images and excellent sharpness compared to lower resolution cameras. The device records at 5Mpx resolution ensuring that even the smallest detail is captured on the footage.

WIDE DYNAMIC RANGE

The use of Wide Dynamic Range (WDR) takes care of the quality of the recordings by detecting and making lighting corrections in areas of overexposure and lack of light. Thanks to this solution, the device is able to capture details of contrasting images.



Accessories:

For whom will this surveillance kit be suitable?

This is a modern solution with a wide range of applications. Reach for this versatile kit if you are interested, for example, in monitoring rooms, grounds or objects both indoors and outdoors. It will prove useful wherever you can run a cable installation.

With its help it is possible, among other things:

• monitoring of a store,
• monitoring of a wholesale and warehouse, as well as a production hall,
• monitoring of a school, monitoring of a kindergarten or other educational institutions,
• monitoring of a backyard, sports field or playground,
• monitoring of a private home,
• monitoring of a bar and restaurant,
• monitoring of a parking lot.

Choose this set if you need a professional monitoring system that will not let you down.

The set includes:

• BCS-B-NVR0401(2.0) DVR ( 1pc ).
• BCS-B-TIP15FR3(2.0) cameras ( 1pc ).
• 1TB hard drive ( 1pc ).
• UTP cable ( 5m )
• RJ45 plug ( 4pcs )
• PoE Switch 4-Port ( 1pc )
• Sticker "Attention Object Monitored" ( 1pcs )
