5-port ATTE IP-5-11-E PoE Switch

The image shows a white, rectangular ATTE PoE switch with a minimalist design and a secure locking mechanism on the side. It features multiple ports for network connectivity and a power indicator on the front panel.
The image shows an open metal enclosure with a mounted electronic circuit board and power supply unit. The interior features a perforated panel for ventilation and organized cable management.
The image shows a red circuit board with multiple Ethernet ports and electronic components, mounted on a perforated white panel. Above it, there is a power supply module with a transformer and various connectors.
A white, rectangular electronic enclosure with a perforated front panel for ventilation and multiple mounting holes. The design includes cutouts on the sides for cable management and easy access.

  • Manufacturer

    ATTE

  • Product Code

    IP-5-11-E

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: in stock Shipping 24/48h

Price (Incl. VAT):

153,87 €

Add to Watchlist

Najniższy koszt dostawy: 12,98 zł

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

The IP-5-11-E set consists of the XPOE-6-11-OF switch module and the APS-90-480-OF switched-mode power supply enclosed in an ABOX-E indoor enclosure
The LONG RANGE mode of operation allows to increase the transmission range of power and data for LAN ports 1 ... LAN 4 to 280m while limiting the network bandwidth for these ports to 10Mbps
LAN ports:
  • 1 x RJ45 10/100 Base-T - Uplink
  • 5 x RJ45 10/100 Base-T + PoE (802.3af/at) / Passive PoE
Web / console management:No
LEDs:Power, LAN
Transmission speed:10 / 100 Mbps : 1 LAN Port + 5 LAN & PoE Ports.
Maximum output power:
  • 40 W @ Passive PoE - Ports 1 ... 4,
  • 70 W @ Passive PoE - Port 5,
  • 30 W @ PoE (802.3af/at) - Ports 1 ... 5
Maximum total power:96 W
Operating modes:
  • Normal : 100 m @ 10/100 Mbps - Ports 1 ... 5
  • Long Range : 280 m @ 10 Mbps - Ports 1 ... 4 ; 100 m @ 10/100 Mbps - Port 5
  • LAN port 6 - Uplink
Selected features:
  • Cascading capability (power transfer between devices using Passive PoE via LAN port 5).
  • PoE output voltage is equal to input voltage
  • Ability to independently enable and disable PoE power for each LAN port 1 ... LAN 5
  • Modular design streamlines maintenance tasks and enables quick, easy system expansion
  • Raster module mounting system makes it easy to expand the unit with additional modules
Power supply:230 V AC - cable terminals
Weight:1.4 kg
Dimensions:255 x 205 x 95 mm
Manufacturer / Brand:ATTE
