BCS-P-DPIP24FSR3-Ai2 4Mpx 2.8mm IR30 BCS Point IP Dome Camera
Photo gallery
-
Manufacturer
-
Product Code
BCS-P-DPIP24FSR3-Ai2
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Dome
- Night visibility: up to 30m
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Color: White
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 3,73 MB
-
Size: 1,01 MB
Related products
Product Description
Main features:
- Sensor: 1/2.7" PS CMOS,
- Pixel count: 4Mpx,
- Compression: H.265+/H.264+/MJPEG,
- Sensitivity: 0.002Lux(F1.6,AGC) 0Lux(B/W,IR),
- Lens: 2.8mm/F1.6,
- Field of view: H: 101.1° V: 55.3° D: 111.1°,
- Infrared illuminator: Up to 30 meters,
- Built-in microphone,
- Audio input/output: 1/1,
- Functions: AWB, AGC, AES, BLC, HLC, WDR(120dB), 2D/3D DNR,
- Memory card slot: MicroSD up to 256GB,
- Color: White,
- Protection class: IP67, IK10,
- Power supply: 12VDC / PoE (802.3af).
Network 4Mpx camera model BCS-P-DPIP24FSR3-AI2 by BCS Point. It is equipped with 1/2.7" 4Mpx CMOS sensor with progressive scanning system. Fixed lens with a focal length of 2.8mm. For accurate monitoring and capturing a considerable amount of detail in insufficient lighting, an IR illuminator with a range of up to 30 meters is built in.
Technical specifications:
| Device Name | BCS-P-DPIP24FSR3-Ai2 |
| Product line | BCS Point |
| Camera type | Dome |
| Resolution | 4 Mpx |
| Sensor | 1/2.7'' |
| Scanning system | Progressive Scan |
| Pixels | 2688(H)×1520(V) |
| Lens | fixed |
| Focus | fixed |
| Focal length | 2.8 mm |
| Aperture | F1.6 |
| Iris | Fixed |
| Digital zoom | 16× |
| Viewing angle | H: 101.1° V: 55.3° D: 111.1° |
| DORI | Detect 63m / Observe 25m / Recognize 13m / Identify 6m |
| Camera sensitivity | 0.002Lux(F1.6,AGC) 0Lux(B/W,IR) |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Image rotation | Mirror, Flip 0°/90°/180°/270° |
| Number of streams | 3 |
| Resolutions | 4M(2688×1520)(2560×1440) / 3M(2304×1296) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / (640×360) / 2CIF(704×288) / CIF(352×288) |
| Main stream | 2688×1520/2560×1440/2304×1296/1920×1080/1280×720(30fps) |
| Second stream | 1280×720/720×576/640×360/704×288/352×288(30fps) |
| Third stream | 720×576/640×360/704×288/352×288(30fps) |
| Bitrate | 128Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR |
| Illuminator type | IR |
| Illuminator | 30m |
| Microphone | Yes |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711 |
| Alarm input | 1 |
| Alarm output | 1 |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detection | 4 |
| Privacy masks | 4 |
| Networking | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS |
| Power supply type | 12VDC / PoE(802.3af) |
| Power consumption | max 4.5W |
| Housing color | White |
| Operating conditions | -30°C~+55°C max 95% RH |
| Dimensions | Ø109×62mm |
| Weight | 0.22 kg |
| Ai - Built-in intelligent functions | Yes |
| Ai - Perimeter protection | Yes |
| Ai - Object recognition | Yes |
| Ai - Face detection | Yes |
