IP Video Intercom Monitor BCS-MON4000W-S BCS Line
Photo gallery
-
Manufacturer
-
Product Code
BCS-MON4000W-S
-
Warranty
36 miesięcy
Ask about this product show form
Files attached to the product show files
Product Description
Main features:
| |
BCS-MON4000W-S Hands-free video monitor BCS Line
The BCS-MON4000W-S is a hands-free BCS IP video intercom monitor. It has a 4.3" TFT capacitive touchscreen with 480x272 resolution. Local management of the monitor is done via a graphical interface. It is possible to expand the system up to 10 monitors (per premises) and up to 5 for multi-family systems. The device belongs to the economy line, it has no memory card slot.
Technical specifications:
| Device type | Hands-free video monitor |
| Compatibility | BCS outdoor panels with SIP firmware v4.3 or later |
| Number of supported inputs | 20 (for a system where the SIP server is the selected outdoor panel), for multi-family panels the maximum number of outdoor panels is 10 |
| Operating system | Linux |
| Expansion | Max 10 video monitors in the same premises (5 for multifamily systems) |
| Display type | TFT touchscreen, capacitive |
| Resolution | 480 x 272 |
| Diagonal size | 4.3" |
| Camera protocol | BCS Line, Onvif |
| Number of supported CCTV cameras | 32 |
| Video compression | H.264 |
| Resolution of supported cameras | 720P (1280×720) or less (auxiliary stream) |
| Audio | Built-in omnidirectional microphone and speaker |
| Audio compression | G.711a; G.711u; PCM |
| Network connection | RJ-45 (10/100Base-T) |
| Protocol | TCP/IP, SIP |
| Built-in web server | No |
| Memory card | No memory card support |
| Doorbell function | Yes |
| Auto-open entrance function | Yes |
| Intercom | Yes |
| Relay output | Yes |
| Secondary caller function | Yes |
| Manual control of NO output | Yes (interchangeable with call secondary function) |
| Do not disturb (DND) function | Yes (built-in daily and weekly schedule) |
| Image conversion of intercom camera to CCTV camera | Yes, manually controlled during call and conversation or permanent conversion |
| Name identification of entrances (external panels) | Yes |
| Possibility to manually view image from any entrance | Yes, audio + video |
| Outputs | 1 x NO/COM relay output |
| Inputs | 4 x wired sensor (or doorbell) 1 x 12VDC power input 1x Ethernet 10/100 Mbps auto |
| Power supply | DC12V 1A,PoE (802.3af/af/passive) |
| Power consumption | Operation ≤6W, standby ≤4W |
| Operating conditions | -10°C ~ +55°C, 10-95% RH |
| Housing | Plastic |
| Weight | 0.21 kg |
| Dimensions | 136 × 140 × 25.5 mm |
| Mounting | Surface mounted |
| Other | Comes with mounting base for installing the unit on the wall and connection tape for connecting power supply, doorbell, wired sensors and relay output lead out |
