IP Network Recorder 16 Channel KEEYO LV-V-NVR-16CH-8P 8x PoE
Photo gallery
-
Manufacturer
-
Product Code
LV-V-NVR-16CH-8P
-
Warranty
24 miesiące
- Technology: IP
- Number of channels: 16
- Built-in POE switch: Yes
Ask about this product show form
Files attached to the product show files
Related products
Product Description
- Support for IP cameras from other manufacturers
- Up to 16 IP cameras can be connected
- Built-in 8-port PoE switch
- H.265+ video compression
- Live viewing, recording and playback of footage from cameras up to 8 Mpx
- 1 SATA interface for recording and backup
- 1 10/100Mbps network card with automatic speed selection
- Simultaneous HDMI/VGA output
- In-app support via mobile devices with systems: Android, iOS
- Web browser support: Chrome, Firefox, Safari, Microsoft Edge, Internet Explorer 8-11
- Modern casing
- Built-in web server, support via CMS or mobile client
Remote access from desktops and smartphones
BITVISION mobile app is a quick and easy way to operate your property's video surveillance system, with it you will be able to:
✅Save video excerpts to your smartphone's memory
✅Configure time frames for motion detection
✅Receive notifications from motion detection or other events
✅Share your devices with other smartphones with the mobile app, such as family members or employees
Support popular browsers
The WEB server on KEEYO DVRs is supported by popular browsers like Google Chrome, Mozilla Firefox and even Safari.
Technical specifications:
| Processor | ARM Cortex A7 Processor |
| Operating System | Embedded LINUX |
| Video | |
| Input | 16CH(3840*2160,2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc.). |
| Output | 1 VGA, 1 HD |
| Audio | |
| Input | 1 RCA port, support 16CH IPC audio |
| Output | 1 RCA port (line-level, 1kΩ), HD output |
| Audio bit rate | 64kbps |
| Audio compression standard | G711u, G711a, ADPCM_DVI4 |
| Intercom | support (two-way) |
| Alarm | |
| Sensor input | N/A |
| Sensor output | N/A |
| Motion detection | 16 channels, MD zones: 396 (22 × 18) |
| Trigger events | Recording, E-mail, FTP, Snapshot, Buzzer and on-screen guidance |
| Display | |
| HD Output1 | 4K(38402160), 19201080,12801024, 1280720, 1024*768 |
| HD Output2 | N/A |
| VGA | Resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Display division | 16CH/13CH/10CH/9CH/8CH/6CH/4CH/1CH |
| Digital zoom | YES |
| OSD | Camera title, time, recording, motion detection, event alarm |
| Recording | |
| Video compression | H265/H264/H265+/H264+ |
| Resolution | 4K(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480) |
| Recording speed | "PAL: 4K@10CHx25fps,5MP@16CH×25fp,4MP@16CHx25fp,3MP@16CH×25fp,1080P@16CH×25fp, 960P@16CH×25fp,720P@16CH×25fp, D1@16CH×25fp NTSC: 4K@10CHx30fps,5MP@16CH×30fp,4MP@16CH×30fp,3MP@16CH×30fp,1080P@16CH×30fp, 960P@16CH×30fp, 720P@16CH×30fp, D1@16CH×30fp" |
| Recording mode | Manual/Timer/Motion Detection/Intelligent Events |
| Playback and backup | |
| Local synchronous playback | 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps, 4CH 960P@30fps, 4CH 720P@30fps,16CH D1@30fps |
| Decoding capability | 4CH 1080P(1920x1080)@30fps |
| Remote synchronous playback | YES |
| Search mode | ALL, Video by time, Motion detection, Alarm, Search by tag, Intelligent events, Image, Log |
| Playback functions | Playback, pause, fast forward, fast reverse, previous frame, next frame, electronic zoom, trim, audio |
| Copy mode | USB device/Network |
| Network | |
| Interface | 1xRJ45 10M/100/1000MInterface Ethernet (Adaptive). |
| Incoming bandwidth | 120Mb |
| Network functions | IPv6/TCP/IP, HTTP, HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE |
| Onvif | onvif S, onvif T |
| Web browser | Edge, IE8-11, Google Chrome, Firefox, Safari |
| CMS software | Windows 7/Windows 8/Windows 10/MAC OS support |
| Cloud support | Yes |
| Smartphone | iPhone, iPad, Android, Android Pad |
| POE | Built-in 8-port PoE switch |
| WIFI | N/A |
| Storage | |
| Interface type | 1 SATA hard drive interface (3.5" SATA) |
| Capacity | Maximum 8 TB |
| eSATA | N/A |
| General | |
| Interface language | Simplified Chinese, Traditional Chinese, English, Polish, Russian, German, French, Portuguese, Spanish, Italian, Korean, Japanese, Ukrainian |
| USB interface | 2 USB 2.0 interfaces |
| RS485 | N/A |
| Power consumption | DC12V∕2000mA ≤10W (without hard drive) |
| Operating environment | -10℃～50℃, 10%～90% (humidity) |
| Dimensions (S × G × W) | 260 × 230 × 43 mm |
| Weight | 2 kg (without hard disk) |
