IP Camera BCS-L-SIP2425SR10-AI2 4 Mpx with 25x optical zoom
Photo gallery
-
Manufacturer
-
Product Code
BCS-L-SIP2425SR10-AI2
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Rotating
- Night visibility: up to 100m
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Color: White
- Streaming: No
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 7,75 MB
-
Size: 1,44 MB
-
Size: 0,68 MB
Related products
Product Description
Main features:
|
|
BCS-L-SIP2425SR10-Ai2 is an advanced 4 Mpx PTZ camera with 25x optical zoom and 16x digital zoom. With STARVIS technology and DORI function, it offers excellent image quality and long distance detection. The camera is equipped with intelligent AI functions such as object recognition, face detection and image analysis. It can be used both in nighttime conditions, thanks to a 100m IR illuminator. IP66 water resistance, overload protection and the ability to operate in extreme temperatures are additional features that make the camera ideal for outdoor surveillance.
Technical specifications:
| Device Name | BCS-L-SIP2425SR10-Ai2 |
| Product line | BCS Line |
| Camera type | PTZ |
| Resolution | 4 Mpx |
| Sensor | 1/2.8'' STARVIS |
| Scanning system | Progressive Scan |
| Pixels | 2560(H)×1440(V) |
| RAM | 1GB |
| ROM | 4GB |
| Lens | motozoom |
| Focal length | 5~125 mm |
| Aperture | F 1.6~3.6 |
| Focus | Auto / manual |
| Iris | Auto / manual |
| Optical zoom | 25× |
| Digital zoom | 16× |
| Viewing angle | H:53.1°~3.4° V:30.4°~1.9° D:59.3°~3.9° |
| DORI | Detect 2161m / Observe 865m / Recognize 432m / Identify 216m |
| Camera sensitivity | 0.005Lux(F1.6) 0.0005Lux(F1.6,B/W) 0Lux(B/W,IR) |
| S/N ratio | 55dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1/3~1/30000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Electronic Image Stabilization | EIS |
| Defog | Electronic |
| Image rotation | Flip 180° |
| Number of streams | 3 |
| Resolutions | 4M(2560×1440) / 3M(2048×1536)(2304×1296) / 2M(1920×1080) / 720P(1280×720) / D1(704×576)(704×480) / CIF(352×288)(352×240) |
| Main stream | 2560×1440 / 2048×1536 / 2304×1296 / 1920×1080 / 1280×720(25/30fps) |
| Second stream | 704×576 / 704×480 / 352×288 / 352×240(25/30fps) |
| Third stream | 1920×1080 / 1280×960 / 1280×720 (25/30fps) |
| Bitrate | H.264: 96 kbps-14848 kbps H.265: 38 kbps-8960 kbps |
| Video compression | H.265 / H.265+ / H.264+ / H.264 / MJPEG |
| Day/night | ICR |
| Illuminator type | IR |
| Illuminator | 100m |
| Audio input | 1 |
| Audio output | 1 |
| Audio compression | G.711A / G.711Mu / G.726 / G.722.1 / G.723 / G.729 / PCM / MPEG2-L2 |
| Alarm input | 2 |
| Alarm output | 1 |
| Memory card slot | microSD 512GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detection | 4 |
| Privacy masks | 24 |
| Networking | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, Qos, RTSP, ARP |
| Power supply type | 12VDC / PoE(802.3at) |
| Power consumption | max 20W |
| Housing color | White |
| IP protection class | IP66 |
| Surge protection | TVS 6kV |
| Operating conditions | -40°C~+70°C max 95% RH |
| Dimensions | Ø160mm×270mm |
| Weight | 2.4 kg |
| PAN speed | 0.1°/s~200°/s(240°/s preset) |
| TILT Speed | 0.1°/s~120°/s(200°/s preset) |
| PAN Range | 0°~360° |
| TILT Range | -15°~90° auto-flip |
| Automation functions | 300 presets, 8 routes(32 presets each), 5 tracks, 5 scans |
| Ai - Built-in intelligent functions | Built-in intelligent image recognition and analysis algorithms |
| Ai - Perimeter protection | Area intrusion, line crossing, rapid movement, loitering, crowd detection, parking detection |
| Ai - Object recognition | Person/vehicle recognition for area intrusion, line crossing and rapid movement reduces false alarm triggering. |
| Ai - Face detection | Face detection and tracking, face photo, facial attribute and expression recognition |
| Ai - SMD | SMD 4.0 |
| Accessories included | Wall mount |
