Switch PoE FS1010P 8+2 10/100Mbps, 8x PoE+, 120W CUDY

Main Features:

Switch FS1010P by Cudy is a PoE network switch, equipped with 8 RJ45 10/100Mbps ports with IEEE 802.3at / 802.3af power support and 2 Uplink ports. The device has a total PoE power budget of 120W, with a single port capable of delivering up to 30W. The model also features high throughput, reaching 2 Gbps.

• Switch type: PoE
• Number of ports: 10
• Number of PoE+ ports: 8
• Number of Uplink ports: 2
• Transmission speed: 10/100 Mbps
• Transmission range: up to 250 m
• PoE power: 120W, maximum 30W per port
• Throughput: 2 Gbps
• Packet processing speed: 1.48 Mpps
• Cache memory: 2M
• MAC table: 8K
• Key features: VLAN, CCTV, Plug & Play
• Operating temperature range: -20°C to +50°C
• Power supply: 100 - 240V AC, 50/60Hz
• Dimensions: 200 × 150 × 44 mm
• Weight: more than 1 kg

Multifunctionality and PoE

Cudy's FS1010P switch is equipped with 8 PoE+ ports, which allow it to power other network devices, such as IP cameras or access points, without the need for additional power cables. The maximum power provided by a single port is 30W, and the total PoE power budget is 120W.

High throughput

The switch's throughput is 2 Gbps, and the packet forwarding speed reaches 1.48 Mpps. These parameters guarantee smooth and fast network communication, even under heavy load. The device allows data transmission over distances of up to 250 meters, making it an ideal choice for extensive installations such as office buildings, warehouses or larger local networks.

Management features

The switch offers advanced network management features such as VLAN and CCTV. With VLAN, it is possible to isolate specific groups of devices, which increases security and control over network traffic. The CCTV function allows you to optimize your network for video surveillance.

Ease of configuration

Thanks to the Plug & Play option, configuration of the device is extremely simple and fast, making it an ideal choice even for non-network experts. The switch features compact dimensions (200 × 150 × 44 mm) and a robust design. It is suitable for operation in a variety of conditions, including temperatures from -20°C to +50°C, making it a versatile solution for both offices and more demanding industrial environments.

Technical specifications:

Router	FS1010P
Number of PoE+ ports	8
Number of Uplink ports	2
Transmission speed	10 / 100 Mbps - 8 x PoE+ ports 10 / 100 Mbps - 2 x Uplink ports
Data transmission	up to 250m
Throughput	2 Gbps
Packet transmission speed	1.48 Gbps
Cache	2M
MAC address table	8K
PoE power budget	120W, up to 30W per 1 port
Selected features and security	VLAN, CCTV, Plug & Play
Power supply	100 - 240V AC, 50/60Hz
Operating temperature	-20°C - 50°C
Humidity	10 ~ 90%
Dimensions	200 × 150 mm × 44 mm
