64-channel IP Recorder BCS-V-NVR6408R-A-8K - BCS Point
Photo gallery
-
Manufacturer
-
Product Code
BCS-V-NVR6408R-A-8K
-
Warranty
36 miesięcy
- Technology: IP
- Number of channels: 64
- Built-in POE switch: No
Ask about this product show form
Product Description
Here are the main features of the BCS-V-NVR6408R-A-8K:
- Product line: BCS View
- System: IP
- Function: Pentaplex (Live viewing / recording / playback / archiving / remote access)
- Channels: 64
- Disks: 8
- Disk capacity: 16 TB
- RAID type: 0/1/5/6/10, hot spare disk module
- Max recording resolution: 32 Mpx
- Input bandwidth: 400Mbps
- Output bandwidth: 400Mbps
- Display performance:
- 2×32M(30fps) +2×8M(30fps)
- 10×8M(25fps)
- 20×4M(30fps)
- 40×2M(30fps)
- Recording resolution: 32M / 24M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
- Video compression: H.265+ / H265 / H.264+ / H.264
- HDMI output: HDMI8K/HDMI4K
- VGA output: 2×VGA
- HDMI display resolution:
- 7680×4320 (HDMI1)
- 3840×2160
- 2560×1440
- 1920×1080
- 1600×1200
- 1280×1024
- 1280×720
- 1024×768
- VGA display resolution:
- 1920×1080
- 1600×1200
- 1280×1024
- 1280×720
- 1024×768
- Output split: 1/4/6/8/9/16/25/32/36/64
- Playback: 1/4/9/16
- Archiving: Possibility to rip footage to external media like USB FLASH, USB HDD
- Users: 128
- Interfaces:
- 2×USB2.0
- 2×USB3.0
- eSATA
- Serial port: RS232, RS485
- Audio input: 1
- Audio output: 2
- Audio compression: G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM
- Alarm input: 16
- Alarm output: 9
- Support: Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
- Network: 2×RJ-45 10/100/1000Mbps
- Compatibility: ONVIF, support for third-party cameras
- Protocols: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
- Power supply: 100~240V AC
- Power consumption (without drives): 50W max.
- Operating conditions: -10°C~+55°C, max 90% RH
- Enclosure: 2U
- Dimensions (W×D×H): 445×465×93mm
- Weight (without drives): 10kg
- POST: Yes
- AI - Smart functions from cameras:
- SMD
- Intrusion into an area
- Line crossing
- Heat map
- ARTR
- Counting people
