8-channel IP Recorder BCS-L-SNVR0801-4KE-8P(2), 8Mpx - BCS Line
Photo gallery
-
Manufacturer
-
Product Code
BCS-L-SNVR0801-4KE-8P(2)
-
Warranty
36 miesięcy
- Technology: IP
- Number of channels: 8
- Built-in POE switch: Yes
Ask about this product show form
Product Description
Here are the main features of the BCS-L-SNVR0801-4KE-8P(2):
- Product line: BCS Line
- System: IP
- Pentaplex function: live viewing / recording / playback / archiving / remote access
- Channels: 8
- Disks: 1
- Disk Capacity: Maximum 20 TB
- Recording mode: Continuous, manual, alarm, motion detection, schedule, Ai
- Maximum recording resolution: 12 Mpx
- Input bandwidth: 144 Mbps (72 Mbps Ai)
- Output bandwidth: 72 Mbps (36 Mbps Ai)
- Recording bandwidth: 144 Mbps (72 Mbps Ai)
- Display performance:
- 1×12M (30fps)
- 1×8M (30fps)
- 2×5M (30fps)
- 3×4M (30fps)
- 6×2M (30fps)
- 1×8M Ai (30fps)
- 1×5M Ai (30fps)
- 2×4M Ai (30fps)
- 4×2M Ai (30fps)
- Recording resolution: 12M / 8M / 5M / 4M / 3M / 2M / 720P / D1
- Video compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
- HDMI output: HDMI 4K
- VGA output: VGA
- HDMI display resolution: 3840×2160 / 1920×1080 / 1280×1024 / 1280×720
- VGA display resolution: 1920×1080 / 1280×1024 / 1280×720
- Output split: 1/4/8/9
- Playback: 1/4/8 channels
- Archiving: Possibility of ripping footage to external media such as USB FLASH, USB HDD
- Users: Up to 128 users
- Interfaces: 2×USB2.0
- Audio input: 1
- Audio output: 1
- Audio compression: G.711A / G.711U / G.726 / PCM
- Support: Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App (iOS, Android)
- Network: RJ-45 10/100/1000 Mbps
- Compatibility: ONVIF(S/G/T), support for third-party cameras
- Protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filter, DDNS, IP Search, P2P, Auto Registration
- Standard: IEEE 802.3 af/at
- Switch PoE power: 72W max 25.5W/port
- PoE channels: 8
- Power supply: 53V DC
- Power consumption (without drives): 10W max
- Operating conditions: -10°C~+55°C, max 93% RH
- Enclosure: Smart
- Dimensions (W×D×H): 270×205×45 mm
- Weight (without drives): 0.68 kg
- Ai - Smart functions from the DVR: SMD Plus
- Ai - Smart functions from cameras: Perimeter protection, SMD Plus
- Ai - Perimeter protection: 4 channels from cameras
- Ai - SMD: 4 channels from cameras / 4 channels from DVR (person/motor vehicle recognition)
