IP Dome Camera 4Mpx BCS-L-EIP14FSR3L3, SkyLight, IR 30m, WDR 120dB
Photo gallery
-
Manufacturer
-
Product Code
BCS-L-EIP14FSR3L3
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Dome
- Night visibility: up to 30m
- Connectivity: Wired
- Memory card slot: No
- Audio: Yes
- Color: White
Ask about this product show form
Product Description
Product contents:
In addition to the camera, the box also contains useful instructions and mounting accessories to speed up the entire process of mounting the camera.
BCS products are devices focused on ease of use, literally anyone can handle their installation and configuration thanks to the included instructions.
In addition to the camera, the box also contains useful instructions and mounting accessories to speed up the entire process of mounting the camera.
- 1x 4Mpx horn camera - BCS-L-EIP14FSR3L3
- Documentation - User manual, warranty card, adjustments
- Template - Small size template with camera mounting holes
- Screws and mounting studs - Everything you need to mount the camera
- Waterproof kit - A set of accessories to protect the camera's connectors from moisture
BCS products are devices focused on ease of use, literally anyone can handle their installation and configuration thanks to the included instructions.
BCS-L-EIP14FSR3L3 camera:
- 4 Mpx (2560×1440 px) resolution provides detailed images.
- Wide viewing angle (H: 94°, V: 52°, D: 111°) enables effective surveillance of large areas.
- The built-in microphone allows you to record audio without additional equipment.
- Range of infrared (IR) and white light up to 30 m - effective monitoring also at night.
- Advanced image features: WDR 120 dB, 3D DNR, BLC, HLC - high quality recordings in difficult conditions.
- Mechanical ICR filter provides day/night mode switching.
- Support for H.265+ / H.264+ / MJPEG compression - saving disk space.
- Possibility of remote operation via browser, mobile application and CMS BCS Manager.
- IP67 protection class - water and dust resistance, for outdoor applications.
- PoE (802.3af) or 12VDC power supply - flexibility in installation.
- Compact dimensions (Ø106×94 mm) and low weight (0.33 kg) - easy installation even in harder to reach places.
Capture the largest possible area
The 2.8mm lens provides a wide field of view, ideal for monitoring large areas. The BCS-L-EIP14FSR3L3 camera can capture a wide scene with minimal blind spots. This configuration is particularly useful in areas that require extensive monitoring, such as parking lots, warehouses or public spaces, where it is important to capture as much of the environment as possible without the need for multiple cameras.
The 2.8mm lens provides a wide field of view, ideal for monitoring large areas. The BCS-L-EIP14FSR3L3 camera can capture a wide scene with minimal blind spots. This configuration is particularly useful in areas that require extensive monitoring, such as parking lots, warehouses or public spaces, where it is important to capture as much of the environment as possible without the need for multiple cameras.
High-quality image
A light-sensitive sensor and a high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The BCS-L-EIP14FSR3L3 records at 4Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
A light-sensitive sensor and a high-quality sensor combined with advanced optics deliver high-quality images with excellent sharpness. The BCS-L-EIP14FSR3L3 records at 4Mpx resolution, giving it a significant advantage over typical FullHD models. It guarantees that even the smallest detail will be captured on the footage.
- A: 1280x720p ( 1Mpx )
- B: 1920x1080p ( 2Mpx )
- C: 2048x1536p ( 3Mpx )
- D: 2560x1440p ( 4Mpx )
- E: 2560x1960p ( 5Mpx )
- F: 3840x2160p ( 8Mpx )
IP67 weatherproof design
This housing protects the BCS-L-EIP14FSR3L3 camera from external factors such as dust, dirt and moisture, which is especially important in industrial environments or dusty locations. The IP67-enclosed cameras can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage.
This housing protects the BCS-L-EIP14FSR3L3 camera from external factors such as dust, dirt and moisture, which is especially important in industrial environments or dusty locations. The IP67-enclosed cameras can be installed in a variety of locations, from industrial to marine, without worrying about environmental damage.
Remote access from phone and desktop computer
BCS systems allow you to configure, control and view via apps that will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to:
BCS systems allow you to configure, control and view via apps that will provide you with constant access to monitoring from anywhere on earth with internet access. The above programs allow you to:
- Access video preview and play back recorded footage
- Save parts of the video to your smartphone's memory
- Configure time frames for motion detection
- Receive notifications from motion detection or other events
- Share your device with other smartphones with the mobile app, such as family members or employees
D.O.R.I.
The DORI (Detection, Observation, Recognition, Identification) parameter is used to determine the ability of video systems, such as BCS-L-EIP14FSR3L3 cameras, to detect, observe, recognize and identify objects or people at specific distances. The values given for each of these four elements determine the effective range at which the system can perform each of these activities:
The DORI (Detection, Observation, Recognition, Identification) parameter is used to determine the ability of video systems, such as BCS-L-EIP14FSR3L3 cameras, to detect, observe, recognize and identify objects or people at specific distances. The values given for each of these four elements determine the effective range at which the system can perform each of these activities:
- Detection (64m): The system is able to detect the presence of an object or person at a distance of up to 64 meters. This means that at this distance you can tell that something is within the camera's range of view, but you can't necessarily determine what it is.
- Observation (25m): At distances of up to 25 meters, the system can not only detect an object, but also provide enough detail for the observer to get an idea of the general shape and perhaps some of the characteristics of the object, but without exact recognition.
- Recognition (13m): Recognition at a distance of up to 13m enables the system to provide enough detail for the observer to determine the type of object, for example, to distinguish whether it is a person, car or other object.
- Identification (6m): At a distance of up to 6 meters, the system is able to provide a highly detailed image to identify specific features of an object or person, such as a face, vehicle license plate, etc., enabling accurate identification.
Reduce unnecessary noise
Key benefits:
3D DNR (3D Digital Noise Reduction) is an advanced noise reduction technology used in video surveillance cameras such as the BCS-L-EIP14FSR3L3, which improves image quality in difficult lighting conditions, especially at night or in low light. By eliminating noise, the technology produces clearer and more detailed images, which is crucial in situations requiring accurate video analysis. 3D DNR works by analyzing consecutive video frames and comparing pixels between them to detect and remove noise from the image. Unlike traditional two-dimensional noise reduction (2D DNR), which only analyzes noise within a single frame, 3D DNR takes into account both information from a single frame and differences between adjacent frames. This additional temporal analysis allows for more effective noise recognition and removal, while preserving image detail.
Key benefits:
- Enhanced image clarity: 3D DNR technology significantly improves image quality in low-light conditions, reducing grain and blur that often appears in video recordings. The result is a clearer and more readable image.
- Better compression and smaller file size: Noise in video can lead to larger file sizes through compression, as more data must be saved. 3D DNR, by reducing noise, allows for better compression and smaller file sizes, which is beneficial for long-term storage.
- Improved visibility of details: By reducing noise at night or in low-light conditions, 3D DNR helps identify fine details such as faces, license plates and other key elements, which is invaluable for evidence analysis.
- Minimizing ghosting: Unlike simpler noise reduction methods, 3D DNR minimizes the appearance of artifacts in the image, such as "ghosting" (the ghosting effect of objects moving in the frame). By analyzing multiple frames at once, the technology does a better job of eliminating these unwanted effects.
Microphone - a more complete picture of the situation
The BCS-L-EIP14FSR3L3 camera is equipped with a built-in microphone, which allows recording ambient sound and transmitting it simultaneously with the image. This allows not only visual monitoring, but also auditory monitoring, providing a more complete picture of the situation. This feature is particularly useful in areas requiring detailed surveillance, such as building entrances, stores or offices, where audio can provide additional information about events and improve the effectiveness of surveillance.
The BCS-L-EIP14FSR3L3 camera is equipped with a built-in microphone, which allows recording ambient sound and transmitting it simultaneously with the image. This allows not only visual monitoring, but also auditory monitoring, providing a more complete picture of the situation. This feature is particularly useful in areas requiring detailed surveillance, such as building entrances, stores or offices, where audio can provide additional information about events and improve the effectiveness of surveillance.
Automatic day/night mode
Adapted to work in all lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.
Adapted to work in all lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.
Technical specifications
| Product details - BCS-L-EIP14FSR3L3 | |
|---|---|
| Device name | BCS-L-EIP14FSR3L3 |
| Product line | BCS LINE |
| Camera type | Dome |
| Resolution | 4 Mpx (2560×1440) |
| Sensor | 1/2.9'' CMOS |
| Scanning system | Progressive Scan |
| RAM / ROM | 128MB / 128MB |
| Lens | Fixed, 2.8mm, F1.6 |
| Viewing angle | H: 94°, V: 52°, D: 111° |
| DORI | Detect 64m / Observe 25m / Recognize 13m / Identify 6m |
| Sensitivity | 0.006Lux (color) / 0.0006Lux (B/W) / 0Lux (IR) |
| Signal to noise ratio (S/N) | 56 dB |
| White balance | Auto / Manual (AWB) |
| WDR | 120 dB |
| Backlight compensation | BLC / HLC / WDR |
| Shutter | Auto / manual 1/3~1/100000s |
| Gain control | Auto / Manual (AGC) |
| Noise reduction | 3D DNR |
| Region of Interest (RoI) | Yes |
| Image rotation | Mirror, Flip 0°/180° |
| Number of streams | 2 |
| Resolutions | 4M, 3M, 2M, 1.3M, 720P, D1, VGA, CIF |
| Main stream | 2560×1440 (1~25/30fps) |
| Second stream | 704×576 (1~25fps), 704×480 (1~30fps) |
| Bitrate | H.264: 32-4096 kbps, H.265: 12-4096 kbps |
| Video compression | H.265, H.265+, H.264, H.264+, MJPEG |
| Day/Night | ICR - mechanical infrared filter |
| Illuminator | IR LED + WhiteLight |
| IR / WhiteLight range | 30 m / 30 m |
| Microphone | Yes |
| Audio compression | G.711A, G.711Mu, G.726, PCM |
| Support | Web, CMS BCS Manager (Windows/Linux/MAC), Mobile App (iOS, Android) |
| Motion detection / Privacy masks | 4 / 4 |
| Networking | RJ-45 10/100 Mbps |
| Compatibility | ONVIF (S/T) |
| Protocols | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP |
| Power supply | 12VDC / PoE (802.3af) |
| Power consumption | max 5.7W |
| Housing color | White |
| Degree of protection | IP67 |
| Operating conditions | -40°C ~ +60°C, max 95% RH |
| Dimensions | Ø106×94 mm |
| Weight | 0.33 kg |
