EZVIZ HP7 PRO 4K WiFi Video Door Phone, Face Verification, Remote Unlocking, Motion Detection
Photo gallery
-
Manufacturer
-
Product Code
CS-HP7-R400-1W2TFD (Pro)
-
Warranty
24 miesiące
Ask about this product show form
Related products
Product Description
Key features:
- 4K resolution - exceptionally detailed video
- Opening by palm verification - palm vein recognition technology for enhanced security
- Opening by face verification (3D structured light) - precise and fast unlocking
- 8-inch touchscreen - intuitive operation and high-quality video viewing
- 2-wire installation - easy installation in an existing system
- Remote door/gate opening¹ - convenient access control from anywhere
- Remote control with the EZVIZ app - full control from your smartphone
- WDR technology - better visibility in high contrast lighting conditions
- Image distortion correction - realistic viewing without curves
- EZVIZ ColorFULL night vision - colorful recordings even at night
- Human motion detection - intelligent presence detection
- Two-way communication - ability to talk to guests in real time
- Weatherproof - reliable operation in various weather conditions
- Wi-Fi 6 (2.4 / 5 GHz) support - fast and stable wireless connection
- MicroSD card support (up to 512 GB) and EZVIZ CloudPlay² - flexible recording storage options
HP7 Pro redefines the concept of front door security. The device instantly recognizes household members and family friends by their unique characteristics, combining advanced opening methods with concern for your peace of mind and security. With HP7 Pro, you get notifications of visitors outside your home - you can talk to them and see them in crystal 4K resolution. HP7 Pro also gives you the ability to connect your other EZVIZ devices to the indoor screen of the intercom, further simplifying their operation - a new level of home security, designed for simple and smart living right from your doorstep.
State-of-the-art entry system
HP7 Pro recognizes the householder and automatically opens the gate for them. Thanks to EZVIZ technology, you are assured that only authorized people will enter - you and your loved ones can feel safe.
The dark night becomes clearer
Almost nothing will hide in the dark - thanks to its large F1.6 aperture, the HP7 Pro provides a bright and clear image around the clock. For your convenience, the intercom lens can automatically switch between two night observation modes
Stable connection for greater efficiency
To guarantee an optimal connection between devices, the indoor monitor can be connected to a 2.4 or 5 GHz Wi-Fi band. Enjoy strong Wi-Fi with lower latency, higher bandwidth and a stable signal.
Greater convenience with smaller video files
Compared to the commonly used H.264 video compression technology, H.265 technology provides a clearer experience when watching recorded video. You no longer have to worry about large files taking up too much disk space - H.265 technology reduces the size of the recording by up to 50%⁴.
High-capacity, secure storage options you can trust
You can store your recorded videos on a local microSD card of up to 512GB, or subscribe to the EZVIZ CloudPlay service for fully encrypted cloud storage.
We go to great lengths to protect your data and privacy
We have designed our product to respectfully protect your data and privacy. You have the option to set a no-filming zone to make sure you only record when it's appropriate and allowed.
Technical specifications:
| Specifications - EZVIZ HP7 Pro 4K Palm Vein Video Doorphone | |
|---|---|
| Model | CS-HP7-R400-1W2TFD (Pro) |
| External panel | |
| Image sensor | CMOS 1/2.8" (progressive scan, low light sensitivity) |
| Lens | 2.0 mm @ F1.6, viewing angle: 158° (diagonal) |
| Day/night mode | IR-cut filter with automatic switching |
| Max resolution | 4K (3840 × 2160) |
| DNR | 2D / 3D DNR |
| Video compression | H.265 / H.264 |
| Frame rate | Max. 15 fps (dynamic network adaptation) |
| Connectivity and control | |
| Connection method | 2-wire wired (optional 4-wire) |
| Transmission distance | Up to 50 m (Φ 2 x 0.75 mm²), up to 100 m (Φ 2 x 1.5 mm²) |
| Gate opening | 2 ports, dry connection, max. 12 V / 2 A |
| Gate opening | 2 ports, max. 12 V / 1.1 A, memory lock required |
| Door opening methods | 1. palm vein scanning 2. Face recognition 3. RFID fob (3 pcs included) 4. EZVIZ app 5. Internal monitor 6. Digital code 7. QR code |
| Audio / Video / Interface | |
| Audio input | Built-in high-sensitivity microphone |
| Audio output | Built-in high-power speaker |
| Bell button | Backlit, 1 button |
| Name card | 3 pieces included, backlit |
| Terminals | 2 for monitor, 2 for gate, 2 for striker |
| Features and alarms | |
| Intelligent alarm | Human motion detection |
| Tamper alarm | Supported |
| Video intercom | Two-way video communication |
| General parameters (external panel) | |
| Operating conditions | -30°C to 60°C, humidity up to 95% (non-condensing) |
| Waterproof | Yes (with cover) |
| Dimensions | 191.8 × 91 × 40 mm |
| Power supply | 24 V DC from the monitor |
| Internal monitor | |
| Display | 8-inch touch screen, 1280 × 800 |
| Audio input / output | Microphone and speaker built-in |
| Buttons | Screen on/off switch |
| MicroSD card | Supports up to 512 GB |
| Network and Wi-Fi parameters | |
| Protocol | EZVIZ Cloud, EZVIZ Connect (proprietary) |
| Wi-Fi standard | IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Frequency | 2.4 GHz and 5 GHz |
| Bandwidth | 20 MHz (2.4G), 80 MHz (5G) |
| Security | WPA/WPA2/WPA3, PSK |
| Transmission speed | Up to MCS11 |
| General (monitor and set) | |
| Monitor functions | Live view, playback, talk, video call |
| Operating conditions (monitor) | 10°C to 45°C, humidity up to 95% |
| Monitor dimensions | 200.3 × 123 × 15 mm |
| Weight | Product: 1130 g, with packaging: 2418 g |
| Power supply | DC 24V/1A, adapter (100-240V AC) |
| Power consumption | 8 W (typical), max. 36 W |
| Package contents | |
| - 8-inch touchscreen monitor - Wall bracket - Power supply - External panel with cover - Mounting templates - Screwdriver - Power cable - 3 × RFID key fobs - 3 × name cards - Wires and connectors - Screw set - Instructions and brochures |
|
| Certifications | |
| Certifications | CE / REACH / WEEE / RoHS |
