IP Bullet Camera 4Mpx BCS-L-TIP14FCR3L3-Ai1, NightColor

Here are the main features of the BCS-L-TIP14FCR3L3-Ai1 camera:

• Product line: BCS Line
• Camera type: Tube
• Resolution: 4 Mpx (2688×1520 pixels)
• Sensor: 1/2.9'' CMOS, Progressive Scan
• RAM: 128 MB
• ROM: 128 MB
• Lens: Fixed, 2.8mm focal length, F1.6 aperture
• Focus: Fixed
• Iris: Fixed
• Digital zoom: 16×
• Viewing angle:
  • H: 95°
  • V: 52°
  • D: 114°
• DORI:
  • Detect: 64m
  • Observe: 25m
  • Recognize: 13m
  • Identify: 6m
• Camera Sensitivity:
  • 0.006 Lux (Color, F1.6, 30IRE)
  • 0.0006 Lux (B/W, F1.6, 30IRE)
  • 0 Lux (IR)
• S/N ratio: 56 dB
• White balance (AWB): Auto / manual
• WDR: 120 dB
• Background compensation: BLC / HLC / WDR (120 dB)
• Shutter: Auto / manual 1/3~1/100000s
• Gain Control (AGC): Auto / manual
• Noise Reduction: 3D DNR
• Image rotation: Mirror, Flip 0°/90°/180°/270°
• Number of streams: 2
• Stream resolutions:
  • Main stream: 2688×1520(125/30fps), 1920×1080(125/30fps)
  • Second stream: 704×576(125fps), 704×480(130fps)
• Bitrate:
  • H.264: 32 Kbps~6144 Kbps
  • H.265: 12 Kbps~6144 Kbps
• Video compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
• Day/night mode: ICR mechanical infrared filter
• Illuminator type: IR LED + White Light, range up to 30m
• NightColor: Yes
• Microphone: Yes
• Audio compression: G.711A / G.711Mu / G.726 / PCM
• Storage: FTP, SFTP, NAS
• Memory card slot: microSD up to 256GB
• Support: Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App (iOS, Android)
• Motion Detection: 4 zones
• Privacy masks: 4 zones
• Network: RJ-45 10/100 Mbps
• Compatibility: ONVIF(S/G/T)
• Protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP
• Power supply: 12VDC / PoE(802.3af)
• Power consumption: max 5.2W
• Housing color: White
• IP rating: IP67
• Operating conditions: -40°C~+60°C, max 95% RH
• Dimensions: 166.2×70×70mm
• Weight: 0.48 kg

Intelligent (Ai) functions:

• Built-in intelligent image recognition and analysis algorithms
• Perimeter protection: Area intrusion detection, line crossing detection
• Object recognition: Person/mechanical vehicle recognition for area intrusion, line crossing, false alarm reduction
• SMD: SMD 4.0 (Smart Motion Detection)

The BCS-L-TIP14FCR3L3-Ai1 camera is an advanced device for professional surveillance systems, equipped with intelligent video analysis functions, high image resolution and comprehensive processing and storage capabilities. With an IP67 rating, it is also suitable for use in harsh weather conditions.
