10–calowy manipulator graficzny SATEL INT-TSH210 w kolorze czarnym, do obsługi systemu alarmowego

SATEL INT-TSH2-W 7'' keypad for alarm system operation

SATEL INT-TSH2-W keypad in a white housing. It is designed to control and manage the INTEGRA, INTEGRA Plus, VERSA and VERSA Plus family of alarm control panels. The device is equipped with a capacitive touchscreen used instead of traditional buttons, and a large 7" widescreen LCD display. The INT-TSH2 series keypad provides quick and easy access to information about the current system status. Thanks to the large, easy-to-read widgets and the ability to define the information indicated in the status screen mode, a single glance at the device's screen is all it takes to find out what's going on in the protected premises. In addition, it is also possible to run a photo show on the keypad. The INT-TSH2-B allows not only simple security management and quick call for help, but also convenient control of building automation elements (including KNX), including indoor and outdoor lighting, heating, air conditioning, operation of blinds or sprinklers. In addition, thanks to MAKRO commands, launching a sequence of such tasks can be done at the touch of just one dedicated icon on the control panel. The device features convenient operation thanks to an intuitive graphical user interface. It is based on a set of specially designed icons that allow, among other things, quick access to control individual system components, as well as to check information about the system's status. The INT-TSH2's capacitive touchscreens guarantee excellent readability of the displayed elements. This combination ensures trouble-free operation of the entire system - also when used by children and the elderly. The INT-TSH2 and INT-TSG2 keypads can display more than 16 million colors - more than the human eye can distinguish. The high image quality is hidden behind a glass panel that protects the display from scratches.


Main Features:

• Interoperability with control panels of the series:
• INTEGRA (Firmware v1.14 or later),
• INTEGRA Plus (Firmware v1.14 or later),
• VERSA (Firmware v1.06 or later),
• VERSA Plus (Firmware v1.06 or later),
• 7" capacitive touchscreen responsive to light touch
• Resolution of 1024x600, display of 16.7 million colors (true color)
• Multi-level customizable graphical interface
• MAKRO functions to facilitate control of the alarm system and home automation components (supported by INTEGRA and INTEGRA Plus control panels only)
• Customizable status screen
• 2 zones (supported by INTEGRA and INTEGRA Plus control panels only)
• Capability to activate panic, FIRE, and AID alarms
• Built-in microSD memory card reader (storing photos for photo frame, background of additional screens, sounds for input violations - chimes)

Technical specifications:
