Camera features IPC-B140HA-LUC:

• 1/2.8" Progressive Scan CMOS sensor – provides a clear and smooth image.
• 4 MP resolution (2560 × 1440) – allows more details to be captured in the frame.
• 2.8 mm lens – wide viewing angle for monitoring the surroundings.
• Sensitivity 0.01 lx, 0 lx with IR – good visibility even in very low light.
• Smart Hybrid Light night mode – the ability to operate at night in color or black and white.
• IR illuminator up to 20 m – effective scene illumination after dark.
• White light illuminator up to 15 m – additional support for nighttime color monitoring.
• H.265+, H.265, H.264+, H.264, MJPEG compression – flexible recording settings and space saving.
• 120 dB WDR – better reproduction of scenes with strong light contrasts.
• BLC, HLC, 3D DNR image functions – improved image clarity in more challenging conditions.
• Built-in microphone – enables audio recording together with video.
• Smart image analysis – motion detection with human classification.
• Support via iVMS-4200, Hik-Connect and HiLook App – convenient remote viewing and camera management.
• IP67 protection rating – resistant to dust and precipitation.
• Power consumption up to 6.5 W – energy-efficient operation.
• Operating temperature from -30°C to +45°C – suitable for outdoor use.
• 12 V DC or PoE power supply – convenient installation options.
• Dimensions 138 × 61 × 58 mm – slim housing for easier installation.
• Weight 250 g – lightweight design.

High-quality image

The light-sensitive sensor in the IPC-B140HA-LUC camera and the high-quality imager combined with advanced optics deliver a high-quality image with excellent sharpness. The device records in 4 MP resolution, giving it a significant advantage over typical Full HD models. It ensures that even the smallest detail is captured in the video footage.

• A: 1280x720p ( 1 MP )
• B: 1920x1080p ( 2 MP )
• C: 2048x1536p ( 3 MP )
• D: 2560x1440p ( 4 MP )
• E: 2560x1960p ( 5 MP )
• F: 3840x2160p ( 8 MP )

Motion detection

IPC-B140HA-LUC has a built-in image motion detection algorithm. Additionally, it allows sending notifications to a phone or computer. You can also freely define the area of interest, so that, for example, you receive notifications only about movement at the entrance gate. In addition to recording 24/7, the cameras can also record only fragments after motion is detected, which reduces hard drive usage.

P2P function

In surveillance cameras, this is a technology that enables direct communication between the camera and the end device (such as a smartphone or computer) without the need to use an external server. Here are the main features and operating principles of this function:

• Direct Connection: P2P allows a direct connection between the camera and the user's device. This means that video data can be transmitted directly, without having to pass through an intermediary server.
• Ease of Configuration: One of the main advantages of P2P is ease of configuration. The user often only needs to scan a QR code or enter the camera ID to establish a connection.
• Remote Access: The user can access the camera image from anywhere in the world, provided that both the camera and the end device have internet access.

Power Over Ethernet (PoE)

The Power over Ethernet (PoE) function in the IPC-B140HA-LUC camera is a technology that enables the transmission of data and electrical power to a network device using a single Ethernet cable. Thanks to this solution, cameras can be installed in places where access to power sources is limited or nonexistent. PoE simplifies installation by reducing the need for additional cables and power adapters. Moreover, surveillance systems using PoE are easier to scale, because adding a new camera only requires connecting it to the PoE network. This increases the flexibility and cost efficiency of surveillance systems.

IP67 weather-resistant design

This type of housing protects the IPC-B140HA-LUC from external factors such as dust, dirt, or moisture, which is especially important in industrial environments or in places with high dust levels. Cameras with an IP67 housing can be installed in a variety of locations, from industrial to marine environments, without worrying about damage caused by environmental factors.

LED illumination and color image after dark - Smart Dual Light

The hybrid light function in the IPC-B140HA-LUC combines infrared LED illumination (IR) for nighttime applications with white LED light, which can be activated in response to motion detection or remotely by the operator. This technology provides not only high image quality in complete darkness thanks to infrared, but also the ability to deter intruders by automatically or manually turning on visible white light, increasing security and surveillance effectiveness.

Remote access from phone and desktop computer

HiLook by Hikvision systems enable configuration, control, and live viewing via the Hik-Connect and iVMS-4200 applications, which provide constant access to monitoring from anywhere in the world with internet access. The above programs allow you to:

• Access live video preview and play back recorded footage
• Save video clips to smartphone memory
• Configure time frames for motion detection
• Receive notifications from motion detection or other events
• Share your devices with other smartphones using the mobile app, e.g. with family members or employees

Hik-Connect - Free app for smartphones with iOS and Android
iVMS-4200 - Free app for desktop computers

Wide dynamic range - High quality in difficult conditions

WDR (Wide Dynamic Range) 120 dB is an advanced technology used in surveillance cameras such as the IPC-B140HA-LUC, which enables recording clear images in conditions of high lighting contrast, where both bright and dark areas may appear simultaneously in the same scene. WDR 120 dB is a technology based on combining two or more frames with different exposures into one image. In practice, the camera records two images — one with a short exposure time, which captures details in bright areas, and another with a longer exposure time, which captures details in dark parts. Then the camera software combines these images to obtain one well-balanced frame in which all details are visible.

Benefits of WDR 120 dB

• Better image quality: Thanks to clear details in both dark and bright parts of the image, WDR 120 dB technology eliminates the problem of so-called "overexposure" and "underexposure."
• Greater surveillance effectiveness: It makes it easier to recognize faces, license plates, and other important elements, which is crucial for security analysis.
• Reduced need for additional lighting: Less need to use extra lighting, which can lead to energy savings and reduced costs.



Video and audio recording

The audio recording function in the IPC-B140HA-LUC allows sounds to be recorded together with the video image, significantly increasing the capabilities and effectiveness of surveillance systems. The key advantages of this solution are:

• Comprehensive surveillance: Audio recording makes it possible to collect more detailed information about the monitored environment, which can be helpful in event analysis or person identification.
• Situation analysis: Sound can provide additional information that is not visible in the image, such as conversations, background noise, or other sounds, which may be important for understanding the context of an event.
• Improved surveillance effectiveness: Integrating audio with a visual surveillance system increases the overall effectiveness of the system, enabling faster and more precise responses to events.

Technical specification:

Parameter	Value
Model	IPC-B140HA-LUC
Camera
Sensor	1/2.8" Progressive Scan CMOS
Transmission standard	IP
Max. resolution	2560 × 1440 (4 MP)
Sensitivity	Color: 0.01 Lux @ (F2.2, AGC ON), B/W: 0 Lux with IR
Head adjustment range	Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Shutter time	1/3 s to 1/100,000 s
Lens	2.8 mm
Recording angle	Horizontal FOV 104°, vertical FOV 57°, diagonal FOV 123°
Mount	F2.2
IR illuminator	Yes, range up to 20 m
White light illuminator	Yes, range up to 15 m
Smart supplemental light	Yes
Wavelength	850 nm
Image compression
Frame rate (main stream)	50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)
Video compression	H.265+ / H.264+ / H.265 / H.264 / MJPEG
Video bitrate	32 Kbps to 8 Mbps
Smart functions
ROI	1 fixed region for two streams
Image functions	BLC, HLC, 3D DNR, ROI
Wide dynamic range	Yes, WDR 52 dB
Image settings	Saturation, exposure, contrast, sharpness, AGC, white balance
Night mode	Yes, in color or black and white (Smart Hybrid Light)
ColorVu	Yes
Smart image analysis	MD 2.0
Perimeter protection	Yes
Human detection (classification)	Yes
Basic functions	Motion detection, video tampering, exception event (IP network disconnected, address conflict, hard drive error, etc.), scene change detection
Linkage methods	FTP/NAS/memory card, monitoring center notification, e-mail, recording trigger, capture of triggered recordings
Activity zones	1 fixed region for the main stream, sub-stream, and third stream
Network
Network interface	1 × RJ45 Ethernet 10/100 Mbps self-adaptive
Network protocols	IPv4, IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP
Simultaneous live view	Up to 6 channels
Number of users / hosts	Up to 32 users, 3 permission levels: Administrator, Operator, User
Client software	VMS-4200, Hik-Connect
Supported WEB browsers	IE 10, IE 11, Chrome 57.0+, Firefox 52.0+, Edge 89+
Compatibility	ONVIF (Profile S, Profile T), ISAPI, SDK
Audio
Audio type	Mono
Built-in microphone	Yes
Noise filtering	Yes
Audio compression	G.711ulaw / AAC-LC
Audio bitrate	64 Kbps (G.711ulaw) / 16 to 64 Kbps (AAC-LC)
General
Power supply	12 V DC / PoE (802.3af, class 3)
Power consumption	12 V DC, 0.5 A, max. 6 W PoE (802.3af), max. 6.5 W
Material	Metal + plastic
Protection rating	IP67
Operating temperature / permissible humidity	-30 °C to 45 °C <95% (non-condensing)
Dimensions	138 mm × 61 mm × 58 mm
Weight	250 g
