IP Network Recorder BCS-NVR04015ME-P-II
Photo gallery
-
Manufacturer
-
Product Code
BCS-NVR04015ME-P-II
-
Warranty
36 miesięcy
- Technology: IP
- Number of channels: 4
- Built-in POE switch: Yes
Files attached to the product show files
Files for download
-
Size: 4,33 MB
-
Size: 0,64 MB
Price (Incl. VAT):
Archival product
Najniższy koszt dostawy: 12,98 zł
Do you represent a budgetary unit?
Check out the deferred payment option.
Product Description
Main features:
- 4 Channel NVR Network Recorder
- Quad-Core processor for simultaneous viewing, recording and remote management
- H.265/H.264/MJPEG dual stream encoding
- Recording of max. 4 cameras IP@8Mpx,6Mpx,5Mpx,4Mpx,3Mpx,1080p,1.3Mpx,720p, max. bitrate 80 Mbps
- Synchronous playback of all channels
- Simultaneous operation of HDMI 4K and VGA outputs
- Remote operation of camera recording parameter settings (selected models)
- Search for IP cameras in the network, PTZ support over the network
- Advanced video detection: motion detection, obstruction, image loss
- Intelligent functions: line crossing, trespassing, disappearance/objects left behind, face detection, audio detection, people counting
- Built-in 4-port PoE switch
- Support for 1 SATAIII drive max. 6TB, 2 USB2.0 ports, audio input and output
- Built-in web server, support via CMS (DSS/Smart PSS/BCS Manager), DMSS, BCS mobile application (iOS, android), P2P
- Included : mouse, power adapter, Ethernet cable, manual, CD
Technical specifications:
| Model: | BCS-NVR04015ME-P-II |
| System | |
| Processor | High-performance Quad-core processor |
| Operating system | Embedded LINUX |
| Functionality | Pentaplex function |
| Control | Mouse, Keyboard, Network |
| Video and Audio | |
| Support for IP cameras | 4 channels |
| Video output | 1 HDMI 4K, 1 VGA |
| Output/Input. Audio | 1 Input. And 1 Audio Output, INTERCOM |
| Screen | |
| Screen division | 1/4 |
| Video output resolution | 3840x2160, 1920×1080, 1280×1024, 1280×720 |
| Sequence | yes |
| Privacy zones | 4 definable zones on each channel |
| OSD | Camera name, time, video loss, camera lock, motion detection, recording |
| Recording | |
| Compression | H.265 / H.264 / MJPEG |
| Recording in resolution | 8Mpx(3840x2160), 6Mpx(3072x2048), 5Mpx(2560x1920), 4Mpx(2688x1520), 3Mpx(2048x1536), 1080P(1920×1080) / 720P(1280×720) |
| Max. bandwidth occupancy | Channel : from 16Kbps ~ 20Mbps , bitrate incoming 80Mbps, outgoing 48Mbps |
| Recording quality | CBR, VBR(1~6 levels) |
| Recording modes | Manual, Schedule (Regular(Continuous), MD (Video detection: Motion Detection, Fade, Cover), Alarm), Stop |
| Recording priority | Manual > Alarm > MD > Regular |
| Recording intervals | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec. |
| Detection & Alarm | |
| Event triggering | Recording, PTZ, Tour, Alarm, Email, FTP, Spot, Buzzer & screen messages |
| Motion Detection | Zones: 396(22×18), Sensitivity: 1~6 |
| Video Fade & Blinding | Yes |
| Alarm Inputs | N/A |
| Relay outputs | N/A |
| Playback & Archiving | |
| Channel playback | Division 1/4 |
| Search mode | Time/Date, Alarm, MD & Advanced Search (every second), Smart Search |
| Playback functions | Play, Pause, Stop, Rew, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Archive, Digital zoom |
| Archiving | Flash drive / USB HDD / USB CD&DVD-RW / Network download. |
| Network | |
| Port | RJ-45 port (10/100M) |
| PoE | 4xPoE(IEEE802.3at/af) - 4Mbps bandwidth per channel recommended |
| Network functions | HTTP, HTTPS, IPV4/IPV6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search (BCS IP cameras, DVR), easy4IP |
| Max. number of users | 128 (simultaneously) |
| Smartphone support | iOS, android |
| Disk support | |
| HDD | 1 SATA port max. 6TB |
| HDD management | Hibernation, Error detection |
| Additional interfaces | |
| USB | 2 USB2.0 ports rear panel |
| RS232 | N/A |
| RS485 | N/A |
| Other | |
| Power supply | DC48V/1.5A |
| Current consumption | 7.5W(without HDD) PoE max 25.5W per port, total max 50W |
| Environmental conditions | -10 ~+50°C / 10~90%RH / 86~106kpa |
| Dimensions | smart 1U, 205mm×205mm×45mm(W×D×H) |
| Weight | 0.5KG (withoutHDD) |
