Omnidirectional antenna AMO-5G13 UBIQUITI 5.45GHz-5.85GHz 13dBi

The image shows a sleek, cylindrical omnidirectional antenna designed for outdoor use, featuring a sturdy mounting bracket for secure installation. The antenna is primarily white with a metallic base, suitable for enhancing wireless connectivity in the 5.45 GHz to 5.85 GHz frequency range.
A close-up of a metallic connector with a sleek, cylindrical design and multiple screws for secure attachment. The connector is mounted on a flat, rectangular base with two holes for installation.
The image shows a metal mounting bracket with a rectangular base and four circular holes for secure attachment. The bracket features a ribbed design on the upper section and a smooth, light-colored lower section with two slots.
Graph showing the reflection attenuation characteristics of a product, with frequency on the x-axis (5.45 GHz to 5.85 GHz) and decibels on the y-axis (-30 dB to -10 dB). Two lines represent vertical polarization (V-pol) and horizontal polarization (H-pol), illustrating their respective attenuation levels across the frequency range.
The image displays two polar plots illustrating directional characteristics for vertical polarization, with the left plot showing a broad, rounded pattern and the right plot depicting a more elongated, narrow pattern. These graphs are used to analyze the signal strength and directionality of antennas.
The image shows two polar plots illustrating directional characteristics for horizontal polarization. The left plot features a circular pattern in green, while the right plot displays a more directional pattern in blue.
Outdoor Wi-Fi antenna with a sleek, cylindrical design and a sturdy mounting bracket for easy installation. The antenna features dual cables for enhanced connectivity and performance.
The image shows a set of mounting hardware, including four long metal bolts, four hex nuts, and three white plastic brackets. Additionally, there are two coaxial cable connectors with transparent protective covers.
The image shows a sleek, cylindrical omnidirectional antenna designed for outdoor use, featuring a sturdy mounting bracket for secure installation. The antenna is primarily white with a metallic base, suitable for enhancing wireless connectivity in the 5.45 GHz to 5.85 GHz frequency range.

Photo gallery

A close-up of a metallic connector with a sleek, cylindrical design and multiple screws for secure attachment. The connector is mounted on a flat, rectangular base with two holes for installation.
The image shows a metal mounting bracket with a rectangular base and four circular holes for secure attachment. The bracket features a ribbed design on the upper section and a smooth, light-colored lower section with two slots.
Graph showing the reflection attenuation characteristics of a product, with frequency on the x-axis (5.45 GHz to 5.85 GHz) and decibels on the y-axis (-30 dB to -10 dB). Two lines represent vertical polarization (V-pol) and horizontal polarization (H-pol), illustrating their respective attenuation levels across the frequency range.
The image displays two polar plots illustrating directional characteristics for vertical polarization, with the left plot showing a broad, rounded pattern and the right plot depicting a more elongated, narrow pattern. These graphs are used to analyze the signal strength and directionality of antennas.
The image shows two polar plots illustrating directional characteristics for horizontal polarization. The left plot features a circular pattern in green, while the right plot displays a more directional pattern in blue.
Outdoor Wi-Fi antenna with a sleek, cylindrical design and a sturdy mounting bracket for easy installation. The antenna features dual cables for enhanced connectivity and performance.
The image shows a set of mounting hardware, including four long metal bolts, four hex nuts, and three white plastic brackets. Additionally, there are two coaxial cable connectors with transparent protective covers.

  • Manufacturer

  • Product Code

    AMO-5G13

  • Warranty

    24 miesiące

see description

Ask about this product show form

Do you have questions? Looking for answers? Are you interested?

  • Call
  • 34 341 16 30
  • We advise Mon - Fri 8 00 am to 4 00 pm
  • or send a message using the form below

Copy the code from the picture

weryfikator

Close

  • Availability: in stock Shipping 24/48h

Price (Incl. VAT):

238 €

Add to Watchlist

Do you represent a budgetary unit?
Check out the deferred payment option.

CA Raty

Product Description

AirMax Omni dual-polarized omni-directional antenna. The antenna is designed to work with a dedicated Ubiquiti Rocket M5 device. Thanks to its omnidirectional radiation pattern, it allows building a very efficient and relatively inexpensive 802.11n 2xMIMO base station with throughput up to 300 Mbps. AMO-5G13 is an ideal solution for distributed client environments where there is a need to cover a large area (360 degrees) with a high network capacity.

Technical specifications:

Frequency range:5.45 GHz ... 5.85 GHz
Energy gain : 13 dBi
Wave polarization:dual linear
VSWR:1.5:1
Horizontal (H) main beam width:360 °
Main beam width in thevertical plane (V):7 °
Connector:SMA-RP
Attachment to mast:max. Ø 60 mm
Cable length:Not
Weight:0.79 kg
Dimensions:799 x 90 x 65 mm
Manufacturer/Brand:UBIQUITI

Szczegóły dotyczące zgodności produktu z przepisami: Osoba odpowiedzialna za produkt
