Hotel access controller PR821-CH
Photo gallery
-
Manufacturer
-
Product Code
PR821-CH
-
Warranty
36 miesięcy
- Application: Interior
- Frequency: 125/13.56 kHz
- Autonomous operation: No
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,13 MB
-
Size: 1,51 MB
-
Size: 0,43 MB
Product Description
PR821-CH hotel access controller
Main features:
- card slot with support for EM 125 kHz and 13.56 MHz MIFARE cards
- cooperation with an external reader placed at the entrance to the room
- cooperation with a touch-sensitive function key panel (HRT82FK)
- three NO/NC input lines
- two transistor outputs 1A/15V DC
- relay output 1.5A/30V
- power supply: 12V DC
- communication via RS485
- protection class: IP41
- possibility to control:
- anti-burglary system
- electrical power supply
- air conditioning
- average current consumption: 100 mA
- tamper contact: potential-free NC type contact, 24V/50mA
- identification modes: card
- operation with PR Master software
- illumination of the card pocket
- warranty: 36 months
Technical specifications:
| Power supply voltage | Nominal 12 V DC, acceptable 10-15 V DC | ||
| EM 125 kHz (UNIQUE) compatible with EM4100/4102 and 13.56 MHz compatible with ISO/IEC 14443A and MIFARE® | |||
| Reading range | Up to 15 cm for ISO type cards | ||
| Average current consumption | approx. 100mA | ||
| Contact Tamper | Potential-free NC type contact, 24V/50mA | ||
| Inputs | Three (IN1 - IN3) two-state NO/NC input lines internally polarized to supply plus via 15kΩ resistor, switching threshold approx. 3.5V | ||
| Relay output | Relay output (REL1) with one isolated NO/NC contact, max load 30V/1.5A | ||
| Transistor outputs | Two transistor outputs (IO1, IO2) of open collector type, max. load 15VDC/1A | ||
| Distances | Between controller and communication interface (RS485): max. 1200m Between controller and PRT reader (RACS CLK/DTA): max. 150m Between controller and XM expander (RACS CLK/DTA): max. 150m |
||
| Environmental class | II | ||
| Operating temperature | -10°C ~ 50°C | ||
| Relative humidity | 10% ~ 95% (non-condensing) | ||
| Protection class | IP41 | ||
| Weight | approx. 120g | ||
| Dimensions (W/H/D) | 85x85x27mm |
