IP Monitoring Set 8x LV-V-IP5M25DF-B 5MPx, 1x LV-NVR-9CH KEEYO
Photo gallery
-
Manufacturer
-
Product Code
ZM22055
-
Warranty
24 miesiące
- Technology: IP
- Resolution: 5MPx
- Enclosure: Dome
- Number of cameras: 8
- Connectivity: Wired
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 0,23 MB
-
Size: 0,32 MB
-
Instrukcja obsługi rejestratora
Size: 4,09 MB
-
Size: 0,69 MB
Related products
Product Description
LV-V-IP5M25DF-B is a camera created for good quality surveillance. It is a network camera, which means that the video signal is transported digitally, so it is of much better quality than in analog cameras. In addition, it is equipped with 120dB hardware WDR, this allows the camera to retain image detail in dark and brightened areas. It has two infrared LEDs, which are fully sufficient to illuminate most properties. In addition, it can be used as an independent surveillance device thanks to support for memory cards with a maximum capacity of 512GB.
ADVANTAGE OF IP MONITORING OVER AHD
It is primarily responsible for the digital signal in network monitoring. When the image in AHD sets loses quality due to the analog signal, IP sets maintain a clear and crisp image. In addition, network monitoring can be much more easily connected to an existing network installation in a home or business.
Another strong point of IP monitoring is the ability to run only one cable to the camera, connecting the camera to the DVR with a UTP cable, you will provide the camera with power and video signal.
Contrary to what you might think, network monitoring and analog monitoring have very similar Internet bandwidth consumption. When not using the live view on the mobile app, internet usage is negligible. The cameras transmit video to the DVR over the local network, and even when your provider's internet network goes down, the monitoring will continue to function.
Toshiba drives are specially designed devices for the monitoring system, resistant to continuous operation for 24 hours, which ordinary PC drives would not withstand. In addition, the 1TB drive is enough for two weeks of recording, after which time old recordings will begin to overwrite with new ones.
Bitvision is a mobile application for smartphones and tablets, which allows you to access video viewing from anywhere on earth with Internet access, notification in case of event detection, and in addition, it does not require an external IP address. The app is in Polish and available for free for Android and iOS devices.
The cameras are IP67-certified, which means they have been adequately protected against moisture and harsh weather conditions.
In turn, they are equally suitable for indoor and outdoor installation.
The cameras have motion detection functions in the image, such a solution informs about any object moving in the frame. In addition, you can adjust the sensitivity of detection and the area in the image to cancel unwanted alerts caused by the movement of plants or smaller animals.
The suggested mounting surface for dome cameras is horizontal surfaces (e.g. ceilings), in order to properly mount the camera it is necessary to position its frame so that there are no walls 1-2m away in the field of view, or other closely placed obstacles that may interfere with the dispersion of infrared light. This will fully exploit the potential of infrared light and get the best possible image at night.
The suggested mounting height for dome cameras is from 2m to 3.5m.
KIT CONTENTS:
- Keeyo LV-V-IP5M25DF-B 5MPx camera (6pcs).
- Keeyo LV-NVR-9CH DVR (1pcs).
- PoE switch 8+2 (1pc).
- Toshiba S300 1TB HDD (1pc).
- UTP network cable (30m.).
- Set of RJ45 plugs
- "ATTENTION MONITORED OBJECT" sticker (1pcs.)
ADVANTAGE OF IP MONITORING OVER AHD
It is primarily responsible for the digital signal in network monitoring. When the image in AHD sets loses quality due to the analog signal, IP sets maintain a clear and crisp image. In addition, network monitoring can be much more easily connected to an existing network installation in a home or business. Another strong point of IP monitoring is the ability to run only one cable to the camera, connecting the camera to the DVR with a UTP cable, you will provide the camera with power and video signal.
USE OF INTERNET CONNECTION
Contrary to what you might think, network monitoring and analog monitoring have very similar Internet bandwidth consumption. When not using the live view on the mobile app, internet usage is negligible. The cameras transmit video to the DVR over the local network, and even when your provider's internet network goes down, the monitoring will continue to function.
UP TO 7 DAYS OF STORED VIDEO
Toshiba drives are specially designed devices for the monitoring system, resistant to continuous operation for 24 hours, which ordinary PC drives would not withstand. In addition, the 1TB drive is enough for two weeks of recording, after which time old recordings will begin to overwrite with new ones.
REMOTE ACCESS - Bitvision
Bitvision is a mobile application for smartphones and tablets, which allows you to access video viewing from anywhere on earth with Internet access, notification in case of event detection, and in addition, it does not require an external IP address. The app is in Polish and available for free for Android and iOS devices.
WEATHERPROOF
The cameras are IP67-certified, which means they have been adequately protected against moisture and harsh weather conditions.
In turn, they are equally suitable for indoor and outdoor installation.
BASIC MOTION DETECTION
The cameras have motion detection functions in the image, such a solution informs about any object moving in the frame. In addition, you can adjust the sensitivity of detection and the area in the image to cancel unwanted alerts caused by the movement of plants or smaller animals.
PROPER INSTALLATION OF THE SURVEILLANCE CAMERA
The suggested mounting surface for dome cameras is horizontal surfaces (e.g. ceilings), in order to properly mount the camera it is necessary to position its frame so that there are no walls 1-2m away in the field of view, or other closely placed obstacles that may interfere with the dispersion of infrared light. This will fully exploit the potential of infrared light and get the best possible image at night.
The suggested mounting height for dome cameras is from 2m to 3.5m.
| Camera | |
| Image sensor | CMOS 1/2.8" SONY Starvis with back illumination |
| Image resolution | 5MP |
| Effective pixels | 2616 (S) x 1964 (W) |
| Compression | H.264/H.265/JPEG/AVI |
| Audio compression | G711A/U |
| TV system | PAL/NTSC |
| Electronic curtain time | Auto: 1/3-1/100000 s |
| Minimum illumination | Color: 0.006 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Signal-to-noise ratio | |
| Scanning system | Progressive |
| Video output | Networked |
| Reset button | No |
| Lens | |
| Focal length and field of view | 2.8mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128° |
| Lens type | Fixed focal length lens, optional 2.8mm |
| Focus control | Fixed |
| Aperture | F1.6 |
| Pixels | 5MP |
| Night vision | |
| Infrared LED | 42µ x 2 pcs. |
| Infrared range | 25M |
| Infrared status | Automatic control |
| Infrared switching | Intelligent, manual and timer mode |
| Networking | |
| Ethernet | RJ-45 (10/100Base-T) |
| Wireless | N/D |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, SMTP, UDP, SNMP |
| ONVIF | Support for ONVIF 19.12 (S/T/G profile) |
| P2P | YES |
| POE | Internal, support IEEE 802.3af |
| Video delay | 0.3 sec (within LAN) |
| Main stream 1 | 2592*1944@30 fps |
| Main stream 2 | 2560*1440@30 fps |
| Main stream 3 | "1920*1080@30 fps |
| 1280*720@30 fps" | |
| Secondary stream 1 | 1280*720@30 fps |
| Additional stream 2 | 720*480@30 fps |
| Additional stream 3 | N/D |
| Triple mode | N/D |
| Web browser | IE8-11, Google Chrome, Firefox, Mac Safari |
| Smartphone | iPhone, Android |
| AI functions | |
| Intelligent analysis | Intrusion detection, line crossing, wandering, person gathering detection (based on person detection), vehicle movement detection |
| Camera functions | |
| Day/Night | Color / Black & White (IR-CUT) |
| Image configuration | Saturation / Brightness / Contrast / Sharpness, Mirroring, 3D NR, White balance, Flicker control (FLK), Shutter detection, HLC |
| Full color | N/D |
| Corridor pattern | Support |
| De-noise mode | N/D |
| ROI | Support |
| BLC | Support |
| WDR | 120 dB |
| Motion detection | Support (allows motion detection based on person movement only) |
| Privacy mask | 3 rectangular zones |
| Recording mode | NVR/CMS/Web |
| Language | "Simplified Chinese, Traditional Chinese, English, Bulgarian, Polish, Arabic, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian, Dutch, Czech, Vietnamese" |
| Interface | |
| Microphone | No |
| Alarm | N/D |
| SD card slot | Internal, support up to 512 GB |
| RS485 | N/D |
| General | |
| Housing | Sphere: metal, base: plastic, IP67 |
| Infrared filter | YES |
| Operating temperature | -20℃ ~ +60℃, max 95% RH |
| Storage temperature | -20℃ ~ +60℃, max. 95% RH |
| Power source | DC12V±10%, 700mA |
| Dimensions | ￠109 x 93 (W) mm |
| Weight | 600 g |
| Recorder | |
| Processor | ARM Cortex A7 Processor |
| Operating System | Embedded LINUX |
| Video | |
| Channels | 9CH (3840*2160,2592x1944, 2048x1536, 1920×1080, 1280×960, 1280×720, etc.). |
| Video outputs | 1 VGA, 1 HDMI |
| Audio | |
| Input | 1 RCA port, support 9CH IPC audio input |
| Output | 1 RCA Port (linear, 1kΩ), HD output |
| Audio Bit Rate | 64kbps |
| Audio compression standard | G711u, G711a, ADPCM_DVI4 |
| Intercom | support (two-way) |
| Alarm | |
| Sensor input | None |
| Output | None |
| Motion detection | 9 channels, MD zones: 396 (22 × 18) |
| Trigger events | Recording, email, FTP, screenshot, beeper and on-screen guidance |
| Display | |
| HD output 1 | 4K(38402160), 19201080,12801024, 1280720, 1024*768 |
| HD 2 output | None |
| VGA | Resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Display division | 9CH/8CH/6CH/4CH/1CH |
| Digital zoom | YES |
| OSD | Camera title, time, recording, motion detection, event alarm |
| Recording | |
| Video compression | H265/H264/H265+/H264+ |
| Resolution | 4K(3840×2160),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),960P(1280x960),720P(1280×720),D1 (720×576/720×480) |
| Recording speed | "PAL: 4K@8CHx25fps,5MP@9CH×25fp,4MP@9CHx25fp,3MP@9CH×25fp,1080P@9CH×25fp, 960P@9CH×25fp,720P@9CH×25fp, D1@9CH×25fp NTSC: 4K@8CHx30fps,5MP@9CH×30fp,4MP@9CH×30fp,3MP@9CH×30fp,1080P@9CH×30fp, 960P@9CH×30fp, 720P@9CH×30fp, D1@9CH×30fp" |
| Recording mode | Manual/Timer/Motion Detection/Intelligent Event |
| Playback and backup | |
| Local synchronous playback | 1CH 4K@30fps, 1CH 5MP@30fps,2CH 4MP@30fps, 2CH 3M@30fps, 4CH 1080P@30fps,6CH 960P@30fps, 8CH 720P@30fps,9CH D1@30fps |
| Decoding capability | 4CH 1080P(1920x1080)@30fps |
| Remote synchronous playback | YES |
| Search mode | ALL, Record from selected date, Motion detection, Alarm, Tag search, Smart event, Image, Log |
| Playback functions | Playback, pause, fast forward, rewind, previous frame, next frame, electronic zoom, trim, audio |
| Backup copy mode | USB device/Network |
| Network | |
| Interface | 1xRJ45 10M/100M, Adaptive Ethernet interface. |
| Input throughput | 80Mb |
| Network functions | IPv6/TCP/IP, HTTP, HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE |
| Onvif | Onvif S, Onvif T |
| Web browser | Edge,IE8-11, Google Chrome, Firefox, Safari |
| CMS software | Windows 7/Windows 8/Windows 10/MAC OS support |
| Cloud support | Yes |
| Smart phone | iPhone, iPad, Android, Android Pad |
| POE | None |
| WIFI | None |
| Storage | |
| Interface type | 1 SATA hard drive interface (SATA 3.5") |
| Capacity | Up to 8 TB capacity |
| eSATA | None |
| General | |
| Interface language | Simplified Chinese, Traditional Chinese, English, Polish, Russian, German, French, Portuguese, Spanish, Italian, Korean, Japanese, Ukrainian |
| USB interface | 2 USB 2.0 interfaces |
| RS485 | None |
| Power consumption | DC12V∕2000mA ≤10W (without hard drive) |
| Operating environment | -10℃～50℃, 10%～90% (humidity) |
| Dimensions (S × G × W) | 260 × 230 × 43 (mm) |
| Weight | 2 kg (without HDD) |
