IP dome camera BCS-V-EIP24FSR3-AI1 4Mpx, 2.8mm, IR30 - BCS View
Photo gallery
-
Manufacturer
-
Product Code
BCS-V-EIP24FSR3-AI1
-
Warranty
36 miesięcy
- Technology: IP
- Resolution: 4Mpx
- Enclosure: Dome
- Night visibility: up to 30m
- Connectivity: Wired
- Memory card slot: Yes
- Audio: Yes
- Color: White
Ask about this product show form
Files attached to the product show files
Files for download
-
Size: 2,02 MB
-
Size: 7,38 MB
-
Size: 0,28 MB
-
Size: 1,45 MB
Related products
Product Description
IP dome camera BCS-V-EIP24FSR3-AI1 4Mpx, 2.8mm, IR30 - BCS View
BCS View 2K IR 30m 4Mpx audio acusense dome camera
- Model: BCS-V-EIP24FSR3-Ai1
- IP dome camera
- 1/3" 4Mpx PS CMOS sensor
- DarkView Starlight technology
- Support for three encoding streams
- Resolution 2688x1520 30fps
- H.265+/H.264+/MJPEG compression
- Mechanical infrared filter ICR
- Functions AGC, AWB, AES, BLC, HLC, WDR(120dB), 3D DNR, ROI
- Motion detection, privacy mask
- Smart functions:
- Perimeter protection
- Area intrusion
- Line crossing
- Object recognition
- Face detection
- Built-in web service, compatibility with BCS-NVR, CMS (BCS Manager), BCS mobile app (android, iOS), P2P, Onvif
- Fixed-focus lens 2.8mm F1.6
- Infrared illuminator with a range of up to 30m
- Built-in microphone
- MicroSD memory card slot up to 256GB
- Outdoor metal housing IP67
- Operating conditions -30°C ~ +60°C
- Power supply DC 12V, PoE (802.3af)
- Image view:
REMOTE ACCESS - BCS Manager
BCS is a mobile application that will allow you to configure devices and remotely view recorded video anytime, anywhere you are, plus it is extremely easy to configure and available in Polish.
AUTOMATIC DAY/NIGHT MODE
Adapted to work in any lighting conditions with visibility up to 30m even in total darkness. In addition, the Day/Night sensor switches the video mode automatically based on the amount of light reaching the lens.
WEATHER RESISTANT
The IP67 rating means that the camera can be placed anywhere. The device guarantees trouble-free operation even in the harshest atmospheric conditions, thanks to the high-quality materials of the device's housing.
HIGH QUALITY IMAGE
The latest technologies used in the camera's sensor and sensor, combined with advanced optics, provide high quality images and excellent sharpness compared to lower resolution cameras. The device records in 2K resolution ensuring that even the smallest detail is captured in the footage.
WIDE DYNAMIC RANGE
The use of Wide Dynamic Range (WDR) takes care of the quality of recordings by detecting and making lighting corrections in areas of overexposure and lack of light. Thanks to this solution, the device is able to capture details of contrasting images.
Technical specifications:
| Video system | IP |
| Scanning system | Progressive Scan |
| Sensor | 1/3" 4Mpx CMOS |
| Pixels | 2688(H) × 1520(V) |
| Sensitivity | Color:0.005Lux@(F1.6, AGC on), B/W:0Lux(IR on). |
| Lens | 2.8mm F1.6 |
| Focus | Fixed |
| Iris | Fixed |
| Viewing angle | horizontal FOV 103°, vertical FOV 55°, diagonal FOV 122° |
| White balance | (AWB) Auto/manual |
| Background compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto/manual (1/3~1/100000s) |
| Gain control | (AGC) Auto / Manual |
| Noise reduction | 3D DNR |
| Day/night function | Mechanical ICR filter |
| Infrared illuminator | 30m |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG(second stream) |
| Main stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Second stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Stream three | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Network connection | RJ-45 (10/100Mbps) |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Compatibility | ONVIF(S/G) |
| Audio | Built-in microphone |
| Audio compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
| Users | Max. 32 |
| Mobile users | iOS, android |
| Power supply | DC12V (±25%) 0.5A max. 6W / PoE(802.3af) 36~57V, 0.22A max 7W |
| Operating conditions | -30°C ~ +60°C, 10%~95% RH |
| Housing | IP67 |
| Weight | 0.6kg |
| Dimensions | Ø127.3 × 95.9 mm (Ø5.01″ × 3.78″) |
